Driving tips
8-26
HB8022BA
8. Connect the hitch wire harness’s black four –pin
wire connector to the towing trailer ’s wire harness
HB8021BA
Hitch harness connector 9. Confirm proper function of the hitch wire harness
by individually activating the brake, right turn signal,
left turn signal, stop, and parking lights on the trailer. NOTE Always disconnect the trailer wire harness be- fore launching or retrieving a watercraft.
When you do not tow a trailer
Remove the ball mount from the hitch receiver
tube and insert the receiver cover onto the hitch re- ceiver tube. Place the dust cap over the four –pin connector of
the hitch wire harness to protect against possibledamage. Occasionally lubricate terminals of the four –pin
connector using the terminal grease.

Driving tips
8-34
Side mirrors
HB0085
After hitching a trailer to your vehicle, check that the
standard side mirrors provide a good rearward field of view without significant blind spots. If significant blind spots occur with the vehicle ’s standard side
mirrors, use towing mirrors that conform with Fed-
eral, state/province and/or other applicable regula-tions.
Trailer lights
Connection of trailer lights to your vehicle ’s electrical
system requires modifications to the vehicle ’s light-
ing circuit to increase its capacity and accommo-
date wiring changes. To ensure the trailer lights are
connected properly, please consult your SUBARU dealer. Check for proper operation of the turn sig-nals, the brake lights and parking lights each timeyou hitch up.
CAUTION
Direct splicing or other improper connection
of trailer lights may damage your vehicle
’s
electrical system and cause a malfunction of your vehicle ’s lighting system.
Tires
Make sure that all the tires on your vehicle are prop-
erly inflated to the pressure specified on the tire
placard located on the left center pillar of your ve-hicle.
Trailer tire condition, size, load rating and proper
inflation pressure should be in accordance with the
trailer manufacturer ’s specifications.
In the event your vehicle gets a flat tire when towing
a trailer, ask a commercial road service to repair the
flat tire.
If you carry a regular size spare tire in your vehicle
or trailer as a precaution against getting a flat tire,
be sure that the spare tire is firmly secured.

Driving tips
8-35
– CONTINUED –
WARNING
Never tow a trailer when the temporary spare tire is used. The temporary spare tire is not
designed to sustain the towing load. Use ofthe temporary spare tire when towing can result in failure of the spare tire and/or less
stability of the vehicle.
Trailer towing tips
CAUTION
Never exceed 45 mph (72 km/h) when tow-
ing a trailer in hilly country on hot days. When towing a trailer, steering, stability,
stopping distance and braking performancewill be different from normal operation. For
safety’ s sake, you should employ extra cau-
tion when towing a trailer and you should
never speed. You should also keep the follow-ing tips in mind:
Before starting out on a trip
Check that the vehicle and vehicle-to-hitch mount-
ing are in good condition. If any problems are apparent, do not tow the trailer.
Check that the vehicle sits horizontally with the
trailer attached. If the vehicle is tipped sharply up at
the front and down at the rear, check the total trailer
weight, GVW, GAWs and tongue load again, then
confirm that the load and its distribution are accept- able. Check that the tire pressures are correct.
Check that the vehicle and trailer are connected
properly. Confirm that. –the trailer tongue is connected properly to the
hitch ball. – the trailer lights connector is connected prop-
erly and trailer ’s brake lights illuminate when the
vehicle’ s brake pedal is pressed, and that the trail-
er’ s turn signal lights flash when the vehicle ’s turn
signal lever is operated. – the safety chains are connected properly.
– all cargo in the trailer is secured safety in posi-
tion.– the side mirrors provide a good rearward field of
view without a significant blind spot.
Sufficient time should be taken to learn the “feel”
of the vehicle/trailer combination before starting out
on a trip. In an area free of traffic, practice turning, stopping and backing up.

Driving tips
8-37
– CONTINUED –
sudden downshifts. When driving uphill in hot weather, the air condi-
tioner may turn off automatically to protect the
engine from overheating. When driving uphill in hot weather, pay attention to
the water temperature gauge pointer (for all
vehicles) and AT OIL TEMP warning light (for AT
vehicles) since the engine and transmission are rel-
atively prone to overheating under these conditions.
If the water temperature gauge pointer approaches
the OVERHEAT zone or the AT OIL TEMP warning
light illuminates, immediately switch off the air condi-
tioner and stop the vehicle at the nearest safe place. Refer to the “Engine overheat ” section in chapter 9,
and “Warning and indicator lights ” section in chap-
ter 3. If your vehicle has a automatic transmission, avoid
using the accelerator pedal to stay stationary on an
uphill slope instead of using the parking brake or
foot brake. That may cause the transmission fluid to
overheat. Also, if your vehicle is equipped with an
automatic transmission, avoid driving with the gearselector lever in “D” when towing a heavy trailer to
prevent fluid overheating.
Parking on a grade
Always block the wheels under both vehicle and
trailer when parking. Apply the parking brake firmly. You should not park on a hill or slope. But if parkingon a hill or slope cannot be avoided, you shouldtake the following steps:
1. Apply the brakes and hold the pedal down.
2. Have someone place wheel blocks under boththe vehicle and trailer wheels.
3. When the wheel blocks are in place, release the
regular brakes slowly until the blocks absorb theload.
4. Apply the regular brakes and then apply the
parking brake; slowly release the regular brakes.
5. Shift into 1st or reverse gear (manual transmis- sion) or
“P” (automatic transmission) and shut off the
engine.

In case of emergency
9-12
Jump starting
WARNING
Battery fluid is SULFURIC ACID. Do not let it
come in contact with the eyes, skin, clothing or the vehicle. If battery fluid gets on you, thoroughly flush
the exposed area with water immediately. Get
medical help if the fluid has entered your
eyes.
If battery fluid is accidentally swallowed, im-
mediately drink a large amount of milk or wa-
ter, and obtain immediate medical help. Keep everyone including children away from
the battery. The gas generated by a battery explodes if a
flame or spark is brought near it. Do not
smoke or light a match while jump starting. Never attempt jump starting if the dis-
charged battery is frozen. It could cause thebattery to burst or explode. Whenever working on or around a battery,
always wear suitable eye protectors, and re- move metal objects such as rings, bands or
other metal jewelry.
Be sure the jumper cables and clamps on
them do not have loose or missing insulation.
Do not jump start unless cables in suitablecondition are available. A running engine can be dangerous. Keep
your fingers, hands, clothing, hair and tools away from the cooling fan, belts and any other
moving engine parts. Removing rings,watches and ties is advisable.
When your vehicle does not start due to a run down
(discharged) battery, the vehicle may be jump
started by connecting your battery to another bat-
tery (called the booster battery) with jumper cables.
Jump starting is dangerous if it done incorrectly. If
you are unsure about the proper procedure for jump
starting, consult a competent mechanic. How to jump start
1. Make sure the booster battery is 12 volts and the
negative terminal is grounded.
2. If the booster battery is in another vehicle, do notlet the two vehicles touch.
3. Turn off all unnecessary lights and accessories.
4. Connect the jumper cables exactly in the se-
quence illustrated.

Maintenance and service
11-2
Wheel balance 11-41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wear indicators 11-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire rotation 11-42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire replacement 11-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel replacement 11-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel covers 11-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheels (If equipped) 11-45 . . . . . . . . . . . . . . . .
Windshield washer fluid 11-46 . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement of windshield wiper blades 11-47 . .
Battery 11-50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 11-51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main fuse 11-53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of accessories 11-54 . . . . . . . . . . . . . . . . . . . . . . .
Replacing bulbs 11-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight 11-56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front turn signal light and parking light 11-58 . . . . . .
Front fog light (if equipped) 11-61 . . . . . . . . . . . . . . . . . . . . .
Front side marker light 11-62 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear combination lights 11-63 . . . . . . . . . . . . . . . . . . . . . . . . . .
License plate light 11-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Room light, spot light and cargo area light 11-66 . . .
Trunk light 11-67
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High mount stop light 11-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maintenance and service
11-52
HB8003CA
The other one is housed in the engine compartment.
HS0208
1) Fuse puller 2) Spare fuse
The fuse puller and spare fuses are stored in the main fuse box cover in the engine compartment.
If any lights, accessories or other electrical controls
do not operate, inspect the corresponding fuse. If a
fuse has blown, replace it.
HS0204
A) Good B) Blown
1. Turn the ignition switch to the “LOCK” position
and turn off all electrical accessories.
2. Remove the cover.
3. Determine which fuse may be blown. The backside of each fuse box cover and the “Fuse and cir-
cuits” section in chapter 12 in this manual show the
circuit for each fuse.

Maintenance and service
11-54
Installation of accessories
Always consult your SUBARU dealer before instal- ling fog lights or any other electrical equipment inyour vehicle. Such accessories may cause the elec-
tronic system to malfunction if they are incorrectly
installed or if they are not suited for the vehicle.
