Operating check
ActivationWhen this function is acti
vated, the indicator light
comes on, accompanied by
an audible signal.
The light also comes on as soon as
the driver changes the stalk position
to 0.
Neutralisation When neutralising the func
tion, the indicator light
comes on, accompanied by
an audible signal.
The indicator light also comes on as
soon as the driver uses the manual
lighting controls.
If the sunshine / brightness sen
sor does not function correctly,
the system activates the function
(the lights come on) and the dipped
beam headlamps indicator light on
the instrument panel flashes.
Contact a PEUGEOT dealer to have
the system checked.
109
Automatic switching
on of the lights
Side lights and dipped beam head
lamps switch on automatically if the
light is poor, or during continuous
operation of the windscreen wipers.
They switch off as soon as the light
becomes bright enough or the wind
screen wipers stop.
Note : in foggy weather, the bright
ness sensor can detect sufficient
light. As a consequence, the lights
will not come on automatically.
This function is active when the vehi
cle is supplied to the customer.
To switch the function on or off::
Place the key in the accessories
position (1st notch),
Change the stalk position to 0,
Press the end of the stalk for more
than two seconds.
Note : after the ignition is switched
off and depending on the brightness,
the lights remain on for approximate
ly thirty seconds or until the vehicle is
locked. Do not cover the sunshine /
brightness sensor located in the
centre of the fascia. It helps to
regulate the air conditioning,
automatic switching on of the
lights and the automatic adjust
ment of the instrument panel
brightnes.
YOUR 607 IN DETAIL

110
Screenwash/headlamp wash lowWhen the minimum level of
the reservoir is reached,
this warning light comes on,
accompanied by an audible
signal and the message
'Screenwash low' on the multi
function display.
Next time you stop, fill the screen
wash / headlamp wash reservoir.
If the reservoir is empty, the warning
light comes on when the ignition is
switched on, or every time the stalk
is operated, until the reservoir is
filled.
YOUR 607 IN DETAIL
WINDSCREEN
WIPER STALK
Windscreen wipers
3 Fast wipe
2 Normal wipe
1 Intermittent or automatic wipe
0 Off
When the ignition has been
switched off for more than a
minute with the control in a wipe
position (1, 2 or 3), it is necesary
to reactivate this function. To d o
this, move the stalk to any position,
then move it back to the required
position. Windscreen and headlamp wash
Pull the windscreen wiper stalk
towards you.
The windscreen wash then the wind
screen wipers operate for a fixed
period. The windscreen wash and
headlamp wash operate simultane
ously for a few seconds,
only if the
dipped beam or main beam head
lamps are on. Do not cover the rain
sensor located on the
windscreen behind the
interior mirror.
When using an automat
ic car wash, switch off the ignition
or check that the wiper stalk is not
in the automatic position.
In winter, it is advisable to wait
until the windscreen is completely
free of ice before operating the
automatic wipe.
Maintenance position
This position enables the wiper
blade to be removed.
In the minute following switching off
of the ignition, any action on the stalk
positions the wipers in the centre of
the windscreen so that they may be
cleaned or replaced.
To park the wipers after this has
been done, switch on the ignition
and operate the stalk.

111
YOUR 607 IN DETAIL
Automatic windscreen wiper
In position 1, the wiper operates
automatically and adjusts its speed
to the intensity of the rainfall. Operating check
Activation
The indicator light comes on,
accompanied by an audible
signal, as soon as the driver
sets the windscreen wiper
stalk to position 1.
Neutralisation When the function is neu
tralised, going from position 1
to another position, the indi
cator light comes on, accom
panied by an audible signal.
In cases of malfunction, the driver
is informed by the message 'Rain
sensor faulty' on the multifunction
display.
In position 1, the windscreen wiper
will operate on intermittent wipe.
Contact a PEUGEOT dealer to have
the system checked.

If there is an operating
fault, the audible signal will
be a short bleep followed
by a long bleep when
changing to reverse gear.
YOUR 607 IN DETAIL
128
REAR PARKING ASSISTANCE
This system consists of four proximity
sensors, located in the rear bumper,
and a special speaker fitted under the
rear parcel shelf.
It detects any obstacle (person, vehicle,
tree, gate, pavement etc.) behind the
vehicle.
Note: this function will be disarmed
when the vehicle is towing a trailer
(vehicle fitted with towing attachment
recommended by PEUGEOT). In win
ter, ensure that the sensors are not
covered with frost or snow.
Activation
The system is activated as soon as
reverse gear is engaged; an audible
bleep shows that it is active.
An audible signal indicates the prox
imity of the obstacle. This signal
becomes more rapid as the vehicle
approaches the obstacle.
When the distance between the rear
of the vehicle and the obstacle is
less than approximately twentyfive
centimetres, the audible signal
becomes continuous. Deactivation
 Change to neutral, the system
becomes inactive.
Detection zone

139
TYRE UNDERINFLATION
DETECTION
Sensors check the tyre pressure
during driving, and trigger a warning
in the event of malfunction (speed
greater than 15mph [25 km/h]).
Flat tyreWhen this warning light
comes on, accompanied by
an audible signal and the
message 'Tyre pressure
low' on the multifunction
display, have the tyre pressure
checked as soon as possible.
Puncture
This warning light, accom
panied by an audible signal
and the message 'Punc
tured tyre(s) detected' on
the multifunction display, is
followed by illumination of the
'STOP' warning light.
Stop immediately, avoiding any sud
den movement of the steering wheel
and the brakes.
Change the damaged (punctured or
very deflated) tyre, and have the tyre
presure checked as soon as possible.
Note: if the damaged tyre is tem
porarily stored in the boot, it will
again emit this message to remind
you of the necessity of having it
repaired. This will prevent another
warning of the same type being dis
played. Sensor(s) not detected
This warning light, accom
panied by an audible signal
and the message ' X tyre
pressure sensor(s) miss
ing ' on the multifunction
display, indicates that underinflation
detection is absent from one (or sev
eral) tyre(s).
Contact a PEUGEOT dealer to
replace the faulty sensor(s).
Note: this message is also displayed
when one of the tyres is away from
the vehicle (being repaired) or when
a wheel without a sensor is fitted.
LES INFORMATIONS PRATIQUES
All repairs and changing
of tyres on a wheel fitted
with this system must be
carried out by a
PEUGEOT dealer.
The tyre underinflation detec
tion system is an aid to driving
which does not replace the
need for the driver to be vigilant
or to drive responsibly.
This system does not remove the
necessity for having the tyre pres
sure (including that of the spare
wheel) checked regularly, to
ensure optimum dynamic perfor
mance of the vehicle and to pre
vent premature wear of the tyres,
particularly in the case of arduous
driving conditions (heavy load,
high speed).
The system may temporarily be
disturbed by radio broadcasts on
a frequency close to it.

PRACTICAL INFORMATION 141
Fold the jack by pressing at the
ends
Aand place it in one of the
four locations Eunderneath the
vehicle (the nearest one to the
wheel to be changed).
Extend the jack, first by hand, pul
ling the ends Athen using wheel
brace 1and the extension 3.
Remove a wheel bolt at the top
and fit the centralising tool 2in its
place.
Unscrew the other bolts and
remove the wheel.
Fitting a wheel
Position the wheel using the cen
tralising tool to assist you.
Tighten the bolts by hand and
remove the centralising tool.
Partly tighten the bolts using the
wheelbrace.
Fold the jack and remove it.
Fully tighten the bolts using the
wheelbrace.
Replace the wheel trim.
Put the tool holder back in posi
tion. This helps to keep the boot
floor in its correct position, to pre
vent any deformation of the floor
when loaded.
Tighten the spare wheel securing
strap to prevent noise and for your
safety in the event of impact. For your safety, always
change the wheel:
– on level, stable, nonslippery
ground,
– with the handbrake applied,
– with first or reverse gear engaged (position Pfor the
automatic gearbox),
Never go underneath a vehicle
which is supported only by a
jack (use a ramp).
After changing the wheel:
– have the tightening of the bolts and the tyre pressure checked
by a PEUGEOT dealer as soon
as possible.
– have the punctured wheel repaired and refit it to the vehi
cle as soon as possible.
Tyres fitted with the Tyre Under
Inflation Detection System.
These wheels have a pressure
sensor. Have them repaired by a
PEUGEOT dealer.

Fuse N° RatingFunctions
10* 20 AAutomatic headlamp lighting control unit.
11* 70 A Builtin systems interface.
12* 70 A Ignition supply (+ve accessories / ignition controlled +ve).
13* 20 A Automatic headlamp lighting control unit.
14 15 A Double injection relay supply.
15* Not used.
16* Not used.
17* 30 A ESP hydraulic unit.
18 30 A Ignition supply (+ starter).
19 20 A Variable suspension control unit.
20 10 A Fan unit relay Cruise control safety switch Manual gearbox clut ch switch
Manual gearbox reversing lights switch or automatic gearbox multifu nction switch
Automatic headlamp lighting control unit Vehicle speed senso r Coolant level sensor
Water in diesel sensor Power switch control unit relay.
21 5 A Automatic gearbox control unit Automatic gearbox multifunction sw itch.
22 25 A ESP control unit.
23 15 A Diesel heating.
24 5 A Engine management control unit – Dual control control unit.
25 10 A Fuel pump.
26 30 A Driver's seat memory control unit.
27 25 A Double injection relay supply.
28 10 A Throttle housing deicing resistor, Intake pilot solenoid val ve Flow meter Piston deactivator
injectionpump Oil heating.
29 30 A Air pump, diesel additive control unit Diesel additive inje ctor.
30 Cannot be used.
31 5 A Automatic gearbox shift lock.
32 10 A ESP or ABS control unit.
33 15 A Automatic gearbox control unit Automatic gearbox multifunction sw itch (except reversing lights) Automatic
gearbox sequential control.
34 5 A Oxygen sensors Exhaust gas recirculation solenoid valve, Exhaust gas reci rculation throttle solenoid valve
Turbo pressure regulation solenoid valve..
PRACTICAL INFORMATION 149

PRACTICAL INFORMATION 147
Fuse no. Rating
Functions
7 10 A Switches, rear lighter illumination, front courtesy light, rear co urtesy light, rear lighter,
number plate lighting, headlamp height adjustment.
8 10 A Diagnostic connector, headlamp height adjustment control uni t, HF locking receiver,
passenger compartment air temperature sensor, HF tyre underinflatio n receiver.
9 20 A Headlamp wash.
10 20 A Glove box lighting, front lighter, front and rear courtesy li ght, electrochrome interior mirror,
electric exterior mirrors.
11 5 A Control unit for automatic lighting of headlamps, air bags control unit, safety relay for
automatic lighting of headlamps.
12 30 A Rear window switches on driver's pad, rear windows.
13 30 A Windscreen wiper.
14 15 A Not used.
15 15 A Driver's door pad, passenger's door pad.
16 15 A Rear lighter.
17 5 A Heated exterior mirrors.
18 15 A Rear left brake light, additional brake light.
19 10 A Parking assistance control unit, navigation control unit.
20 15 A Alarm siren, monochrome screen or colour screen control unit, HF receiver, audio system /
telephone, monochrome or colour navigation control unit, diese l additive control unit.
21 15 A Dignostic connector, caravan socket, trailer sidelights relay.
22 15 A Diesel additive control unit, driver's seat memory control unit, d river's door pad,
passenger's door pad.
23 30 A Driver's window, passenger's window, sunroof safety autoreverse, pa ssenger window swit
ch on driver's door pad andpassenger's door pad.
24 10 A Rear fog lamp.
25 40 A PARC shunt.
26 40 A Heated rear screen, radio aerial amplifier.
