THE KEYS
The keys allow you to switch on
the ignition and to independently
operate the front doors, the fuel
filler cap, the glove box, the pas
senger air bag disarming switch
and the mechanical child lock.
Central locking
From the driver’s or passenger
door, the keys allow you to lock,
deadlock or unlock the doors and
the tailgate and to fold back the
exterior mirrors.
If one of the doors or the boot is
open, it is impossible to operate
the central locking.
The remote control performs
the same functions at a
distance.The remote control key
Locking
Press button
Ato lock the vehicle.
Button Aalso locates the vehicle
and reinitialises the remote con- trol.
Deadlocking
Press button Ato deadlock the
vehicle and close the windows
automatically.
A second press on button Ain
the five seconds following dead
locking, changes deadlocking to
normal locking.
Deadlocking renders the
internal and external doorlocking controls inoperative. Do not leave anyoneinside the vehicle when it is deadlocked.
Unlocking/Ventilation
Press button Bto unlock the vehi
cle.
A second press on buttonBin
the five seconds following unlock
ing opens the windows. Opening/Closing the electric
sliding side doors
Along press on button
C or D
unlocks the vehicle, then permits
opening or closing of the corre
sponding rear door.
Folding/Unfolding the key
Press button Eto unfold or fold
the key in its case.
STARTING
1 STOP position: the ignition is off.
2 1 st
notch, Accessories
position:
the ignition is off but the
accessories can be used.
3 2 nd
notch, Running posi
tion:
the ignition is on.
4 Starting position: operates the starter.
4
103
18-11-2002
YOUR 807 AT A GLANCE

YOUR 807 IN DETAIL91
Memorising using the buttons M,
1 and 2
T
o memorise using the buttons located
on the side of the seat: Place the ignition key in the 'running'
position (2 nd
notch),
 Adjust your seat and mirrors,
 Press button M,then button 1
(first driving position) or button 2
(second driving position) within
four seconds.
An audible signal confirms that a
position has been memorised.
Memorising a new position cancels
the previous one.
Recalling a memorised position
Engine off Briefly press button 1 or 2to recall
the corresponding memorised
position.
Note: after recalling a memorised
position five times in succession, the
function will be cancelled until the
engine is started.
Engine running Keep button 1 or 2pressed down
until the end of setting of the cor
responding memorised position.
Memorising seat and mirror
positions
Four driving positions can be memo
rised:
– two, using
two remote control
keys (two users),
– two, using buttons M/1 and M/2.
Driving positions memorised by
the remote control key
When locking the doors, the remote
control key memorises the position
of the driver's seat and the exterior
mirrors.
When unlocking the doors, the dri
ver's seat and the exterior mirrors
resume the position memorised by
the remote control key if this has
changed in the meantime.
Each remote control key can
memorise a specific setting. Front heated seat controls
The front seats can be heated sepa
rately.
Use the adjustment controls located
on the side of each seat to select the
level of heating required :
0:
Off.
1: Low.
2: Medium.
3: High.
The seat temperature is controlled
automatically.
Note: the heated seats only operate
with the engine running.
18-11-2002

YOUR 807 IN DETAIL91
Memorising using the buttons M,
1 and 2
T
o memorise using the buttons located
on the side of the seat: Place the ignition key in the 'running'
position (2 nd
notch),
 Adjust your seat and mirrors,
 Press button M,then button 1
(first driving position) or button 2
(second driving position) within
four seconds.
An audible signal confirms that a
position has been memorised.
Memorising a new position cancels
the previous one.
Recalling a memorised position
Engine off Briefly press button 1 or 2to recall
the corresponding memorised
position.
Note: after recalling a memorised
position five times in succession, the
function will be cancelled until the
engine is started.
Engine running Keep button 1 or 2pressed down
until the end of setting of the cor
responding memorised position.
Memorising seat and mirror
positions
Four driving positions can be memo
rised:
– two, using
two remote control
keys (two users),
– two, using buttons M/1 and M/2.
Driving positions memorised by
the remote control key
When locking the doors, the remote
control key memorises the position
of the driver's seat and the exterior
mirrors.
When unlocking the doors, the dri
ver's seat and the exterior mirrors
resume the position memorised by
the remote control key if this has
changed in the meantime.
Each remote control key can
memorise a specific setting. Front heated seat controls
The front seats can be heated sepa
rately.
Use the adjustment controls located
on the side of each seat to select the
level of heating required :
0:
Off.
1: Low.
2: Medium.
3: High.
The seat temperature is controlled
automatically.
Note: the heated seats only operate
with the engine running.
18-11-2002

THE KEYS
The keys allow you to switch on the
ignition and to independently operate
the locks on the driver's door and
passenger door, the fuel filler cap,
the glove box, the passenger air bag
disarming switch and the child safety
lock.
Central locking
From the driver's door or passenger
door, the keys allow you to lock,
deadlock or unlock the doors and
tailgate, as well as fold back the
exterior mirrors.
If one of the doors or the tailgate is
open, the central locking does not
work.
The remote control performs the
same functions at a distance.
YOUR 807 IN DETAIL103
The remote control
Version with single locking
Press button
Ato lock the vehicle.
This is confirmed by fixed lighting of
the direction indicators for approxi
mately two seconds. Vehicles fitted with deadlocking
Warning:
deadlocking renders the
internal and external door locking
controls inoperative.
Never leave anyone inside the vehi
cle when the vehicle is deadlocked.
Pressing buttonAdeadlocks the
vehicle. This is confirmed by fixed
lighting of the direction indicators for
approximately two seconds.
A second press on button Awithin
five seconds of deadlocking changes
this to single locking. This is con
firmed by fixed lighting of the direc
tion indicators for two seconds.
Note: the driver operates the dead
locking from inside the vehicle. On
starting the vehicle deadlocking
changes to single locking.
Note: presing button A, in addition to
locking or deadlocking, permits auto
matic closing of the windows and the
sunroof. However, the sunroof stops
in a partially open posiition. Unlocking
/Ventilation
Press button B to unlock the vehicle.
This is confirmed by rapid flashing of
the direction indicators.
A second press on button Awithin
five seconds of deadlocking opens
the windows.
Note : if the vehicle is locked and
unlocking is activated inadvertently,
unless the doors are opened within
30 seconds, the vehicle will lock
automatically.
Opening/Closing the electric
sliding side doors
A long press on button Copens or
closes the rear right door.
A long press on button Dopens or
closes the rear left door.
Note : this press unlocks the vehicle
before opening the corresponding
door.
Folding/opening out the key
To tuck away the key blade, press
button E, then fold it down into the
remote control module.
To open out the key, press button E.
18-11-2002

Changing the battery
of the remote control
The information "battery flat" is given
by an audible signal accompanied by
the message "Remote control bat
tery low" on the multi–function dis
play.
To replace the battery, unclip the
casing using a coin at the ring
(CR1620/3 volt battery).
If the remote control does not work
after the battery has been changed,
re programme the remote control.
Programming the remote
control
 Switch off the ignition.
 Switch the ignition on again.
 Press button Aimmediately.
 Switch off the ignition and remove
the remote control key from the
ignition lock. The remote control is
now working again. CONFIDENTIAL CARD
The confidential card contains the
identification code necessary for any
work carried out by a PEUGEOT
dealer on the system. This code is
hidden by a film, which should be
removed only if necessary.
Keep your card in a safe place,
never inside the vehicle.
Key in ignition
The message
"Key in ignition" on
the multi–function display, accompa
nied by a buzzer on opening the
driver's door, indicates that the key
has been left in the ignition.
YOUR 807 IN DETAIL
104
ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control system
a few moments after the ignition has
been switched off and therefore
prevents starting of the vehicle by
anyone who does not have the key.
The ignition key has an electronic
chip which has a special code. When
the ignition is switched on, the code
is recognised and starting is possi
ble.
If the system does not function
correctly,
the message "Antitheft
device fault" appears on the
multi–function display, accompanied
by an audible signal.
WARNING : your vehicle is no
longer protected.
Contact a PEUGEOT dealer as soon
as possible.
Locating your vehicle
To locate your vehicle, if you have
locked it, in a car park :
 press button A. The courtesy
lights come on and the direction
indicators flash for a few seconds.
18-11-2002

YOUR 807 IN DETAIL105
Make a careful note of the number on each key. The key number i s coded on the label attached to the key. If
the key is lost, your PEUGEOT dealer can rapidly supply you with ne w keys.
The highfrequency remote control is a sensitive system; do not ope rate it while it is in your pocket as there is
a possibility that it may unlock your vehicle without your knowle dge.
The remote control cannot operate if the key is in the ignit ion, even if the ignition is switched off, except for reprogramming.
Do not operate the deadlock if there is someone inside the vehicle.
Driving with the doors locked or deadlocked may mean it is diffi cult for the emergency services to access the
passenge rcompartment in the event of an emergency.
As a safety measure (when there are children on board), remove the i gnition key when leaving the vehicle, even for a
short time.
Do not handle the buttons of your remote control when out of range of your vehicle, as you run the risk of stopping it
from working.
It would then be necessary to reprogramme the remote control.
When buying a secondhand car:
– Ensure that you are given the confidential card;
– have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones
that can start your vehicle.
Do not make any modifications to the electronic engine immobil iser system.
18-11-2002

Changing the battery
of the remote control
The information "battery flat" is given
by an audible signal accompanied by
the message "Remote control bat
tery low" on the multi–function dis
play.
To replace the battery, unclip the
casing using a coin at the ring
(CR1620/3 volt battery).
If the remote control does not work
after the battery has been changed,
re programme the remote control.
Programming the remote
control
 Switch off the ignition.
 Switch the ignition on again.
 Press button Aimmediately.
 Switch off the ignition and remove
the remote control key from the
ignition lock. The remote control is
now working again. CONFIDENTIAL CARD
The confidential card contains the
identification code necessary for any
work carried out by a PEUGEOT
dealer on the system. This code is
hidden by a film, which should be
removed only if necessary.
Keep your card in a safe place,
never inside the vehicle.
Key in ignition
The message
"Key in ignition" on
the multi–function display, accompa
nied by a buzzer on opening the
driver's door, indicates that the key
has been left in the ignition.
YOUR 807 IN DETAIL
104
ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control system
a few moments after the ignition has
been switched off and therefore
prevents starting of the vehicle by
anyone who does not have the key.
The ignition key has an electronic
chip which has a special code. When
the ignition is switched on, the code
is recognised and starting is possi
ble.
If the system does not function
correctly,
the message "Antitheft
device fault" appears on the
multi–function display, accompanied
by an audible signal.
WARNING : your vehicle is no
longer protected.
Contact a PEUGEOT dealer as soon
as possible.
Locating your vehicle
To locate your vehicle, if you have
locked it, in a car park :
 press button A. The courtesy
lights come on and the direction
indicators flash for a few seconds.
18-11-2002

YOUR 807 IN DETAIL105
Make a careful note of the number on each key. The key number i s coded on the label attached to the key. If
the key is lost, your PEUGEOT dealer can rapidly supply you with ne w keys.
The highfrequency remote control is a sensitive system; do not ope rate it while it is in your pocket as there is
a possibility that it may unlock your vehicle without your knowle dge.
The remote control cannot operate if the key is in the ignit ion, even if the ignition is switched off, except for reprogramming.
Do not operate the deadlock if there is someone inside the vehicle.
Driving with the doors locked or deadlocked may mean it is diffi cult for the emergency services to access the
passenge rcompartment in the event of an emergency.
As a safety measure (when there are children on board), remove the i gnition key when leaving the vehicle, even for a
short time.
Do not handle the buttons of your remote control when out of range of your vehicle, as you run the risk of stopping it
from working.
It would then be necessary to reprogramme the remote control.
When buying a secondhand car:
– Ensure that you are given the confidential card;
– have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones
that can start your vehicle.
Do not make any modifications to the electronic engine immobil iser system.
18-11-2002
