2002 NISSAN FRONTIER jump start

6 In case of emergency
Flat tire ...................................................................6-2
Changing a flat tire ............................................6-2
Jump starting ..........................................................6-8
Push starting ..........................................................6-9
If your vehicle overheats ......................................6-10Towing your vehicle .............................................6-11
Towing recommended by Nissan ....................6-11
Vehicle recovery (freeing a stuck
vehicle) ............................................................6-13
ZX

To start your engine with a booster battery,
the instructions and precautions below must
be followed.
WARNING
cIf done incorrectly, jump starting can
lead to a battery explosion, resulting
in severe injury or death. It could
also damage your vehicle.
cExplosive hydrogen gas is always
present in the vicinity of the battery.
Keep all sparks and flames away
from the battery.
cDo not allow battery fluid to come
into contact with eyes, skin, clothing
or painted surfaces. Battery fluid is a
corrosive sulphuric acid solution
which can cause severe burns. If the
fluid should come into contact with
anything, immediately flush the con-
tacted area with water.
cKeep battery out of the reach of
children.
cThe booster battery must be rated at
12 volts. Use of an improperly rated
battery can damage your vehicle.cYour vehicle has an automatic en-
gine cooling fan. It could come on at
any time. Keeps hands and other
objects away from it.
cWhenever working on or near a bat-
tery, always wear suitable eye pro-
tectors (e.g., goggles or industrial
safety spectacles) and remove rings,
metal bands, or any other jewelry.
Do not lean over the battery when
jump starting.cDo not attempt to jump start a frozen
battery. It could explode and cause
serious injury.
WARNING
Always follow the instructions below.
Failure to do so could result in damage
to the charging system and cause per-
sonal injury.
1.
If the booster battery is in another vehicle,
position the two vehicles to bring their
ACE1018
JUMP STARTING
6-8In case of emergency
ZX

batteries into close proximity to each other.
Do not allow the two vehicles to touch.
2. Apply the parking brake. Move the shift
lever to N (Neutral) (on automatic trans-
mission models, move the selector lever
to P (Park)). Switch off all unnecessary
electrical systems (lights, heater, air con-
ditioner, etc.).
3. Remove vent caps on the battery (if so
equipped). Cover the battery with an old
cloth to reduce explosion hazard.
4. Connect jumper cables in the sequence
as illustrated.
CAUTION
cAlways connect positive (+) to posi-
tive (+) and negative (þ) to body
ground (for example, engine lift
bracket, etc.)Ðnot to the battery.
cMake sure the jumper cables do not
touch moving parts in the engine
compartment and that the cable
clamps do not contact any other
metal.
5. Start the engine of the booster vehicle
and let it run for a few minutes.6. Keep the engine speed of the booster
vehicle at about 2,000 r/min, and start the
engine of the vehicle being jump started.
CAUTION
Do not keep the starter motor engaged
for more than 10 seconds. If the engine
does not start right away, turn the key
off and wait 3 to 4 seconds before
trying again.
7. After starting your engine, carefully dis-
connect the negative cable and then the
positive cable.
8. Replace the vent caps (if so equipped).
Be sure to dispose of the cloth used to
cover the vent holes as it may be con-
taminated with corrosive acid.
CAUTION
cAutomatic transmission models can-
not be push started. This may cause
transmission damage.
cThree-way catalyst equipped models
should not be started by pushing.
The three-way catalyst may be dam-
aged.
cNever try to start the vehicle by tow-
ing it. When the engine starts, the
forward surge could cause the ve-
hicle to collide with the tow vehicle.
PUSH STARTING
In case of emergency6-9
ZX

8 Maintenance and do-it-yourself
Maintenance requirements .....................................8-2
General maintenance .............................................8-3
Explanation of general maintenance
items ..................................................................8-3
Exterior maintenance.........................................8-3
Interior maintenance ..........................................8-3
Maintenance precautions .......................................8-5
Engine compartment check locations ....................8-7
Engine cooling system .........................................8-10
Checking engine coolant level ........................8-10
Changing engine coolant ................................8-11
Engine oil .............................................................8-11
Checking engine oil level ................................8-11
Changing engine oil ........................................8-13
Changing engine oil filter.................................8-14
Automatic transmission fluid ................................8-15
Temperature conditions for checking ..............8-15
Power steering fluid..............................................8-17
Brake and clutch fluid...........................................8-17
Window washer fluid ............................................8-18
Window washer fluid reservoir ........................8-18
Battery ..................................................................8-18Jump starting ...................................................8-20
Drive belts ............................................................8-20
Spark plugs ..........................................................8-21
Replacing spark plugs
(except supercharger) .....................................8-22
Replacing spark plugs
(with supercharger)..........................................8-23
Air cleaner ............................................................8-23
Windshield wiper blades ......................................8-25
Cleaning ..........................................................8-25
Replacing .........................................................8-25
Parking brake and brake pedal ............................8-26
Checking parking brake...................................8-26
Checking brake pedal .....................................8-26
Brake booster ..................................................8-27
Clutch pedal .........................................................8-28
Checking clutch pedal .....................................8-28
Fuses ....................................................................8-29
Passenger compartment .................................8-29
Keyfob battery replacement .................................8-30
Lights ....................................................................8-31
Headlights ........................................................8-31
ZX

JUMP STARTING
If jump starting is necessary, see ``Jump
starting'' in the ``In case of emergency''
section. If the engine does not start by jump
starting, the battery may have to be re-
placed. Contact an authorized NISSAN
dealer.
WARNING
Be sure the ignition key is in the OFF or
LOCK position. The engine could rotate
unexpectedly.
1. Visually inspect each belt for signs of
unusual wear, cuts, fraying or looseness.
If the belt is in poor condition or loose,
have it replaced or adjusted by an autho-
rized NISSAN dealer.
2. Have the belts checked regularly for con-
dition and tension in accordance with the
maintenance schedule found in the
NISSAN Service and Maintenance Guide.''
ADI1073
DRIVE BELTS
8-20Maintenance and do-it-yourself
ZX

Hubs
Auto-lock free-running hubs ................. 5-21
I
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders) .................................................. 2-10
Inside mirror ............................................... 3-13
Instrument brightness control .................... 2-20
J
Jump seat .................................................... 1-5
Jump starting ............................................... 6-8
K
Key ............................................................... 3-2
Keyless entry system (See remote keyless
entry system) ............................................... 3-4
L
Labels
Air conditioner specification label ......... 9-14
Emission control information label........ 9-14
Engine serial number ........................... 9-13
F.M.V.S.S. certification label ................ 9-13Vehicle identification number (VIN)
plate ...................................................... 9-12
Warning labels (for SRS) ..................... 1-16
Light
Air bag warning light............................. 1-16
Brake light (See stop light) ................... 8-35
Bulb check/instrument panel ................ 2-10
Bulb replacement.................................. 8-35
Headlight aiming adjustment ................ 8-32
Headlight and turn signal switch .......... 2-20
Headlights ............................................. 8-31
Light bulbs ............................................ 8-31
Passenger supplemental air bag
ON/OFF switch and light ...................... 1-13
Spotlights (See map light) .................... 2-33
Warning/indicator lights and audible
reminders .............................................. 2-10
Lock
Door locks............................................... 3-2
Power door locks .................................... 3-3
Luggage rack (see roof rack) ...................... 3-9
Luggage (See vehicle loading
information) ................................................ 9-15
M
Maintenance
General maintenance ............................. 8-3
Inside the vehicle.................................... 8-3
Maintenance precautions ....................... 8-5
Outside the vehicle ................................. 8-3Seat belt maintenance.......................... 1-26
Under the hood and vehicle ................... 8-4
Malfunction indicator lamp (MIL) ............... 2-14
Manual windows ........................................ 2-29
Map lights .................................................. 2-33
Meters and gauges ...................................... 2-2
Mirror
Inside mirror.......................................... 3-13
Outside mirror control ........................... 3-14
Outside mirrors ..................................... 3-13
Vanity mirror ......................................... 3-13
Multi-remote control system (See remote
keyless entry system) .................................. 3-4
O
Octane rating (See fuel octane rating) ........ 9-5
Odometer ..................................................... 2-3
Oil
Capacities and recommended fuel/
lubricants ................................................ 9-2
Changing engine oil.............................. 8-13
Changing engine oil filter...................... 8-14
Checking engine oil level ..................... 8-11
Engine oil .............................................. 8-11
Engine oil and oil filter
recommendation ..................................... 9-6
Engine oil viscosity ................................. 9-7
Outside mirror control ................................ 3-14
Outside mirrors .......................................... 3-13
Overdrive switch ............................... 5-13, 5-14
10-3
ZX

Overheat
If your vehicle overheats ...................... 6-10
Owner's manual order form ....................... 9-30
P
Parking
Parking brake check ............................. 8-26
Parking brake operation ....................... 5-16
Parking/parking on hills ........................ 5-24
Passenger supplemental air bag ON/OFF
switch and light
Passenger supplemental air bag
ON/OFF switch and light ...................... 1-13
Power
Power door locks .................................... 3-3
Power steering fluid .............................. 8-17
Power steering system ......................... 5-25
Power windows..................................... 2-27
Precautions
Maintenance precautions ....................... 8-5
On-pavement and off-road driving
precautions ............................................. 5-3
Precautions on seat belt usage............ 1-18
Precautions when starting and driving ... 5-2
Push starting ................................................ 6-9
R
Radio
Car phone or CB radio ......................... 4-32FM-AM radio with cassette player and
compact disc (CD) player ..................... 4-13
FM-AM radio with compact disc (CD)
changer ................................................. 4-18
Steering wheel audio control switch ..... 4-31
Readiness for inspection maintenance
(I/M) test..................................................... 9-28
Rear sliding window................................... 2-29
Rear window defogger switch ................... 2-19
Registering your vehicle in another
country ....................................................... 9-12
Remote keyless entry system .................... 3-4
Reporting safety defects (USA) ................. 9-28
Roof rack (see luggage rack) ...................... 3-9
S
Safety
Reporting safety defects (USA) ............ 9-28
Seat
Jump seat ............................................... 1-5
Seat belt
Precautions on seat belt usage............ 1-18
Seat belt extenders .............................. 1-26
Seat belt maintenance.......................... 1-26
Seat belts.............................................. 1-18
Three-point type with retractor ............. 1-21
Two-point type without retractor ........... 1-24
Seat belt warning light ............................... 2-13
Seats
Adjustment .............................................. 1-2
Separate seats ....................................... 1-2Service manual order form ........................ 9-30
Shifting
Automatic transmission ........................ 5-10
Manual transmission............................. 5-15
Spark plug replacement............................. 8-21
Speedometer ............................................... 2-3
Spotlights (See map light) ......................... 2-33
SRS warning label ..................................... 1-16
Starting
Before starting the engine ...................... 5-8
Jump starting .......................................... 6-8
Precautions when starting and driving ... 5-2
Push starting........................................... 6-9
Starting the engine ................................. 5-8
Steering
Power steering fluid .............................. 8-17
Power steering system ......................... 5-25
Tilting steering wheel............................ 3-12
Steering wheel audio control switch .......... 4-31
Step rail...................................................... 3-11
Stop light .................................................... 8-35
Sun shade.................................................. 2-31
Sunroof ...................................................... 2-30
Supplemental restraint system
(Supplemental air bag system).................... 1-6
Switch
Automatic power window switch .......... 2-29
Hazard warning flasher switch ............. 2-22
Headlight and turn signal switch .......... 2-20
Overdrive switch.......................... 5-13, 5-14
Passenger supplemental air bag
ON/OFF switch and light ...................... 1-13
10-4
ZX
