Driving tips
8-9
– CONTINUED –
aid kit and portable phone or citizens band radio. Drive carefully. Do not take unnecessary risks by
driving in dangerous areas or over rough terrain. Slow down and employ extra caution at all times.
When driving off-road, you will not have the benefit
of marked traffic lanes, banked curves, traffic signs and the like. Do not drive across steep slopes. Instead, drive
either straight up or straight down the slopes. A ve-
hicle can much more easily tip over sideways than it
can end over end. Avoid driving straight up or down
slopes that are too steep. Avoid sharp turning maneuvers, especially at
higher speeds. Do not grip the inside or spokes of the steering
wheel. A bad bump could jerk the wheel and injureyour hands. Instead drive with your fingers andthumbs on the outside of the rim. If driving through water, such as when crossing
shallow streams, first check the depth of the water
and the bottom of the stream bed for firmness and
ensure that the bed of the stream is flat. Drive slowly
and completely through the stream. The water
should be shallow enough that it does not reach the
vehicle’ s undercarriage. Water entering the engine
air intake or the exhaust pipe or water splashing
onto electrical parts may damage your vehicle and may cause it to stall. Never attempt to drive through
rushing water; regardless of its depth, it can wash
away the ground from under your tires, resulting in
possible loss of traction and even vehicle rollover.
Always check your brakes for effectiveness im-
mediately after driving in sand, mud or water. Do
this by driving slowly and stepping on the brake
pedal. Repeat that process several times to dry outthe brake discs and brake pads. Do not drive or park over or near flammable mate-
rials such as dry grass or fallen leaves, as they may
burn easily. The exhaust system is very hot while en- gine is running and right after the engine stops. This
could create a fire hazard. After driving through tall grass, mud, rock, sand,
rivers, etc., check that there is no grass, bush, pa-
per, rags, stones, sand, etc. adhering to or trapped
on the underbody. Clear off any such matter from
the underbody. If the vehicle is used with these ma-
terials trapped or adhering to the underbody, a
mechanical breakdown or fire could occur. Secure all cargo carried inside the vehicle and
make certain that it is not piled higher than the seat-
backs. During sudden stops or jolts, unsecured car-
go could be thrown around in the vehicle and cause
injury. Do not pile heavy loads on the roof. Thoseloads raise the vehicle ’s center of gravity and make

Driving tips
8-10
it more prone to tip over. If you must rock the vehicle to free it from sand or
mud, depress the accelerator pedal slightly and
move the selector lever back and forth between “D”
and “R” repeatedly. Do not race the engine. For the
best possible traction, avoid spinning the wheels
when trying to free the vehicle.
When the road surface is extremely slippery, you
can obtain better traction by starting the vehicle withthe transmission in 2nd than 1st (both for MT and
AT). Never equip your vehicle with tires larger than
those specified in this manual. Frequent driving of an AWD vehicle under hard-
driving conditions such as rough roads or off roads
will necessitate more frequent replacement of engine
oil, brake fluid and transmission oil than that specified
in the maintenance schedule described in the “War -
ranty and Maintenance Booklet ”.
Remember that damage done to your Subaru while
operating it off-road and not using common sense
precautions such as those listed above is not eligi-ble for warranty coverage. Winter driving
HG8001AA

Operation during cold weather
Carry some emergency equipment, such as tire
chains, a window scraper, a bag of sand, flares, asmall shovel, and jumper cables.
Check the battery and cables. Cold temperatures
reduce battery capacity. The battery must be in
good condition to provide enough power for cold
winter starts.
Use an engine oil of proper grade and viscosity for
cold weather. Heavy summer oil will cause harder
starting.

Driving tips
8-11
– CONTINUED –
Keep the door locks from freezing by squirting them with deicer or glycerin.
Forcing a frozen door open may damage or sepa-
rate the rubber weather strips around the door. If the
door is frozen, use hot water to melt the ice, and af-
terwards thoroughly wipe the water away. Use a windshield washer fluid that contains an anti-
freeze solution. Do not use engine antifreeze or oth-
er substitutes because they may damage the paintof the vehicle.
Before driving your vehicle
Before entering the vehicle, remove any snow or ice
from your shoes because that could make the ped-
als slippery and dangerous.
While warming up the vehicle before driving, check that the accelerator pedal, brake pedal, and all oth-
er controls operate smoothly. Clear away ice and snow that has accumulated un-
der the fenders to avoid making steering difficult.
During severe winter driving, stop when and where itis safe to do so and check under the fenders peri-
odically.
Parking in cold weather
Do not use the parking brake when parking for long
periods in cold weather since it could freeze in that
position. Instead, observe the following:
1. Place the shift lever in “1” or “R” for manual trans-
mission vehicles, and in “P” for automatic transmis-
sion vehicles.
2. Use tire stops under the tires to prevent the ve-
hicle from moving.
When the vehicle is parked in snow or when it
snows, raise the wiper blades off the glass to pre-vent damage to them.
When the vehicle has been left parked after use on
roads heavily covered with snow, or has been left
parked during a snowstorm, icing may develop onthe brake system, which could cause poor braking
action. Check for snow or ice buildup on the sus-
pension, disc brakes and brake hoses underneath the vehicle.
If there is caked snow or ice, remove it, being care-ful not to damage the disc brakes and brake hoses
and ABS harness.

Driving tips
8-27
– CONTINUED –
Trailer towing
Your car is designed and intended to be used pri-
marily as a passenger-carrying vehicle. Towing a
trailer puts additional loads on your car ’s engine, dri-
vetrain, brakes, tires and suspension and has an
adverse effect on fuel economy.
If you do decide to tow a trailer, your safety and sat-
isfaction depend upon proper use of correct equip-
ment and cautious operation of your vehicle. Seekthe advice of your SUBARU dealer to assist you in
purchasing a hitch and other necessary towing
equipment appropriate for your vehicle. In addition,
be sure to follow the instructions on correct installa-
tion and use provided by the trailer and other towing
equipment manufacturers.
SUBARU assumes no responsibility for injuries or
vehicle damage that result from trailer towing equip-
ment, or from any errors or omissions in the instruc- tions accompanying such equipment or for your fail-
ure to follow the proper instructions. Warranties and maintenance
SUBARU warranties do not apply to vehicle damage or malfunction caused by trailer towing. If you use
your vehicle to tow a trailer, more frequent mainte-
nance will be required due to the additional load. (Refer to
“Maintenance schedule under severe driv-
ing conditions ” in the “Warranty and Maintenance
Booklet”.)
Under no circumstances should a trailer be towedwith a new vehicle or a vehicle with any new power-
train component (engine, transmission, differential, wheel bearings, etc.) for the first 1,000 miles (1,600 km) of driving. Maximum load limits
WARNING
Never exceed the maximum load limits ex-
plained below. Exceeding the maximum loadlimits could cause personal injury and/or ve-hicle damage.
CAUTION
Adequate size trailer brakes are required
when the trailer and its cargo exceed 1,000 lbs (453 kg) total weight. Before towing a trailer, check the trailer total
weight, GVW, GAWs and tongue load. Make sure the load and its distribution in your
vehicle and trailer are acceptable.

In case of emergency
9-15
– CONTINUED –
Confirm that the cooling fan is turning. If the fan is
not turning, immediately turn the engine off and con-
tact your authorized dealer for repair.
3. After the engine coolant temperature has
dropped, turn off the engine.
If the temperature gauge stays at the overheated
zone, turn the engine off.
4. After the engine has fully cooled down, check the
coolant level in the reserve tank.If the coolant level is below the “MIN” mark, add
coolant up to the “MAX” mark.
5. If there is no coolant in the reserve tank, add
coolant to the reserve tank. Then remove the radia- tor cap and fill the radiator with coolant.
If you remove the radiator cap from a hot radiator,
first wrap a thick cloth around the radiator cap, then
turn the cap counterclockwise slowly without press-
ing down until it stops. Release the pressure from
the radiator. After the pressure has been fully re-
leased, remove the cap by pressing down and turn-ing it. Towing
If towing is necessary, it is best done by your
SUBARU dealer or a commercial towing service.
Observe the following procedures for safety.
HG9000BA
WARNING
Never tow AWD vehicles (both AT and MT) with the front wheels raised off the groundwhile the rear wheels are on the ground, orwith the rear wheels raised off the ground while the front wheels are on the ground. This will cause the vehicle to spin away due to the

In case of emergency
9-19
– CONTINUED –
3. Secure the vehicle onto the carrier properly with safety chains. Each of safety chain should be
equally tightened and care must be taken not to pull
the chains so tightly that the suspension bottomsout.
CAUTION
If your vehicle has a front underspoiler and rear underspoiler (both optional), be carefulnot to scrape them when placing the vehicleon the carrier and when removing the vehicle
from the carrier.
Towing with all wheels on the ground
HG9001AA
1. Check the transmission and differential oil levels
and add oil to bring it to the upper level if necessary.
2. Release the parking brake and put the transmis-sion in neutral.
3. The ignition switch should be in the “ACC” posi-
tion while the vehicle is being towed.
4. Take up slack in the towline slowly to prevent
damage to the vehicle.
WARNING
Never turn the ignition switch to the “LOCK”
position while the vehicle is being towed be-
cause the steering wheel and the direction ofthe wheels will be locked. Remember that the brake booster and pow-
er steering do not function when the engine is not running. Because the engine is turned off,
it will take greater effort to operate the brakepedal and steering wheel.

11
11-1
– CONTINUED –
Maintenance schedule 11-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance precautions 11-3 . . . . . . . . . . . . . . . . . . . . . . . .
Engine hood 11-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine compartment overview 11-7 . . . . . . . . . . . . . . . . .
2.5 liter model 11-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.0 liter (Turbo) model 11-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil 11-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the oil level 11-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the oil and oil filter 11-10 . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-11 . . . . . . . . . . .
Recommended grade and viscosity under
severe driving conditions 11-13 . . . . . . . . . . . . . . . . . . . . . .
Cooling system 11-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hose and connections 11-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant 11-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air cleaner element 11-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing the air cleaner element 11-18 . . . . . . . . . . . . . .
Spark plugs 11-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended spark plugs 11-21 . . . . . . . . . . . . . . . . . . . . .
Drive belts 11-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission oil 11-23 . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the oil level 11-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-24 . . . . . . . . . . .
Automatic transmission fluid 11-24 . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-24 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended fluid 11-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front differential gear oil (AT vehicles) 11-26 . . . . . Checking the oil level 11-26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-26 . . . . . . . . . . .
Rear differential gear oil 11-27 . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the gear oil level 11-27 . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-28 . . . . . . . . . . .
Power steering fluid 11-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-29 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended fluid 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake fluid 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-30 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended brake fluid 11-31 . . . . . . . . . . . . . . . . . . . . . . .
Clutch fluid (MT vehicles) 11-31 . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-31 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended clutch fluid 11-32 . . . . . . . . . . . . . . . . . . . . . .
Brake booster 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pedal 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the brake pedal free play 11-33 . . . . . . . . . . . .
Checking the brake pedal reserve distance 11-34 . .
Clutch pedal (MT vehicles) 11-34 . . . . . . . . . . . . . . . . . . . . . .
Checking the clutch function 11-34 . . . . . . . . . . . . . . . . . . . .
Checking the clutch pedal free play 11-35 . . . . . . . . . . .
Replacement of brake pad and lining 11-35 . . . . . . . .
Breaking-in of new brake pads and linings 11-36 . . .
Parking brake stroke 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires and wheels 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Types of tires 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire inspection 11-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire pressures and wear 11-38 . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance and service

Maintenance and service
11-4
Always be very careful to avoid injury when
working on the vehicle. Remember that some of the materials in the vehicle may be hazard-
ous if improperly used or handled, for exam-ple, battery acid. Your vehicle should only be serviced by per-
sons fully competent to do so. Serious per-sonal injury may result to persons not experi-enced in servicing vehicles. Always use the proper tools and make cer-
tain that they are well maintained. Never get under the vehicle supported only
by a jack. Always use a safety stands to sup-port the vehicle. Never keep the engine running in a poorly
ventilated area, such as a garage or other
closed areas. Do not smoke or allow open flames around
the fuel or battery. This will cause a fire. Because the fuel system is under pressure,
replacement of the fuel filter should be per-
formed only by your SUBARU dealer. Ensure your eyes are free of oil and fluid, as
they can be harmful to your eyes. If you get one in your eyes, wash your eyes with clean
water. For your safety, you are wise to weareye protection.
Do not tamper with the wiring of the SRS
airbag system or seatbelt pretensioner sys-tem, or attempt to take its connectors apart,as that may activate the system or it can ren-der it inoperative. The wiring and connectorsof these systems are yellow for easy identifi- cation. NEVER use a circuit tester for these wiring. If your SRS airbag or seatbelt pretensionerneeds service, consult your nearest SUBARU
dealer. Before checking or servicing in the
engine compartment
Always stop the engine and set the parking
brake firmly to prevent the vehicle from mov- ing. Always let the engine cool down. Engine
parts become very hot when the engine is run-
ning and remain hot for some time after theengine is stopped. Do not spill engine oil, engine coolant, brake
fluid or any other fluid on hot engine compo-nents. This may cause a fire. Always remove the key from the ignition
switch. When the ignition switch is in the
