2002 PEUGEOT 807 ECO mode

YOUR 807 IN DETAIL49
PTY function: Audio RD3
This allows you to listen to stations broadcasting a specific t ype of programme (news, culture, sport, rock etc.).
With FMselected, press the "TA"button for two seconds to switch this function on or off.
To search for a PTYprogramme:
select the PTYfunction,
briefly press button Ior Jto scroll down the list of the various types of programmes offered .
when the programme of your choice is displayed, keep button Ior Jpressed for two seconds
to carry out an automatic search (after an automatic search the PTYfunction is switched off).
In PTY mode the different types of programmes can be stored in the memory . To do this, press
the preselection buttons "1"to "6" for two seconds.
Briefly press the corresponding button to recall the type of prog ramme stored in the memory.
EON system: Audio RD3
This connects stations which are part of the same network. It en ables the broadcast of traffic information, by a station that
is part of the same network as the station to which you are li stening.
This service is available when you have selected the TAtraffic information programme or the PTYfunction.
18-11-2002

YOUR 807 IN DETAIL51
COMPACT DISC: AUDIO RD3
Selecting CD mode After insertion of a disc, printed face upwards, the player start s automatically.
If a disc is already inserted, press button Q.
Ejection of a disc Press button Sto eject the disc from the player.
Selecting a track Press button Ito select the next track.
Press button Jto return to the start of the current track or to select the previ ous track.
Accelerated play
Keep button Ior Jpressed for forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released.
Shuffle
When the CD player is selected, keep button Q pressed for two seconds. The tracks will be played in random seque nce.
Pressing the button again for two seconds returns you to normal p lay.
Shuffle mode is deactivated each time the audio system is switche d off.
The use of copied compact discs may cause faults.
Insert circular compact discs only.
18-11-2002

YOUR 807 IN DETAIL
54
Stalk movement
Function
A
Ejection of CD.
B SOURCE Selection of source: radio, CD or CD changer.
Press for more than 2 seconds: mute / cancel mute for current audio so urce being used
C Press: telephone on/off. Rotation: Adjusting the volume Audio adjustment: bass, trebl e, loudness, fader (FR/RR balance),
balance (L/R balance), automatic volume.
D Call connect (Tel/Incoming call) –
Display contextual menu (Tel/Not engaged).
E Access "PEUGEOT" services menu.
Press for more than 2 seconds: call "PEUGEOT" breakdown direct.
F MODE Change display.
Press for more than 2 seconds: display general information.
G Press: display contextual menu of display Confirm inputting or a djustment Cancel.
Rotation: move within a menu Select function / parameter Ad just.
H Adjust higher frequency, step by step or continuous (long press).
Select previous CD (CD changer).
I Adjust lower frequency, step by step or continuous (long press).
Select following CD (CD changer).
J ESC Cancel current operation.
Press for more than 2 seconds: clear all superimposed displays and retu rn to permanent application.
K Infrared window*.
L SIM card cover.
M kkAutomatic search of higher frequency Selection of following CD track.
Double press : change from LO mode to DX mode.
Press for more than 2 seconds: CD fast forward.
18-11-2002

YOUR 807 IN DETAIL55
Stalk movement
Function
N jjAutomatic search of lower frequency Selection of previous CD track.
Double press : change from LO mode to DX mode.
Press for more than 2 seconds: CD rewind.
O DARK 1st press: display top band (remainder of screen is black) 2nd press: brightness removed
(black screen) 3rd press: return to normal screen.
Press for more than 5 seconds: reinitialisation of the system.
P MENU Display general menu Press for more than 2 seconds: display help scre en.
Q Disconnect.
R BAND Select FM1, FM2, FMast, AM wavebands.
AST Press for more than 2 seconds: automatic storing of stations (autosto re).
S TA/PTY Traffic information priority on/off.
Press for more than 2 seconds: PTY function on/off.
T RDS RDS function on/off.
Press for more than 2 seconds: regional following mode on/off
U AUDIO Display window for adjusting loudness, sound distribution an d automatic
volume correction.
V SOS Press between 2 and 8 seconds: emergency call.
1 to 6 1 2 3 4 5 6 Select station in memory Select of CD in the CD changer.
Press more than 2 seconds: store station in memory while listening.
0 to 9 * #0 1 2 3 4 5Alphanumeric keypad for entering text and telephone numbers.
6 7 8 9 * #
* During the year.
18-11-2002

YOUR 807 IN DETAIL
56
GENERAL FUNCTIONS On/off
With the ignition switch in the accessories position or with the ignition on, press button C to switch the audio
function of the RT3 audio/telephone on or off.
Note: in the absence of an ignition key, press button C to switch the telematics system on or off.
The RT3 telephone can operate for 30 minutes without switc hing the vehicle ignition on.
Notes:
– the SIM card must be removed only after the audio/telephone h as been switched off,
– following automatic switching off of the audio/telepho ne after 30 minutes, it is possible to make a telephone call by pressing
button D,
– after the ignition has been switched off, the audio/te lephone can be switched on again by pressing buttons D, E, V or by
inserting a CD in the player.
Antitheft system
The RT3 audio/telephone is coded in such a way that it ca n operate only on your vehicle. If fitting it to another vehicle,
consult your PEUGEOT dealer for configuration of the system.
The system is automatic and requires no action on your part.
ADJUSTING THE VOLUME
Turn button Cclockwise to increase the volume of the audio/telephone or an ticlockwise to decrease it.
Note: the volume setting is specific to each source. It is possible to have different settings for radio, CD or CD changer.
AUDIO SETTINGS Press buttonUto access Bass,Treble ,Loudness ,Fader (front/rear balance), Balance(left/. right balance)
and Automatic volume adjustment settings.
Exit from audio mode is automatic after a few seconds without a ny action, or by pressing button J.
Note: bass and treble settings are specific to each source. It is possibl e to have different settings for radio,
CD or CD changer.
18-11-2002

YOUR 807 IN DETAIL61
PTY function
This allows you to listen to stations broadcasting a specific t ype of programme (news, culture, sport, rock etc.)
When FM is selected, press the "TA/PTY"button for more than two seconds to switch the function or or off.
To find a PTYprogramme:
select the PTYbutton,
turn button Gto scroll down the different types of programmes offered,
when the programme of your choice is displayed, press button Mor Nto carry out an automatic
search (after an automatic search the PTYfunction is switched off if no station has been found).
In PTY mode the different types of programmes can be stored in the memory . To do this, press the preselection buttons
" 1 " to " 6'' for more than two seconds. To recall the type of programme sto red in the memory, briefly press the corrresponding
button.
EON system
This system connects stations which are part of the same network. It enables the broadcast of traffic information or a PTY
programme, by a station that is part of the same network as the station to which you are listening.
The service is available when you have selected the TAtraffic information programme or the PTYfunction.
Contextual menu The contextual menu allows you to access the following functi ons:
"Inputting a frequency"
"Display Radio text" to display information connected with th e station being listened to.
18-11-2002

YOUR 807 IN DETAIL
64
TELEPHONE MODE
This function is a GSM dualband telephone (800 and 1 800 MHz) incorporated in the RT3 audio system.
It is a ''hands free'' telephone. This function is provided by a microphone located next to the front courtesy light, the
speakers and a steering column control which allows access to most of the functions (because the audio/telephone control
panel buttons allow access to all the functions).
Display of the principal ''mobile'' type functions, as well as consultation of the indexes, is pro vided by the multi–function
display.
This function is active whatever position the ignition key is in.
Note: when the key is in the accessories position (1st notch), this funct ion will be interrupted after thirty minutes, when the
message ''Economy mode active'' appears on the multi–function display. If you are using the telephone at that time, you
will be able to finish your call.
Using the menus
Press the ''MENU'' button to display the general menu. Select thetelematicsapplication, validiate Telephone functions
to access the principal telephone functions, then the various menus, in order to reach the one required.
This menu allows you to access the following functions:
Network: allows you to select the network search mode and to see the ne tworks
available.
Duration of calls: allows you to consult the duration recorder of calls made and ze ro
reset.
SIM card security: allows you to use or modify the PIN code and to erase the list of
calls and minimessages (SMS).
Telephone options: allows you to configure the calls with entering of my number,
automatic answering after X rings and specification of ring opt ions.
Within each menu:
Move around and select a function by turning knob Gthen validate by pressing the knob.
Cancel an operation by means of the ''ESC''button.
18-11-2002

YOUR 807 IN DETAIL
70
Services* Press button Eto display the "Services"menu and select one of the following services:
• "Customer Contact Centre" which enables you to contact the PEUGEOT Customer Contact Centre direct
ly and access the services offered (this type of call is suspended if an energency or breakown call is made).
• "Peugeot Assistance" which enables you to contact the call centre which controls the PEUGEOT breakdown
service directly and receive rapid assistance (you have 6 seconds within which to cancel the call when it is
made). During the breakdown call phase it is not possible to make any other calls with the exception of
emergency calls.
• "Operator services" which gives access to the list of services specific to the operator (e .g.: customer service,
consumption monitoring, news, stock market, weather, travel, games, etc) if they are available.
Note: during connection to a service, it is not possible to receive cal ls or SMS mini messages; they will be diverted to your
voice message service. Contrarily, it is possible to send a call wh ich results in automatic disconnection.
Emergency call*
In an emergency, press button Vuntil a signal is heard and a call validation / deletion screen is displayed (delay
of 6 seconds) or enter 11 2directly.
Note: in this case, a green diode flashes on the RT3 audio/tele phone panel when the emergency call procedure begins, then
lights permanently when the call is taken by the emergency services.
In the absence of a specific service contract, the parameters of th e SOS button are set so that a call is made to 11 2 unique
number made available by the worldwide GSM network, reserved for e mergency calls.
Before making a call of this kind, the audio/telephone must detect a cellular network. No security mode is required and,
depending on the network, you do not need to insert your SI M card or enter your PIN.
If you have signed the specific contract, refer to its general co nditions.
* If option and service available.
18-11-2002
