Clean all dirt from outside of the reservoir
tank and look at the fluid level. If the fluid
is cold, the level should be in the “COLD”
range. Similarly, if it is hot, the fluid level
should be in the “HOT” range. If the level
is at the low side of either range, add
automatic transmission fluid DEXRON
II or III to bring the level within the range.
To remove the reservoir cap, turn it coun-
terclockwise and lift up. To reinstall it,
turn it clockwise. After replacing the reser-
voir cap, visually check the steering box
case, vane pump and hose connections
for leaks or damage.
CAUTION
The reservoir tank may be hot so be
careful not to burn yourself.
NOTICE
Avoid overfilling, or the power steer-
ing could be damaged.
Keep your tire pressures at the proper
level.
The recommended cold tire pressures, tire
size and the vehicle capacity weight are
given in Section 8. They are also on the
tire pressure label as shown.
You should check the tire pressures every
two weeks, or at least once a month. And
don’t forget the spare!
Incorrect tire pressure can reduce tire
life and make your vehicle less safe to
drive. Low tire pressure results in excessive
wear, poor handling, reduced fuel econo-
my, and the possibility of blowouts from
overheated tires. Also, low tire pressure
can cause poor sealing of the tire bead.
If the tire pressure is excessively low,
there is the possibility of w
heel deforma-
tion and/or tire separation.
High tire pressure produces a harsh ride,
handling problems,excessive wear at the
center of the tire tread, and a greater
possibility of tire damage from road haz-
ards.
If a tire frequently needs ref illing, have it
checked by your Toyota dealer.
The following instructions for checking
tire pressure should be observed:
The pressure should be checked only
when the tires are cold. If your ve-
hicle has been parked for at least 3
hours and has not been driven for
more than 1.5 km or 1 mile since, you
will get an accurate cold tire pressure
reading.
Always use a tire pressure gauge.
The appearance of a tire can be mis-
leading. Besides, tire pressures that
are even just a few pounds off can
degrade ride and handling.
Checking tire pressure

’02 Corolla U (L/O 0105)
2322002 Corolla_U (OM12743U)
3. Turn the bulb base counterclockwiseto the front of the vehicle as shown.4. Pull the bulb out of the bulb base.Install a new bulb.5. Install the bulb base by turning itclockwise to the front of the vehicle.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer.

’02 Corolla U (L/O 0105)
2332002 Corolla_U (OM12743U)
1. Loosen the retainer nut and take outthe beam unit.2. Turn the cover counterclockwise andremove it.3. Disconnect the cords.
—Front fog lights

’02 Corolla U (L/O 0105)
2342002 Corolla_U (OM12743U)
4. Release the bulb retaining springand remove the bulb. Install a new
bulb and the bulb retaining spring.
To install the bulb, align the cutouts of the
bulb with the protrusions of the mounting
hole.5. Connect the cords and install the cover by turning it clockwise.
6. Install the fog light and tighten the nut.Use a Phillipshead screwdriver.
—Parking/front side
marker/front turn signal lights

’02 Corolla U (L/O 0105)
2452002 Corolla_U (OM12743U)
Tire size:Compact spare tireT115/70D14
T125/70D14
Except compact spare tire P175/65SR14
P185/65SR14
Tire pressure, kPa (kgf/cm
2 or bar, psi):
Compact spare tire 420 (4.2, 60)
Except compact spare tire 210 (2.1, 30)
Wheel size:
Compact spare tire14 4T
Except compact Spare tire 14 5 1/2JJ
Wheel nut torque, N·m (kgf·m, ft·lbf): 102.9 (10.5, 76)
NOTE: For a complete information on tires (e.g. replacing tires or re-
placing wheels), see “Checking
tire pressure” through “Aluminum
wheel precautions” in Section 72.
Engine compartment
Fuses (type A)
1. A/C 7.5 A: Air conditioning system,
electric cooling fans
2. SPARE 5 A: Spare fuse
3. SPARE 10 A: Spare fuse
4. SPARE 15 A: Spare fuse
5. DOME 15 A: Car audio system, interior
light, personal light, trunk light, clock,
daytime running light system
6. HAZARD 10 A: Turn signal lights,
emergency flashers
Engine compartment
7. AM2 15 A: Starter system, “ST” and
“IGN” fuses
8. HEAD (LH) or HEAD (LHUPR) 15 A: Lefthand headlight (high beam)
9. ALTS 5 A: Charging system
10. HEAD (RH) or HEAD (RHUPR) 15 A: Righthand headlight (high beam)
11. EFI or FHTR 15 A: Multiport fuel in-
jection system/sequential multiport fuel
injection system
12. HORN 10 A: Horn
Tires Fuses

’02 Corolla U (L/O 0105)
2462002 Corolla_U (OM12743U)
Engine compartment
13. DRL 7.5 A: Daytime running light sys-
tem
14. HEAD RHLWR 10 A: Righthand
headlight (low beam)
15. HEAD LHLWR 10 A: Lefthand head-
light (low beam)
16. CDS 30 A: Electric cooling fans
17. TURN 7.5 A: Turn signal lights, emer-
gency flashers
18. GAUGE 10 A: Gauge and meters,
buckup lights, air conditioning system,
power windows, rear window defogger,
power door lock system
Instrument panel
19. WIP 20 A: Windshield wipers and
washer
20. DEF IUP/MHTR 10 A: Rear window
defogger, multiport fuel injection sys-
tem/sequential multiport fuel injection
system
21. ECUIG 10 A: Starting system, electric
cooling fan, automatic transmission
shift lock system, antilock brake sys-
tem, cruise control system
22. IGN 7.5 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, charging system, SRS airbag
system, seat belt pretensi oners23. STOP 15 A:
Stop lights, high mounted
stoplight, antilock brake system, auto-
matic transmission shift lock system,
cruise control system, multiport fuel in-
jection system/sequential multiport fuel
injection system
24. TAIL 15 A: Tail lights, gauges and me-
ters, instrument panel light control, cig-
arette lighter, clock, car audio system,
rear window defogger, license plate
lights, electronically controlled automat-
ic transmission system, multiport fuel
injection system/sequential multiport
fuel injection system, air conditioning
system, emer gency flashers
25. OBD 7.5 A: Onboard diagnosis sys-
tem
26. ECUB 7.5 A: SRS airbag system,
seat belt pretensioners
27. ST 5 A: Starter system, multiport fuel
injection system/sequential multiport
fuel injection system
28. D/L 30 A: Power door lock system
29. FOG 15 A: Front fog lights
30. SHTR 15 A: No circuit

’02 Corolla U (L/O 0105)
2472002 Corolla_U (OM12743U)
31. CIG 15 A: Car audio system, clock,
cigarette lighter, power rear view mir-
rors, SRS airbag system, seat belt pre-
tensioners, automatic transmission shift
lock system
Fuses (type B)
32. HTR 50 A: Air conditioning system,
“A/C” fuse
33. MAIN 40 A: Starter system, “HEAD
(LH) or HEAD (LHUPR)”, “HEAD (RH)
or HEAD (RHUPR)”, “HEAD LHLWR”,
“HEAD RHLWR” and “DRL” fuses
34. RDI 30 A: Electric cooling fans
35. AM1 50 A: “CIG”, “TURN”, “GAUGE”,
“ECUIG” and “WIP” fuses
36. DEF 40 A: Rear window defogger,
“DEF IUP/MHTR” fuse
37. POWER 30 A: Power windows, electric
moon roof
Fuses (type C)
38. FL ABS 50 A: Antilock brake system
39. FL ALT 100 A: “RDI”, “CDS”, “AM1”,
“POWER”, “D/L”, “TAIL”, “OBD”, “FOG”,
“ECUB”, “STOP”, “DEF” and “HTR”
fuses
