2002 TOYOTA SEQUOIA remote start

02_SEQUOIA_U (L/O 0108)
82002 MY SEQUOIA_U (OM34418U)
Your vehicle is supplied with the two
kinds of keys.1. Master key (black)—This key works in every lock. Your Toyota dealer will
need it to make you a new key with
builtin transponder chip.
2. Sub key (gray)—This key also works in every lock.
A transponder chip for engine immobiliser
system has been filled in the head of the
master and sub keys. These chips are
needed to enable the system to function
correctly, so be careful not to lose these
keys. If you make your own duplicate key,
you will not be able to cancel the system
or start the engine. Since the side doors can be locked with-
out a key, you should always carry a
spare master key in case you accidentally
lock your keys inside the vehicle.
For information on use of the wireless
remote control key, see “Side doors” on
page 12 in this section.NOTICE
When using a key containing a trans-
ponder chip, observe the following
precautions:

When starting the engine, do not
use the key with a key ring resting
on the key grip and do not press
the key ring against the key grip.
Otherwise the engine may not start,
or may stop soon after it starts.
Keys

02_SEQUOIA_U (L/O 0108)
302002 MY SEQUOIA_U (OM34418U)
SETTING THE SYSTEM1. Turn the ignition key to the “LOCK” position and remove it.
The indicator light will start flashing when
the key is removed from the ignition
switch. (See “Engine immobiliser system”
on page 10 for details.)
2. Have all passengers get out of the vehicle.
3. Close and lock all the side doors, back door and hood.
The indicator light will come on when all
the side doors, back door and hood are
closed and locked. The system will automatically be set after
30 seconds. When the system is set, the
indicator light will start flashing again.
4. After making sure the indicator light starts flashing, you may leave the ve-
hicle.
Never leave anyone in the vehicle when
you set the system, because unlocking
from the inside will activate the system.
WHEN THE SYSTEM IS SET
Activating the system
The system will give the alarm under the
following conditions:If any of the side doors is unlocked or
opened without the key or wireless re-
mote control transmitter, or if the back
door or hood is forcibly opened
If the battery terminal is disconnected
and then reconnected
The indicator light will come on when the
system is activated. If the alarm has been activated and the
key is not in the ignition switch, all the
side doors and back door will relock au-
tomatically.
After one minute, the alarm will automati-
cally stop and the indicator light will starts
flashing again.
Reactivating the alarm
Once set, the system automatically resets
the alarm after the alarm stops.
The alarm will activate again under the
same circumstances described in
“Activating the system”.
Stopping the alarm
The alarm will be stopped by the following
two ways:
Turn the ignition key from the “LOCK”
to “ON” position.
Unlock any of the side doors or back
door with the key or wireless remote
control transmitter.
These ways cancel the system at the
same time.

02_SEQUOIA_U (L/O 0108)
11 22002 MY SEQUOIA_U (OM34418U)
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate,
side marker and instrument panel lights
Position 2—Headlights and all of the
aboveThe lights automatically turn off after 30
seconds when all the side doors and back
door are closed with the ignition key in
the “ACC” or “LOCK” position and the le-
ver at position 2.
The lights also automatically turn off when
the driver ’s door is opened with the lever
at position 1.
If the doors are locked by the wireless
remote control transmitter, the lights auto-
matically turn off immediately.
To turn them on again, turn the key to the
“ON” position or actuate the headlight
switch.
If you are going to park for over one
week, make sure the headlight switch is
off.
The timing for the headlights turning off
can be changed. For details, contact your
Toyota dealer.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light system (all mod-
els sold in Canada and some models
sold in the U.S.A.)
The headlights turn on at reduced intensi-
ty when the parking brake is released with
the engine started, even with the light
switch in the “OFF” position. They will not
go off until the ignition switch is turned
off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
to full intensity for driving at night.
Headlights and turn signals
(without automatic light
control system)

02_SEQUOIA_U (L/O 0108)
11 62002 MY SEQUOIA_U (OM34418U)
When all the doors are unlocked with
a key or wireless remote control trans-
mitter simultaneously, the lights come
on for about 15 seconds and then fade
out, even if the door is not opened.
The following adjustments can be made in
this system. For details, contact your
Toyota dealer.
Cancelling the door key or wireless re-
mote control operation
Changing the timing for the light turn-
ing off
To prevent the battery being discharged,
the lights will automatically turn off when
the key is removed and the door is left
opened with the switch at “DOOR” position
for 20 minutes or more.
CENTER PERSONAL LIGHTS
To turn on the center personal light,
push the switch. To turn the light off,
push the switch once again.
To turn on the luggage compartment
light, slide the switch.
The luggage compartment light switch has
the following positions:
“ON”—Keeps the light on all the time.
“OFF”—Turns the light off.
“DOOR”—Turns the light on when any of
the side doors or back door are opened.
The light goes off immediately when the
back door is closed. However, the light
remains on when all the side doors are
closed. ILLUMINATED ENTRY SYSTEM
With the switch in “DOOR” position, the
interior light, luggage compartment light,
ignition switch light and foot light come
the side doors are closed, the lights re-
main on for about 15 seconds and then
fades out.
However, in the following cases, the lights
go off immediately.
All the doors are closed when the igni-
tion key is in “ACC” or “ON” position.
The ignition key is turned to “ACC”,
“ON”, or “START” after all the side
doors are closed.
All the doors are closed and locked.
When all the doors are unlocked with a
key or wireless remote control transmitter
simultaneously, the lights come on for
about 15 seconds and then fade out, even
if the door is not opened.
The following adjustments can be made in
this system. For details, contact your
Toyota dealer.
Cancelling the door key or wireless re-
mote control transmitter linked opera-
tion
Changing the timing for the light turn-
ing off
Luggage compartment light

02_SEQUOIA_U (L/O 0108)
11 72002 MY SEQUOIA_U (OM34418U)
For easy access to the ignition switch,
the ignition switch light comes on when
any of the side doors are opened.
The light remains on for some time after
all the side doors are closed.
However, in the following cases, the lights
go off immediately.
All the doors are closed when the igni-
tion key is in “ACC” or “ON” position.
The ignition key is turned to “ACC”,
“ON”, or “START” after all the side
doors are closed.
All the doors are closed and locked.When all the doors are unlocked with a
key or wireless remote control transmitter
simultaneously, the ignition switch light
comes on for about 15 seconds and then
fade out, even if the door is not opened.
To prevent the battery being discharged,
the light will automatically turn off when
the key is removed and the door is left
opened for 20 minutes or more.
The following adjustments can be made in
this system. For details, contact your
Toyota dealer.
Cancelling the door key or wireless re-
mote control transmitter linked opera-
tion
Changing the timing for the light turn-
ing off
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the “ON” position.
Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
The “INT TIME” band lets you adjust the
wiping time interval when the wiper lever
is in the intermittent position (position 1).
Twist the band upward to increase the
time between sweeps, and downward to
decrease it.
Ignition switch light Windshield wipers and washer

02_SEQUOIA_U (L/O 0108)
2432002 MY SEQUOIA_U (OM34418U)
IN CASE OF AN EMERGENCY
If your vehicle will not start244
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your engine stalls while driving 247
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot increase the engine speed 247
. . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 248
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
If you have a flat tire 249
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
If your vehicle needs to be towed 257
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you lose your keys 261
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
If you lose your wireless remote control transmitter 261
. . . . . . . . . . . . .
SECTION 4

02_SEQUOIA_U (L/O 0108)
3142002 MY SEQUOIA_U (OM34418U)
21. DOME 10 A: Center interior and per-
sonal lights, personal lights, luggage
compartment light, air conditioning sys-
tem, wireless remote control system,
garage door opener, ignition switch
light, door courtesy lights, foot light,
vanity lights, power antenna
22. ECUB 7.5 A: Multiplex communication
system (power door lock system, secu-
rity system, autodoor locking system,
automatic light control system, head-
light delay off system, tail light auto
cut system, illuminated entry system,
daytime running light system), back
door lock system, driver and front pas-
senger door lock system, gauges and
meters
23. MIR HTR 15 A: Outside rear view mir-
ror heaters
24. RAD NO.1 20 A: Car audio system
25. TAIL 15 A: Tail lights, back door cour-
tesy light, license plate lights 26. ECUIG 7.5 A:
Charging system,
cruise control system, antilock brake
system, vehicle skid control system,
traction control system (twowheel
drive models), active traction control
system (fourw heel drive models), elec-
tronically controlled automatic transmis-
sion system, power antenna, electric
moon roof, back door lock system,
driver and front passenger door lock
system, g auges and meters, multiin-
formation display, SRS airbag system,
front seat belt pretensioners
27. WSH 25 A: Wipers and washer
28. IGN 2 20 A: Starting system
29. PWR NO.3 20 A: Rear passenger ’s
power window (right side)
30. PWR NO.4 20 A: Rear passenger ’s
power window (left side)
31. CIG 15 A: Air conditioning systems,
power rear view mirror control, ciga-
rette lighter 32. RAD NO.2 7.5 A:
Car audio system,
power antenna, power outlets, multiplex
communication system (power door
lock system, security system, auto
door locking system, automatic light
control system, headlight delay off sys-
tem, tail light auto cut system, illumi-
nated entry system, daytime running
light system)
33. 4WD 20 A: A.D.D. control system,
fourwheel drive system
34. STOP 15 A: Stop lights, highmounted
stop lights, multiport fuel injection sys-
tem/sequential multiport fuel injection
system, vehicle skid control system,
traction control system (twowheel
drive models), active traction control
system (fourw heel drive models), mul-
tiplex communication system (autodoor
locking system)
35. OBD 7.5 A: Onboard diagnosis sys-
tem

02_SEQUOIA_U (L/O 0108)
3232002 MY SEQUOIA_U (OM34418U)
Cooling systemCoolant level 285 . . . . . . . . . . . . . . . . . . . . . .
Engine overheating 248 . . . . . . . . . . . . . . . . .
Radiator and reservoir 285 . . . . . . . . . . . . . .
Radiator cap 248 . . . . . . . . . . . . . . . . . . . . . . .
Winter driving tips 232 . . . . . . . . . . . . . . . . . .
Corrosion prevention 264 . . . . . . . . . . . . . . . . .
Cruise control 148 . . . . . . . . . . . . . . . . . . . . . . .
Cup holders 205 . . . . . . . . . . . . . . . . . . . . . . . . .
D
Defogger
Back window 119 . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirror 119 . . . . . . . . . . . .
Dimmer switch, Headlight 110,112 . . . . . . . . .
Dinghy towing 233 . . . . . . . . . . . . . . . . . . . . . . .
Directional signals 110,112 . . . . . . . . . . . . . . .
Discharge warning light 125 . . . . . . . . . . . . . . .
Doityourself maintenance
Parts and tools 281 . . . . . . . . . . . . . . . . . . . . .
Service precautions 280 . . . . . . . . . . . . . . . .
Does your vehicle need repairing? 275 . . . . .
Doors
Side doors 12 . . . . . . . . . . . . . . . . . . . . . . . . .
Driver ’s seat belt reminder buzzer 125 . . . . . .
Driver ’s seat belt reminder light 125 . . . . . . . .
Driving
Automatic transmission 133 . . . . . . . . . . . . .
Driving tips 228 . . . . . . . . . . . . . . . . . . . . . . . .
Driving tips
Driving tips in various conditions 229 . . . . .
Driving with an automatic transmission 133 . . . . . . . .
Economical driving 240 . . . . . . . . . . . . . . . . . Good driving practice 133
. . . . . . . . . . . . . . .
Winter driving tips 232 . . . . . . . . . . . . . . . . . .
During
Breakin 213 . . . . . . . . . . . . . . . . . . . . . . . . . .
E
Economical driving
Saving money on both fuel and repairs 240 . . . . . . . . . . . . . . . . . . . . . .
Electric moon roof 32 . . . . . . . . . . . . . . . . . . . . .
Electrical system,
Battery 296,297 . . . . . . . . . . . . . . . . . . . . . . . .
Fuse locations 279 . . . . . . . . . . . . . . . . . . . . .
Fuses 298 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 113 . . . . . . . . . . . . .
Emergency, In case of8
Blown fuse 298 . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 113 . . . . . . . . . . .
Flat tire 249 . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot increase the engine speed 247 . . . . . . . . . . . . . . . . .
If you lose your keys 261 . . . . . . . . . . . . . . . .
If you lose your wireless remote control transmitter 261 . . . . . . . . . . . . . . . .
If your engine stalls while driving 247 . . . . .
If your vehicle needs to be towed 257 . . . . .
If your vehicle will not start 244 . . . . . . . . . .
Jump starting 245 . . . . . . . . . . . . . . . . . . . . . .
Overheating 248 . . . . . . . . . . . . . . . . . . . . . . .
Towing 257 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emissions Inspection and
Maintenance (I/M) programs 276 . . . . . . . . . Engine
Before starting the engine 228 . . . . . . . . . . .
Checking the coolant level 285 . . . . . . . . . .
Emission control device 216 . . . . . . . . . . . . .
Engine compartment 278 . . . . . . . . . . . . . . .
Exhaust gas caution 217 . . . . . . . . . . . . . . . .
Hood release 29 . . . . . . . . . . . . . . . . . . . . . . .
Oil consumption 217 . . . . . . . . . . . . . . . . . . . .
Oil level 284 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil pressure gauge 123 . . . . . . . . . . . . . . . . .
Overheating 248 . . . . . . . . . . . . . . . . . . . . . . .
Starting procedure 228 . . . . . . . . . . . . . . . . .
Threeway catalytic converter 216 . . . . . . .
Engine coolant
Temperature gauge 122 . . . . . . . . . . . . . . . . .
Winter driving tips 232 . . . . . . . . . . . . . . . . . .
Engine coolant temperature gauge 122 . . . . .
Engine immobiliser system 10 . . . . . . . . . . . . .
Engine oil
Winter driving tips 232 . . . . . . . . . . . . . . . . . .
Engine oil pressure gauge 123 . . . . . . . . . . . . .
Exhaust gas caution 217 . . . . . . . . . . . . . . . . . .
F
Facts about engine oil consumption 217 . . . .
Flasher, Headlight 110,112 . . . . . . . . . . . . . . . .
Flat tire
After changing wheels 256 . . . . . . . . . . . . . .
Changing tire 254 . . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 249 . . . . . . . . . . . . . . . .
Jack point 252 . . . . . . . . . . . . . . . . . . . . . . . . .
Jacking precautions 249 . . . . . . . . . . . . . . . .
Jacking up 253 . . . . . . . . . . . . . . . . . . . . . . . .
