2002 SUBARU IMPREZA WRX horn

16
Instrument panel
HGF032BB
1) Door locks (page 2-3)
2) Light control lever (page 3-15)
3) Combination meter (page 3-6)
4) Wiper control lever (page 3-20)
5) Hazard warning flasher switch
(page 3-5)
6) Audio (page 5-1)
7) Gear shift lever (MT) (page
7-10)/Selector lever (AT) (page7-13)
8) Outside mirror switch (page 3-28)
9) Climate control (page 4-1)
10) Cruise control (page 7-27)
11) Horn (page 3-31)
12) SRS airbag (page 1-38)
13) Tilt steering (page 3-30)
14) Fuse box (page 11-51)
15) Hood lock release (page 11-5)
16) Power window (page 2-20)

Keys and doors
2-7
– CONTINUED –
HB1000BC
A: LOCK/ARM button
Press to Lock all doors. Press and Hold to activate panic alarm.
B: UNLOCK/DISARM button
B1) Press once to Unlock driver ’s
door.
B2) Press a second time to Unlock all doors.
C: LED
Locking the doors
Briefly press the “LOCK/ARM” button (for less than
two seconds) to lock all doors (and rear gate on the
wagon). The horn will sound one time.
If any of the doors (or the rear gate) is not fully
closed, the horn will sound three times to alert you that the doors (or the rear gate) are not properly
closed. When you close the door, it will automaticallylock.
Unlocking the doors
Briefly press the “UNLOCK/DISARM” button (for less
than two seconds) to unlock the driver ’s door. The
horn will sound two times. To unlock all doors (and
rear gate on the wagon), briefly press the
“UNLOCK/DISARM” button a second time within 5
seconds.
Illuminated entry
The interior (dome) light will illuminate when the
“UNLOCK/DISARM” button is pressed. The light will
illuminate for approximately 30 seconds or until the
“LOCK/ARM” button is pressed. Once any of the
doors (or the rear gate on the wagon) is opened, this function will be canceled. The interior light mustbe set to the middle position in order for this func-
tion to operate. Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button
pressed for more than two seconds .
To deactivate it, press the “LOCK/ARM” button or

Keys and doors
2-8
“UNLOCK/DISARM” button. Unless a button on the
remote is pressed, the alarm will be deactivated
after approximately 30 seconds. Selecting audible signal operation
Using the horn, the system will give you an audible
signal when the doors lock and unlock. If desired,
you may turn the audible signal off.
To turn the audible signal off, unlock the door by
pressing the “UNLOCK/DISARM” button and then
simultaneously depress “LOCK/ARM” and
“UNLOCK/DISARM” buttons for more than two se-
conds. The horn will sound two times to inform you
that the audible signal has been turned off.
To turn the audible signal on, unlock the door by
pressing the “UNLOCK/DISARM” button and then
simultaneously depress “LOCK/ARM” and
“UNLOCK/DISARM” buttons for more than two se-
conds. The horn will sound one time to inform you
that the audible signal has been turned on.
Replacing the battery
When the transmitter battery begins to get weak,
transmitter range will begin to decrease and the
LED will not illuminate. Replace the battery as soonas possible. To replace the battery:
HB1001BA
1. Remove the two screws on the back of the trans-
mitter case by using a phillips screwdriver.
2. Separate the case.
3. Remove the old battery from the holder.

Keys and doors
2-11
– CONTINUED –
4. Place the ignition key into the ignition switch and
cycle the switch from LOCK to ON ten times within
15 seconds . Be sure to stop at the LOCK position.
The horn will sound once to indicate that you are in
the transmitter programming mode. NOTE
You must finish the next step (opening the driv-
er’ s door) within 45 seconds of starting this pro-
cedures.
To program the transmitters:
HB1005BB
1. Open the driver ’s door.
2. Close the driver ’s door.
HB1000DC
1) Press any button.
3. Press and release any button on the transmitter
that you wish to program into the system. The horn will sound two times to indicate that the transmitter
has been programmed.
Any additional transmitters can also be programmed
at this time. Repeat steps 1 through 3 for an addi-
tional transmitter.
To exit the programming mode:
1. After all of your transmitters are programmed, re-
move the key from the ignition switch.
The horn will sound three times to indicate that the
system has exited the programming mode.
2. Make sure that the keyless entry system properly

Keys and doors
2-12
operates by operating each transmitter. Deleting old transmitter codes
The control unit of the keyless entry system has four
memory locations to store transmitter codes, givingit the ability to operate with up to four transmitters.
When you lose a transmitter, the lost transmitter ’s
code remains in the memory. For security reasons,
lost transmitter codes should be deleted from the
memory.
To delete old transmitter codes, program four trans-
mitter codes into the system. If you have only one
current transmitter, program it four times. If you have
two current transmitters, program each one twice. If
you have three current transmitters, program two of
them once and the third one twice. This process will
leave only current transmitter codes in the system ’s
memory. NOTE
Make sure no one else is operating their keyless entry system within range of your vehicle whenprogramming transmitters. If someone else wereto operate their remote transmitter while you are programming your transmitters, it is possible that their transmitter code will be programmedinto your system, allowing them unauthorized
access to your vehicle. Security system (if equipped)
The security system helps to protect your vehicle
and valuables from theft. The horn sounds and the
parking lights flash if someone attempts to break
into your vehicle. The starter motor is also inter-
rupted to prevent starting the vehicle without a key.
The system can be armed and disarmed with the
remote transmitter.The system does not operate when the key is in-
serted into the ignition switch.
System operation
The security system will give the following alarm in-
dications when triggered: The parking lights will flash and the horn will
sound intermittently. In addition, the starter motor willnot operate. The alarm automatically resets after 30 seconds;
however, the alarm will reactivate if the vehicle is
tampered with again. The alarm will continue for sixtimes if any sensor continues to be activated.
The alarm is triggered by: Opening a door, the rear gate or trunk lid.
Application of physical shock to the vehicle (e.g.

Keys and doors
2-13
– CONTINUED –
breaking glass or forced entry). Note that there are
two alarm levels for shock: warning and alarm. In
warning mode, the alarm detects lower level vibra-
tions and triggers 2 warning chirps on the horn and
two flashes on the lights as a deterrent to would be
vandals. In alarm mode, higher levels of shock are
detected and the system will go into full alarm. Ignition switch being turned on while in armed
state. Arming the system
To arm the system using remote transmitter
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk
lid) are locked.
5. Close all doors (and the rear gate on the wagon).
HB1000EC
1) Press to Arm the system.
2) Press to Disarm the system.
HG2017BA
Security system indicator light

Keys and doors
2-14
6. Briefly press the “LOCK/ARM” button (for less
than two seconds). All doors (and the rear gate on
the wagon) will lock, the horn will sound one time,the parking lights will flash one time and the indica-
tor light starts flashing slowly (approximately once
every two seconds).
If any of the doors (or the rear gate) is not fully
closed, the horn sounds three times, the parking
lights flash three times and the indicator light flashes
rapidly to alert you that the doors (or the rear gate)
are not properly closed. When you close the door,
the system will automatically arm and doors will au-
tomatically lock.
To arm the system using power door lockingswitches
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk
lid) are locked.
5. Close the doors (and the rear gate on the wagon)but leave only the driver ’s door or the front passen-
ger’ s door open.
HB2024FB
6. Push the front side ( “LOCK” side) of the power
door locking switch to set the door locks.
7. Close the door. The horn will sound one time, the
parking lights will flash one time and the indicator
light will start flashing slowly (approximately once
every two seconds) to inform you that the system
has armed.
NOTE The system can be armed even if the engine
hood, the windows and/or moonroofs areopened. Always make sure that they are fully
closed before arming the system.

Keys and doors
2-15
– CONTINUED –
Disarming the system
Briefly press the “UNLOCK/DISARM” button (for less
than two seconds) on the remote transmitter. The
driver’ s door will unlock, the horn will sound two
times, the parking lights will flash two times and the
indicator light will go off.
To unlock all doors (and the rear gate on the
wagon), briefly press the “UNLOCK/DISARM” button
a second time.
Emergency disarming
If you cannot disarm the system using the transmit-
ter (i.e. the transmitter is lost, broken or the transmit-
ter battery is too weak), you can disarm the system
without using the transmitter.
To disarm the system:
1. Unlock the door with the key and then open the
door.
2. The alarm will sound.
3. Insert the key into the ignition switch and cycle it
from the “LOCK” to the “ON” position three (3) times
within 5 seconds .
Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button
pressed for more than two seconds .To deactivate it, press the
“LOCK/ARM” button or
“UNLOCK/DISARM” button.
The parking lights will also flash when the alarm is activated.
Unless a button on the remote is pressed, the alarm
will be deactivated after approximately 30 seconds. Valet mode
When you choose the valet mode, the security sys-
tem does not operate. In valet mode, the remotetransmitter is used only for locking and unlocking
the doors (and rear gate on the wagon) and panicactivation.
To enter the valet mode, open the driver ’s door and
keep the “UNLOCK/DISARM” button depressed for
more than two seconds . The indicator light repeat-
edly flashes two times while the system is in valet mode.
To exit valet mode, open the driver ’s door and keep
the “UNLOCK/DISARM” button pressed for more
than two seconds. The indicator will stop flashing.
Passive arming
When passive arming mode has been programmed
by the dealer, arming of the system is automatically
accomplished without using the remote transmitter.
