2002 PONTIAC BONNEVILLE alarm

2-7
There are several ways to lock and unlock your vehicle.
If your vehicle has a theft
-deterrent system and it is
activated, unlock the doors only with the key or remote
keyless entry system. This will avoid setting off the
alarm. See ªUniversal Theft
-Deterrentº in the Index for
more information.
To unlock the door from the outside, use your door key
or remote keyless entry transmitter (if equipped).
Turning the door key toward the rear of the vehicle will
unlock the door. Turning the door key toward the front
of the vehicle will lock it.
To lock the door from the inside, push the manual door
lock forward. To unlock the door, push the manual door
lock rearward.

2-14
Operation
The driver's door will
unlock and the exterior
lamps may flash twice when
the button with the unlock
symbol is pressed.
The fuel door will also unlock when unlock is pressed,
if you have the optional fuel door lock.
If the button with the unlock symbol is pressed again
within five seconds, all the doors will unlock. Pressing
the unlock button will also illuminate the interior lamps.
See ªIlluminated Entryº and ªSecurity Feedbackº in
the Index.All doors will lock, the exterior lamps may flash once
and the horn may chirp when the button with the lock
symbol is pressed. See ªSecurity Feedbackº in the
Index. Pressing the lock button may also turn off the
interior lamps if illuminated. If you have the optional
fuel door lock, the fuel door will also lock when the lock
button is pressed.
The trunk will unlock when the trunk symbol is pressed
when the ignition is in OFF. The trunk symbol will
also work when the ignition is on, but only while in
PARK (P) or NEUTRAL (N).
Instant Alarm
When the button with the horn symbol on the remote
keyless entry transmitter is pressed, the horn will sound
and the headlamps and taillamps will flash for up to
30 seconds. This can be turned off by pressing the
instant alarm button again or by turning the ignition to
ON. If your vehicle has the Universal Theft
-Deterrent
feature, you may also turn off the alarm by unlocking
the vehicle with a key. See ªUniversal Theft
-Deterrentº
in the Index.

2-21 Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
Even if you park in a lot where someone will be
watching your vehicle, it's still best to lock it up and
take your keys. But what if you have to leave your
ignition key?

If possible, park in a busy, well
-lit area.

Put your valuables in a storage area, like your trunk
or glove box.

Be sure to close and lock the storage area.

Close all windows.

Lock the glove box.

Lock all doors except the driver's.

Give the valet key to the valet. Then take the master
key with you.
Universal Theft-Deterrent
(If Equipped)
If your vehicle has this feature, it has a theft-deterrent
alarm system. With this system, the SECURITY
light will flash as you open the door (if your ignition is
in OFF).
This light on the instrument
panel cluster reminds you to
activate the theft
-deterrent
system when leaving
your vehicle.
To activate the system, do the following:
1. Open the door.
2. Lock the door with the power door lock switch while
the door is open, or use the remote keyless entry
transmitter (if equipped). The SECURITY light
should come on and stay on.
3. Close all doors. The SECURITY light should go
off after about 30 seconds and the system will then
be armed.

2-22
If the SECURITY light comes on for one minute
and then shuts off while the ignition is on, the security
system has detected a problem. See your dealer
for service.
If a door is opened without the key or remote keyless
entry transmitter, or if the door key cylinders are
damaged, the alarm will go off. The exterior lamps will
flash and the horn will sound for 30 seconds, then will
go off in order to save battery power.
Remember, the theft
-deterrent system won't activate if
you lock the doors with a key or manual door lock. It
activates only if you use a power door lock switch while
the door is open, or the remote keyless entry transmitter.
Avoid setting off the alarm by accident.
Always unlock a door with a key, or use the remote
keyless entry transmitter. Unlocking a door any other
way will set off the alarm.
If you set off the alarm by accident, unlock the driver's
door with your key. You can also turn off the alarm by
pressing the button with the unlock symbol on the
remote keyless entry transmitter. The alarm won't stop if
you try to unlock a door any other way.
Testing the Alarm
1. From inside the vehicle, roll down the window.
2. Activate the system by locking the doors with the
power door lock switch while the door is open, or
with the remote keyless entry transmitter.
3. Get out of the vehicle, close the door and wait for the
SECURITY light to go out.
4. Then, reach in through the window, unlock the door
with the manual door lock and open the door. This
should set off the alarm.
If the alarm does not sound when it should, check to see
if the horn works. The horn fuse may be blown. To
replace the fuse, see ªFuses and Circuit Breakersº in
the Index.
If the alarm does not sound, or the exterior lamps do not
flash, see your dealer.

2-23
Content Theft-Deterrent (Option)
If your vehicle has this option, it has a theft-deterrent
alarm system.
A light located in your Twilight Sentinel

cluster, above
the fog lamp button, will begin to flash 30 seconds after
the vehicle ignition is turned off to let you know the
system has been armed.
While armed, the doors will not unlock with the power
door lock switch.
Once armed, the alarm will go off if someone tries to
enter the vehicle without using the remote keyless entry
transmitter or a key, breaks a window, tries to damage
the vehicle or turns the ignition to ON. If any of these do
occur, the horn will sound and the parking lamps will
flash for up to two minutes.
PASS-Key
III
Your vehicle is equipped
with the PASS
-Key III
(Personalized Automotive
Security System)
theft
-deterrent system.
PASS
-Key III is a passive
theft
-deterrent system.
This means you don't have to do anything different to
arm or disarm the system. It works when you insert or
remove the key from the ignition.
Your PASS
-Key III system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.

2-52
Theater Dimming
This feature allows for a three to five-second fade out of
the courtesy lamps instead of immediate turn off after
you remove the key from the ignition.
Delayed Exit Lighting
This feature will turn on the interior lamps for
25 seconds after you remove the key from the ignition
while the doors are closed and it is night. This will give
you time to find the door handle or lock switches as you
exit the vehicle.
This lighting will only be deactivated if the key is
reinserted into the ignition switch or the power door
locks are activated.
Parade Dimming
To activate the instrument panel backlighting during the
day, turn the exterior lamp switch to the parking lamp or
headlamp position. Dimming of the instrument panel
display is not possible during daylight hours. The
instrument panel display can only be adjusted when
the parking lamps or headlamps are on and it is
dark outside.
Perimeter Lighting
When the button with the unlock symbol on the remote
keyless entry transmitter (if equipped) is pressed, the
DRL headlamps, parking lamps and back
-up lamps will
turn on if it is dark enough outside.
Personalization Programming
This feature can be programmed in the on or off mode
for each transmitter.
To turn the feature off do the following:
1. Keep all doors closed, the vehicle in PARK (P) and
the ignition on throughout this procedure.
2. Press and hold LOCK on the power door lock switch
throughout this procedure. All the doors will lock.
3. Press the instant alarm on the transmitter. Perimeter
lighting remains on at this time and the horn will
chirp twice.
4. Press the instant alarm on the transmitter again.
Perimeter lighting is disabled and the horn will
chirp once.
5. Release the door lock switch. The perimeter lighting
feature is now off.

2-53
To turn the feature on do the following:
1. Keep all doors closed, the vehicle in PARK (P) and
the ignition on throughout this procedure.
2. Press and hold LOCK on the power door lock switch
throughout this procedure. All the doors will lock.
3. Press the instant alarm on the transmitter. Perimeter
lighting remains off at this time and the horn will
chirp once.
4. Press the instant alarm on the transmitter again.
Perimeter lighting is now enabled and the horn will
chirp twice.
5. Release the door lock switch. The perimeter lighting
feature is now on.
This procedure only changes the mode for the
transmitter used to change this setting. The procedure
will need to be repeated for the second transmitter.
If your vehicle is equipped with the Driver Information
Center (DIC), you must program this feature through
the DIC. See ªDriver Information Center
Personalization Programmingº in the Index.Front Reading Lamps
The front reading lamps, located on the headliner, will
come on as courtesy lamps when you open any of the
doors while it is dark outside. They will also come on as
part of the interior lighting features listed previously.
To turn on a reading lamp when the doors are closed,
press either button. Press it again to turn the lamp off.
To avoid draining your vehicle's battery, be sure to turn
off the reading lamps when leaving your vehicle. See
ªInadvertent Power Battery Saverº later in this section
for more information.

2-76
Tachometer
The tachometer shows your
engine speed in revolutions
per minute (rpm).
NOTICE:
Do not operate the engine with the tachometer in
the shaded area or engine damage may occur.
Warning Lights, Gages
and Indicators
This part describes the warning lights and gages that
may be on your vehicle. The pictures will help you
locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause an
expensive repair or replacement. Paying attention to
your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you are
familiar with this section, you should not be alarmed
when this happens.
