2002 MERCEDES-BENZ CLK-CLASS belt

1 Contents
IntroductionProduct information .......................... 6
Operator’s manual ............................. 7
Where to find it ................................ 12
Reporting Safety Defects ................ 14Instruments and controlsInstruments and controls ............... 16
Center console .............................. 18
Overhead control panel ............... 19OperationVehicle keys ...................................... 22
Start lock-out .................................... 24
General notes on the central locking
system ........................................... 24
Central locking system ................... 25
Radio frequency and infrared
remote control .............................. 25
Opening and closing windows from
outside ........................................... 29
Panic button .................................. 30Mechanical keys .......................... 30
Doors ..................................................31
Central locking switch .................... 33
Automatic central locking .......... 34
Emergency unlocking in case of
accident ........................................ 34
Trunk ................................................. 35
Trunk lamp ....................................... 36
Trunk lid release switch ................ 37
Trunk lid emergency release ........ 38
Antitheft alarm system ................... 39
Tow-away alarm ............................... 40
Power seats, front ............................. 41
Front head restraints .................. 46
Roll bar and head restraints,
rear ............................................... 47
Backrest ............................................ 49
Multicontour seat ............................ 50
Heated seats ......................................51
Seat belts and integrated restraint
system .......................................... 52
Seat belts .......................................... 53
Seat belt nonusage warning
system ............................................ 54BabySmart
TM airbag deactivation
system ........................................... 59
Self-test BabySmart
TM without
special child seat installed ......... 59
Supplemental restraint system
(SRS) ............................................. 60
Emergency tensioning device
(ETD) ............................................. 60
Airbags .............................................. 61
Safety guidelines for the seat belt,
emergency tensioning device and
airbag ............................................. 67
Infant and child restraint
systems .......................................... 69
Child seat anchors- "LATCH",
type ............................................... 71
Adjusting telescoping steering
column .......................................... 73
Inside rear view mirror .................. 74
Antiglare night position .............. 74
Exterior rear view mirrors ............. 75
Instrument cluster ........................... 78
Indicator lamps in the instrument
cluster ........................................... 80
ProCarManuals.com

3 ContentsParking brake .................................200
Driving instructions ...................... 201
Drive sensibly – save fuel ......... 201
Drinking and driving ................. 201
Pedals ........................................... 201
Power assistance ........................202
Brakes ..........................................202
Driving off ...................................203
Parking ........................................204
Tires .............................................204
Snow chains ................................207
Winter driving instructions ......207
Standing water ...........................209
Passenger compartment ...........209
Traveling abroad ........................209
Cruise control ................................. 210
Brake assist system (BAS) ............ 212
Antilock brake system (ABS) ....... 214
Electronic stability program
(ESP) ........................................... 216
What you should know at the gas
station .........................................220
Check regularly and before a long
trip ...............................................222
Instrument cluster displayMalfunction and indicator lamps in
the instrument cluster ............. 224
On-board diagnostic system Check
engine malfunction indicator
lamp ............................................. 224
Brake warning lamp .................. 225
Supplemental restraint system
(SRS) indicator lamp ................. 226
Fuel reserve and fuel cap
placement warning ................... 226
Electronic stability program (ESP)
— warning lamp .......................... 227
BAS/ESP malfunction indicator
lamp ............................................. 227
ABS malfunction indicator
lamp ............................................. 227
Telescoping steering column –
indicator lamp ............................ 228
Seat belt warning lamp ............. 228
Malfunction and indicator lamps in
the center console .................... 228
AIRBAG OFF indicator lamp .... 228
Roll bar warning lamp .............. 229Malfunction and warning messages
in the multifunction display ...230
DISPLAY DEFECTIVE (engine
control unit) ................................ 231
DISPLAY DEFECTIVE (several
systems) ....................................... 231
BATTERY/ALTERNATOR ...........232
ABS-SYSTEM ...............................233
BRAKE ASSIST ...........................233
BRAKE LINING WEAR ..............234
BRAKE FLUID .............................234
PARKING BRAKE .......................235
ENGINE FAN ...............................235
COOLANT (coolant level) ..........236
COOLANT TEMP. (coolant
temperature) ...............................237
LIGHTING SYSTEM ....................238
LIGHT SENSOR ...........................239
STEER. WHEEL ADJUST. ...........239
ENGINE OIL LEVEL ...................240
ELEC. STABIL. PROG. (Electronic
stability program) ...................... 241
REMOVE KEY ............................. 241
WASHER FLUID .........................242
ProCarManuals.com

4 ContentsTELE AID .....................................243
Practical hintsFirst aid kit .....................................246
Shelf below rear window ..............246
Stowing things in the vehicle ......246
Luggage cover .................................246
Fuses ................................................248
Hood .................................................250
Checking engine oil level .............252
Automatic transmission fluid
level .............................................253
Coolant level ...................................253
Adding coolant ...........................254
Windshield washer / headlamp
cleaning system .........................255
Windshield and headlamp washer
fluid mixing ratio .......................255
Spare wheel, vehicle tools, storage
compartment .............................256
Vehicle jack .....................................257
Wheels .............................................258
Tire replacement ........................258
Rotating wheels ..........................259Spare wheel .................................... 260
Spare wheel bolts .......................... 260
Spare wheel bolts ...................... 260
Spare wheel .................................... 260
Changing wheels ........................... 263
Tire inflation pressure ................. 268
Battery ............................................. 270
Jump starting ..................................271
Towing the vehicle ........................ 273
Exterior lamps ............................... 277
Headlamp assembly .................. 278
Taillamp assemblies .................. 280
Adjusting headlamp aim .............. 282
Changing batteries in the electronic
key .............................................. 285
Synchronizing remote
control ........................................ 287
Raising soft top manually ............ 288
Antenna .......................................... 295
Manual release for fuel filler
flap .............................................. 296
Replacing wiper blade insert ...... 296
Vehicle careCleaning and care of the
vehicle ........................................300
Power washer .............................. 301
Paintwork, painted body
components ................................. 301
Engine cleaning ..........................302
Tar stains .....................................302
Vehicle washing .........................302
Ornamental moldings ................302
Headlamps, taillamps, turn signal
lenses ...........................................303
Window cleaning .......................303
Plastic and rubber parts ............303
Wiper blade .................................303
Light alloy wheels ......................303
Instrument cluster .....................304
Steering wheel and gear selector
lever ..............................................304
Cup holder ...................................304
Seat belts .....................................304
Headliner .....................................304
Upholstery ...................................305
ProCarManuals.com

5 ContentsHard plastic trim items .............305
Plastic and rubber parts ............305
Wind screen ...............................305
Rubber weatherstrip .................305
Soft top .........................................306
Technical dataSpare parts service ....................... 308
Warranty coverage ........................ 308
Identification labels ...................... 309
Layout of poly-V-belt drive ............ 310
Technical data ................................. 311
Fuels, coolants, lubricants etc. –
capacities .................................... 316
Engine oils ....................................... 318
Engine oil additives ....................... 318
Air conditioner refrigerant ........... 318
Brake fluid ....................................... 318
Premium unleaded gasoline ......... 319
Fuel requirements ......................... 319
Gasoline additives ......................... 320
Coolants .......................................... 320
Consumer information ................. 322
IndexIndex ................................................324
ProCarManuals.com

20
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
OperationVehicle keys ...................................... 22
Start lock-out .................................... 24
General notes on the central locking
system ........................................... 24
Central locking system ................... 25
Radio frequency and infrared
remote control .............................. 25
Opening and closing windows from
outside ........................................... 29
Panic button .................................. 30
Mechanical keys ........................... 30
Doors .................................................. 31
Central locking switch .................... 33
Automatic central locking .......... 34
Emergency unlocking in case of
accident ........................................ 34
Trunk ................................................. 35
Trunk lamp ....................................... 36
Trunk lid release switch ................. 37
Trunk lid emergency release ......... 38
Antitheft alarm system ................... 39
Tow-away alarm ................................ 40Power seats, front ............................. 41
Front head restraints .................. 46
Roll bar and head restraints,
rear ............................................... 47
Backrest ............................................ 49
Multicontour seat ............................ 50
Heated seats ......................................51
Seat belts and integrated restraint
system .......................................... 52
Seat belts .......................................... 53
Seat belt nonusage warning
system ............................................ 54
BabySmart
TM airbag deactivation
system .......................................... 59
Self-test BabySmart
TM without
special child seat installed ......... 59
Supplemental restraint system
(SRS) ............................................. 60
Emergency tensioning device
(ETD) ............................................ 60
Airbags ............................................... 61
Safety guidelines for the seat belt,
emergency tensioning device and
airbag ............................................. 67Infant and child restraint
systems .......................................... 69
Child seat anchors- "LATCH",
type ............................................... 71
Adjusting telescoping steering
column .......................................... 73
Inside rear view mirror .................. 74
Antiglare night position .............. 74
Exterior rear view mirrors ............. 75
Instrument cluster ........................... 78
Indicator lamps in the instrument
cluster ........................................... 80
Multifunction steering wheel,
multifunction display ................. 84
Trip and main odometer and sub
menu ............................................. 88
Audio systems .................................. 89
Radio .............................................. 89
CD player ....................................... 90
Cassette player ............................. 91
Telephone .......................................... 92
Telephone book ............................ 92
Redialing ....................................... 94
Incoming call ................................ 96
ProCarManuals.com

41 Seats
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Power seats, front
To operate the front power seat adjustment switches,
turn electronic key in steering lock to position 1 or 2
(with the driver’s or passenger’s door open, the power
seats can also be operated with the electronic key
removed or in steering lock position 0).
Wa r n i n g !
Do not adjust the driver’s seat while driving.
Adjusting the seat while driving could cause the
driver to lose control of the vehicle.Never ride in a moving vehicle with the backrest
reclined. Sitting in an excessively reclined position
can be dangerous. You could slide under the seat
belt in a collision. If you slide under it, the belt
would apply force at the abdomen or neck. That
could cause serious or even fatal injuries. The
backrest and seat belt provide the best restraint
when the wearer is in an upright position and the
belt is properly positioned on the body.Never place hands under seat or near any moving
parts while a seat is being adjusted.
Wa r n i n g !
When leaving the vehicle, always remove the
electronic key from the steering lock, and lock your
vehicle.The power seats can also be operated with the
driver’s or passenger door open. Do not leave
children unattended in the vehicle or with access
to an unlocked vehicle. Unsupervised use of vehicle
equipment may cause an accident and/or serious
personal injury.
ProCarManuals.com

45 Seats
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Important!
Prior to operating the vehicle, the driver should adjust
the seat height for proper vision as well as fore/aft
placement and backrest angle to insure adequate
control, reach, operation, and comfort. The head
restraint should also be adjusted for proper height. See
also airbag section on page 61 for proper seat
positioning.
In addition, also adjust the steering wheel to ensure
adequate control, reach, operation, and comfort.
Both the inside and outside rear view mirrors should be
adjusted for adequate rearward vision.
Fasten seat belts. Infants and small children should be
seated in a properly secured restraint system that
complies with U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and Canadian Motor Vehicle
Safety Standards 213 and 210.2.
All seat, head restraint, steering wheel, and rear view
mirror adjustments as well as fastening of seat belts
should be done before the vehicle is put into motion.
Wa r n i n g !
Children 12 years old and under must never ride in
the front seat, except in a Mercedes-Benz
authorized BabySmart
TM compatible child seat,
which operates with the BabySmart
TM system
installed in the vehicle to deactivate the passenger
side front airbag when it is properly installed.
Otherwise they will be struck by the airbag when it
inflates in a crash. If this happens, serious or fatal
injury can result.
According to accident statistics, children are safer
when properly restrained in the rear seating
positions than in the front seating positions.
Infants and small children must ride in back seats
and be seated in an appropriate infant or child
restraint system, which is properly secured with
the vehicle's seat belt or lower anchors, fully in
accordance with the child seat manufacturer’s
instructions.A child’s risk of serious or fatal injuries is
significantly increased if the child restraints are
not properly secured in the vehicle and the child is
not properly secured in the child restraint.
ProCarManuals.com

48 Seats
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Switch for roll bar and head restraints, rear
The switch is located in the center console.
Turn electronic key in steering lock to position 2.
Press switch:
1Raise roll bar
2Lower roll bar
The lowering or raising procedure is immediately
interrupted by releasing the roll bar switch. With the engine running and the roll bar lowered, the
warning lamp in the roll bar switch will blink for
approx. 15 seconds. The blinking is reminding you to
raise the roll bar if the rear passenger seats are
occupied. See also page 229 for roll bar warning lamp.
Important!
The roll bar is intended to be a safety enhancement to
the other features designed into the vehicle. No system
in any vehicle can eliminate the possibility of serious
injury or fatality in an accident. Properly fastened seat
belts and child restraints must be used!
Notes:
If the warning lamp in the switch comes on, then a
malfunction has been detected. In this case, drive only
with the roll bar raised until the problem has been
corrected. Raise the roll bar by pressing the upper half
of the roll bar switch.
Have the system checked at your authorized
Mercedes-Benz Center as soon as possible.
Items being transported in the rear passenger
compartment should be placed in such a manner as not
to affect the movement of the roll bar when being
raised.
P91.59-2001-26
12
ProCarManuals.com
