2002 TOYOTA RAV4 fuel consumption

’02 Rav4_U (L/O 0108)
1032002 MY RAV4_U (OM42503U)
Do not race the engine and avoid
spinning the wheels.
 If your vehicle remains stuck after
rocking the vehicle several times,
consider other ways such as tow-
ing.
(j) If you cannot shift the selector le-
ver out of “P” position
If you cannot shift the selector lever from
the “P” position even though the brake
pedal is depressed, use the shift lock
override button. For instructions, see “If
you cannot shift automatic transmission
selector lever” on page 202 in Section 4.
The shift pattern is as shown above.
Press the clutch pedal down fully while
shifting, and then release it slowly. Do not
rest your foot on the pedal while driving,
because it will cause clutch trouble. And
do not use the clutch to hold the vehicle
when stopped on an uphill grade–use the
parking brake.
Recommended shifting speeds
The transmission is fully synchronized and
upshifting or downshifting is easy.
For the best compromise between fuel
economy and vehicle performance, you
should upshift or downshift at the following
speeds: gear km/h (mph)
1 to 2 or 2 to 1 24 (15)
2 to 3 or 3 to 2 40 (25)
3 to 4 or 4 to 3 64 (40)
4 to 5 or 5 to 4 72 (45)
Downshift to the appropriate gear if accel-
eration is needed when you are cruising
below the above downshifting speeds.
Upshifting too soon or downshifting too
late will cause lugging and, possibly, ping-
ing. Regularly revving the engine to maxi-
mum speed in each gear will cause ex-
cessive engine wear and high fuel
consumption.
Maximum allowable speeds
To get on a highway or to pass slower
traffic, maximum acceleration may be nec-
essary. Make sure you observe the follow-
ing maximum allowable speeds in each
gear: Twowheel drive models
gear km/h (mph)1 50 (31)
2 94 (58)
3 144 (89)
4 187 (116)
Manual transmission

’02 Rav4_U (L/O 0108)
1532002 MY RAV4_U (OM42503U)
INFORMATION BEFORE DRIVING YOUR
TOYOTA
Offroad vehicle precautions154
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Breakin period 155
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Fuel 155
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Fuel pump shut off system 157
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation in foreign countries 157
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Threeway catalytic converter 158
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust cautions 159
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Facts about engine oil consumption 159
. . . . . . . . . . . . . . . . . . . . . . . . . .
Iridiumtipped spark plugs 160
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system 161
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Brake pad wear limit indicators 164
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage stowage precautions 164
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Limitedslip differential 165
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Your Toyota’s identification 165
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft prevention labels 167
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Suspension and chassis 167
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Types of tires 167
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
SECTION 2

’02 Rav4_U (L/O 0108)
1762002 MY RAV4_U (OM42503U)
NOTICE
Do not tow your vehicle from the
rear. This may cause serious damage
to your vehicle.
Your vehicle is designed primarily as a
passengercarrying vehicle. Towing a
trailer will have an adverse effect on
handling, performance, braking, durability
and driving economy (fuel consumption,
etc.). Your safety and satisfaction depend
on the proper use of correct equipment
and cautious driving habits. For your
safety and the safety of others, you must
not overload your vehicle or trailer. Toyota
warranties do not apply to damage or
malfunction caused by towing a trailer for
commercial purposes. Ask your local
Toyota dealer for further details before
towing.
WEIGHT LIMITS
Before towing, make sure the total trail-
er weight, gross combination weight,
gross vehicle weight, gross axle weight
and trailer tongue load are all within
the limits.
The total trailer weight and tongue load
can be measured with platform scales
found at a highway weighing station, build-
ing supply company, trucking company,
junk yard, etc.CAUTION
The total trailer weight (trailer
weight plus its cargo load) must
not exceed 680 kg (1500 lb.).
The gross combination weight (sum
of your vehicle weight plus its load
and the total trailer weight) must
not exceed the following.
Twowheel drive models2468 kg (5441 lb.)
Fourwheel drive models 2489 kg (5487 lb.)
Trailer towing

’02 Rav4_U (L/O 0108)
1812002 MY RAV4_U (OM42503U)
Slow down and downshift before
descending steep or long downhill
grades. Do not make sudden down-
shifts.
Avoid holding the brake pedal down
too long or too frequently. This
could cause the brakes to overheat
and result in reduced braking effi-
ciency.
Improving fuel economy is easy—just take
it easy. It will help make your vehicle last
longer, too. Here are some specific tips
on how to save money on both fuel and
repairs:
Keep your tires inflated at the cor-
rect pressure. Underinflation causes
tire wear and wastes fuel. See page
231 in Section 72 for instructions.
Do not carry unneeded weight in
your vehicle. Excess weight puts a
heavier load on the engine, causing
greater fuel consumption.
Avoid lengthy warmup idling. Once
the engine is running smoothly, begin
driving—but gently. Remember, howev-
er, that on cold winter days this may
take a little longer.
Keep the automatic transmission
overdrive turned on when engine
braking is not required. Driving with
the overdrive off will reduce the fuel
economy. (For details, see “Automatic
transmission” on page 99 in Section
16.)
Accelerate slowly and smoothly.
Avoid jackrabbit starts. Get into high
gear as quickly as possible.
Avoid long engine idling. If you have
a long wait and you are not in traffic,
it is better to turn off the engine and
start again later.
Avoid engine lugging or overrev-
ving. Use a gear position suitable for
the road on which you are travelling.
Avoid continuous speeding up and
slowing down. Stopandgo driving
wastes fuel.
Avoid unnecessary stopping and
braking. Maintain a steady pace. Try
to time the traffic signals so you only
need to stop as little as possible or
take advantage of through streets to
avoid traffic lights. Keep a proper dis-
tance from other vehicles to avoid sud-
den braking. This will also reduce wear
on your brakes.
Avoid heavy traffic or traffic jams
whenever possible.
Do not rest your foot on the clutch
or brake pedal. This causes premature
wear, overheating and poor fuel econo-
my.
Maintain a moderate speed on high-
ways. The faster you drive, the greater
the fuel consumption. By reducing your
speed, you will cut down on fuel con-
sumption.
How to save fuel and make
your vehicle last longer

’02 Rav4_U (L/O 0108)
2672002 MY RAV4_U (OM42503U)
Discharge warning light90
. . . . . . . . . . . . . . . .
Doityourself maintenance
Parts and tools 221
. . . . . . . . . . . . . . . . . . . . .
Service precautions 219
. . . . . . . . . . . . . . . .
Does your vehicle need repairing? 215 . . . . .
Doors
Side doors 12
. . . . . . . . . . . . . . . . . . . . . . . . .
Driver ’s seat belt reminder buzzer 90 . . . . . . .
Driver ’s seat belt reminder light 90
. . . . . . . . .
Driving
Automatic transmission 99
. . . . . . . . . . . . . .
Driving tips 170
. . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission 103
. . . . . . . . . . . . . . .
Driving tips
Driving tips in various conditions 171 . . . . .
Driving with a manual transmission 103
. . . . . . . . . . . .
Driving with an automatic transmission 99
. . . . . . . . .
Economical driving 181
. . . . . . . . . . . . . . . . .
Good driving practice 99,103
. . . . . . . . . . . .
Winter driving tips 173
. . . . . . . . . . . . . . . . . .
During
Breakin 155
. . . . . . . . . . . . . . . . . . . . . . . . . .
E
Economical driving
Saving money on both fuel and repairs 181 . . . . . . . . . . . . . . . . . .
Electric moon roof 25 . . . . . . . . . . . . . . . . . . . . . Electrical system
Battery 240,241 . . . . . . . . . . . . . . . . . . . . . . . .
Fuse locations 219 . . . . . . . . . . . . . . . . . . . . .
Fuses 242 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 81 . . . . . . . . . . . . . .
Emergency, In case of
Blown fuse 242 . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 81 . . . . . . . . . . . .
Flat tire 189 . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot shift automatic transmission selector lever 202 . . . . . . . .
If you lose your keys 203 . . . . . . . . . . . . . . . .
If you lose your wireless remote control transmitter 203 . . . . . . . . . . . . . . . .
If your engine stalls while driving 188 . . . . .
If your vehicle needs to be towed 198 . . . . .
If your vehicle will not start 184 . . . . . . . . . .
Jump starting 185 . . . . . . . . . . . . . . . . . . . . . .
Overheating 188 . . . . . . . . . . . . . . . . . . . . . . .
Towing 198 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emissions Inspection and Maintenance (I/M) programs 216 . . . . . . . . .
Engine
Air cleaner 230 . . . . . . . . . . . . . . . . . . . . . . . .
Before starting the engine 170 . . . . . . . . . . .
Checking the coolant level 227 . . . . . . . . . .
Emission control device 158 . . . . . . . . . . . . .
Engine compartment 218 . . . . . . . . . . . . . . .
Exhaust gas caution 159 . . . . . . . . . . . . . . . .
Hood release 22 . . . . . . . . . . . . . . . . . . . . . . .
Oil consumption 159 . . . . . . . . . . . . . . . . . . . .
Oil level 226 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 188 . . . . . . . . . . . . . . . . . . . . . . . Starting procedure 170
. . . . . . . . . . . . . . . . .
Threeway catalytic converter 158 . . . . . . .
Engine coolant
Temperature gauge 88 . . . . . . . . . . . . . . . . . .
Winter driving tips 173 . . . . . . . . . . . . . . . . . .
Engine coolant temperature gauge 88 . . . . . .
Engine immobiliser system 11 . . . . . . . . . . . . .
Engine oil
Winter driving tips 173 . . . . . . . . . . . . . . . . . .
Exhaust gas caution 159 . . . . . . . . . . . . . . . . . .
F
Facts about engine oil consumption 159 . . . .
Flasher, Headlight 80 . . . . . . . . . . . . . . . . . . . . .
Flat tire
After changing wheels 197 . . . . . . . . . . . . . .
Changing tire 194 . . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 189 . . . . . . . . . . . . . . . .
Jack point 193 . . . . . . . . . . . . . . . . . . . . . . . . .
Jacking precautions 189 . . . . . . . . . . . . . . . .
Jacking up 193 . . . . . . . . . . . . . . . . . . . . . . . .
Loosening wheel nuts 193 . . . . . . . . . . . . . . .
Lowering vehicle 195 . . . . . . . . . . . . . . . . . . .
Stowing flat tire 196 . . . . . . . . . . . . . . . . . . . .
Wheel block 192 . . . . . . . . . . . . . . . . . . . . . . .
Wheel nuts 195 . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat 151 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid level
Brake 229 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power steering 229 . . . . . . . . . . . . . . . . . . . . .
Washer fluid 243 . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch, Front 82 . . . . . . . . . . . . . . . . .
Foreign countries, Operation in 157 . . . . . . . .
