2002 MERCEDES-BENZ CLK-CLASS climate control

2 ContentsMultifunction steering wheel,
multifunction display ................. 84
Trip and main odometer and sub
menu ............................................. 88
Audio systems .................................. 89
Radio .............................................. 89
CD player ....................................... 90
Cassette player ............................. 91
Telephone .......................................... 92
Telephone book ............................ 92
Redialing ....................................... 94
Incoming call ................................ 96
Navigation system ............................ 97
Trip computer ................................... 98
Malfunction/warning message
memory ...................................... 100
Individual settings ......................... 102
Setting the audio volume .............. 104
Flexible service system (FSS) ...... 105
Engine oil level indicator .............. 108
Engine oil consumption ................ 109
Exterior lamp switch ......................110
Night security illumination ..........111
Headlamp cleaning system .......... 112Combination switch ....................... 113
Hazard warning flasher switch .... 115
Automatic climate control ............. 116
Display and controls .................. 118
Basic setting ................................ 118
Economy ....................................... 119
Special settings ........................... 119
Rear window defroster .............. 120
Air recirculation .........................121
Residual engine heat
utilization .....................................121
Dust filter .................................... 122
Audio and telephone, operation .. 123
Power windows .............................. 142
Interior lighting ............................. 145
Sun visors ....................................... 146
Illuminated vanity mirrors .......... 146
Interior ............................................ 147
Storage compartments, armrest and
cup holder .................................. 147
Glove box ..................................... 147
Ashtray .............................................150
Lighter .............................................. 151
Cargo tie down rings .....................152Parcel net in front passenger
footwell ....................................... 152
Armrest, rear bench ...................... 152
Telephone, general ........................ 153
Cellular telephone ......................... 153
Garage door opener ....................... 154
Soft top ............................................ 158
Wind screen .................................... 166
Roller blind (horizontal) ............... 170
Roller blind (vertical) .................... 171
DrivingControl and operation of radio
transmitters ............................... 174
The first 1 000 miles
(1 500 km) ................................. 175
Maintenance ................................... 175
Catalytic converter ........................ 176
Emission control ............................ 177
Tele Aid ........................................... 178
Steering lock ................................... 188
Starting and turning off the
engine ......................................... 190
Automatic transmission ............... 191
ProCarManuals.com

17 Instruments and controls
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index For more detailed descriptions see Index on page 324.
For adjustment of air outlets, refer to automatic climate
control, see page 116.
1Side air outlet, adjustable
2Air volume control for side air outlet
3Exterior lamp switch, see page 110
4Parking brake release, see page 200
5Parking brake pedal, see page 200
6Hood lock release, see page 250
7Combination switch, see page 113
8Cruise control switch, see page 210
9Multifunction steering wheel, see page 84
Horn (with electronic key in steering lock
position 1 or 2)
10Instrument cluster, see page 78
11Voice control system lever, see separate operating
instructions
12Steering lock with ignition/starter
switch, see page 18813Center air outlets, adjustable
14Air volume control for center air outlets
15Left front seat heater switch, see page 51
16Headlamp washer switch, see page 112
17Roll bar switch, see page 48
Roll bar warning lamp, see page 229
18Hazard warning flasher switch, see page 115
19Central locking switch, see page 33
20Switch for tow-away alarm, see page 40
Indicator lamp for antitheft alarm system, see
page 39
21Right front seat heater switch, see page 51
22Automatic climate control, see page 116
Rear window defroster switch, see page 120
23Glove box (illuminated with electronic key in
steering lock position 1 or 2), see page 147
24Audio system, see page 123
25Storage compartment
26Ashtray with lighter, see page 150
ProCarManuals.com

21
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Navigation system ............................ 97
Trip computer ................................... 98
Malfunction/warning message
memory ...................................... 100
Individual settings ......................... 102
Setting the audio volume .............. 104
Flexible service system (FSS) ...... 105
Engine oil level indicator .............. 108
Engine oil consumption ................ 109
Exterior lamp switch ......................110
Night security illumination ..........111
Headlamp cleaning system .......... 112
Combination switch .......................113
Hazard warning flasher switch ....115
Automatic climate control .............116
Display and controls ...................118
Basic setting .................................118Economy ....................................... 119
Special settings ........................... 119
Rear window defroster .............. 120
Air recirculation .........................121
Residual engine heat
utilization .....................................121
Dust filter .................................... 122
Audio and telephone, operation .. 123
Power windows .............................. 142
Interior lighting ............................. 145
Sun visors ....................................... 146
Illuminated vanity mirrors .......... 146
Interior ............................................ 147
Storage compartments, armrest and
cup holder .................................. 147
Glove box ..................................... 147Ashtray ............................................ 150
Lighter ............................................. 151
Cargo tie down rings ..................... 152
Parcel net in front passenger
footwell ....................................... 152
Armrest, rear bench ...................... 152
Telephone, general ........................ 153
Cellular telephone ......................... 153
Garage door opener ....................... 154
Soft top ............................................ 158
Wind screen .................................... 166
Roller blind (horizontal) ............... 170
Roller blind (vertical) .................... 171
ProCarManuals.com

103 Multifunction steering wheel, multifunction display
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index 1Preliminary display of the individual settings
2“SET TIME HOURS”
(Only vehicles without COMAND)
3“SET TIME MINUTES”
(Only vehicles without COMAND)
4“12/24 HOURS” – the unit set is displayed in the
instrument cluster
(Only vehicles without COMAND)
5“TEMP. INDICATOR” – the unit set is displayed in
the outside temperature display in the instrument
cluster and in the automatic climate control display
6“DISPLAY VALUES IN” – the unit set is displayed in
the trip and main odometer
7“TEXT” – sets the language used in the
multifunction display8“STATION SEARCH USING” – radio adjustment
“FREQUENCY” – use the j or k button to
select a frequency
“MEMORY” – use the j or k button to select
a stored station (preset memory)
9See page 104 for instructions on returning the
setting menus to the factory settings
10Selection marker – indicates the setting selected
Notes:
These settings may only be performed with the vehicle
at standstill and with the key in steering lock position 1
or 2.
ProCarManuals.com

116 Automatic climate control
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Automatic climate control
P83.40-2157-29
1
3
36
2
4
*
*
Mercedes-Benz
D
O
L
BY
-S
TER
E
O
5
ProCarManuals.com

117 Automatic climate control
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index 1Air volume control for center air outlets, turn wheel
up to open.
2Air volume control for side air outlet.
To open air outlets: Turn wheel to position i.
3Center air outlet, adjustable
4Side air outlet, adjustable
5Display and controls
The system is always at operational readiness, except
when manually switched off.
The automatic climate control only operates with the
engine running.
The temperature selector should be left at the desired
temperature setting. The temperature selected is
reached as quickly as possible.The system will not heat or cool any quicker by setting a
higher or lower temperature.
The automatic climate control removes considerable
moisture from the air during operation in the cooling
mode. It is normal for water to drip on the ground
through ducts in the underbody.
The desired interior temperature can be selected
separately for the left and right side of the passenger
compartment.
Note:
If the individual settings (page 102) of the outside
temperature display is switched from °C to
°F or vice
versa, the automatic climate control returns to the
factory settings. Set temperature and activate S
mode.
ProCarManuals.com

118 Automatic climate control
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Display and controls
Press the desired button to activate, indicator lamp is on
while activated.
UAutomatic mode
fRaise temperature
gLower temperaturePDefrost
OAir recirculation
FRear window defroster
bAir distribution, manual
SEconomy mode
ïAir volume, manual
TResidual engine heat utilization
Basic setting - automatic mode
Press left and right U button for automatic mode.
Simultaneously press both f and g buttons for
temperature setting of 72
°F.
Air volume and distribution are controlled
automatically.
This setting can be used all year around.
0
MAX
ProCarManuals.com

119 Automatic climate control
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Economy
The function of this setting corresponds to the
automatic mode. However, because the air conditioning
compressor will not engage (fuel savings), it is not
possible to air condition in this setting.
Press S button to activate.
Press S button once again to return to previous
setting.
Special settings (use only for short duration)
Defogging windows
Switch off O button.
Press left and right U buttons.
Press button b repeatedly until air is directed
upward.
Turn wheels (2) to position i to open left and right
side air outlets (4). Adjust side air outlets upward.Defrosting
Turn wheels (2) to position i to open left and right
side air outlets (4). Adjust side air outlets upward.
Press P button. Maximum heated and automatically
controlled amount of air is directed to the windshield
and side windows.
Press P button once again to return to previous
setting.
ProCarManuals.com
