2002 MERCEDES-BENZ CLK-CLASS alarm

1 Contents
IntroductionProduct information .......................... 6
Operator’s manual ............................. 7
Where to find it ................................ 12
Reporting Safety Defects ................ 14Instruments and controlsInstruments and controls ............... 16
Center console .............................. 18
Overhead control panel ............... 19OperationVehicle keys ...................................... 22
Start lock-out .................................... 24
General notes on the central locking
system ........................................... 24
Central locking system ................... 25
Radio frequency and infrared
remote control .............................. 25
Opening and closing windows from
outside ........................................... 29
Panic button .................................. 30Mechanical keys .......................... 30
Doors ..................................................31
Central locking switch .................... 33
Automatic central locking .......... 34
Emergency unlocking in case of
accident ........................................ 34
Trunk ................................................. 35
Trunk lamp ....................................... 36
Trunk lid release switch ................ 37
Trunk lid emergency release ........ 38
Antitheft alarm system ................... 39
Tow-away alarm ............................... 40
Power seats, front ............................. 41
Front head restraints .................. 46
Roll bar and head restraints,
rear ............................................... 47
Backrest ............................................ 49
Multicontour seat ............................ 50
Heated seats ......................................51
Seat belts and integrated restraint
system .......................................... 52
Seat belts .......................................... 53
Seat belt nonusage warning
system ............................................ 54BabySmart
TM airbag deactivation
system ........................................... 59
Self-test BabySmart
TM without
special child seat installed ......... 59
Supplemental restraint system
(SRS) ............................................. 60
Emergency tensioning device
(ETD) ............................................. 60
Airbags .............................................. 61
Safety guidelines for the seat belt,
emergency tensioning device and
airbag ............................................. 67
Infant and child restraint
systems .......................................... 69
Child seat anchors- "LATCH",
type ............................................... 71
Adjusting telescoping steering
column .......................................... 73
Inside rear view mirror .................. 74
Antiglare night position .............. 74
Exterior rear view mirrors ............. 75
Instrument cluster ........................... 78
Indicator lamps in the instrument
cluster ........................................... 80
ProCarManuals.com

17 Instruments and controls
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index For more detailed descriptions see Index on page 324.
For adjustment of air outlets, refer to automatic climate
control, see page 116.
1Side air outlet, adjustable
2Air volume control for side air outlet
3Exterior lamp switch, see page 110
4Parking brake release, see page 200
5Parking brake pedal, see page 200
6Hood lock release, see page 250
7Combination switch, see page 113
8Cruise control switch, see page 210
9Multifunction steering wheel, see page 84
Horn (with electronic key in steering lock
position 1 or 2)
10Instrument cluster, see page 78
11Voice control system lever, see separate operating
instructions
12Steering lock with ignition/starter
switch, see page 18813Center air outlets, adjustable
14Air volume control for center air outlets
15Left front seat heater switch, see page 51
16Headlamp washer switch, see page 112
17Roll bar switch, see page 48
Roll bar warning lamp, see page 229
18Hazard warning flasher switch, see page 115
19Central locking switch, see page 33
20Switch for tow-away alarm, see page 40
Indicator lamp for antitheft alarm system, see
page 39
21Right front seat heater switch, see page 51
22Automatic climate control, see page 116
Rear window defroster switch, see page 120
23Glove box (illuminated with electronic key in
steering lock position 1 or 2), see page 147
24Audio system, see page 123
25Storage compartment
26Ashtray with lighter, see page 150
ProCarManuals.com

20
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
OperationVehicle keys ...................................... 22
Start lock-out .................................... 24
General notes on the central locking
system ........................................... 24
Central locking system ................... 25
Radio frequency and infrared
remote control .............................. 25
Opening and closing windows from
outside ........................................... 29
Panic button .................................. 30
Mechanical keys ........................... 30
Doors .................................................. 31
Central locking switch .................... 33
Automatic central locking .......... 34
Emergency unlocking in case of
accident ........................................ 34
Trunk ................................................. 35
Trunk lamp ....................................... 36
Trunk lid release switch ................. 37
Trunk lid emergency release ......... 38
Antitheft alarm system ................... 39
Tow-away alarm ................................ 40Power seats, front ............................. 41
Front head restraints .................. 46
Roll bar and head restraints,
rear ............................................... 47
Backrest ............................................ 49
Multicontour seat ............................ 50
Heated seats ......................................51
Seat belts and integrated restraint
system .......................................... 52
Seat belts .......................................... 53
Seat belt nonusage warning
system ............................................ 54
BabySmart
TM airbag deactivation
system .......................................... 59
Self-test BabySmart
TM without
special child seat installed ......... 59
Supplemental restraint system
(SRS) ............................................. 60
Emergency tensioning device
(ETD) ............................................ 60
Airbags ............................................... 61
Safety guidelines for the seat belt,
emergency tensioning device and
airbag ............................................. 67Infant and child restraint
systems .......................................... 69
Child seat anchors- "LATCH",
type ............................................... 71
Adjusting telescoping steering
column .......................................... 73
Inside rear view mirror .................. 74
Antiglare night position .............. 74
Exterior rear view mirrors ............. 75
Instrument cluster ........................... 78
Indicator lamps in the instrument
cluster ........................................... 80
Multifunction steering wheel,
multifunction display ................. 84
Trip and main odometer and sub
menu ............................................. 88
Audio systems .................................. 89
Radio .............................................. 89
CD player ....................................... 90
Cassette player ............................. 91
Telephone .......................................... 92
Telephone book ............................ 92
Redialing ....................................... 94
Incoming call ................................ 96
ProCarManuals.com

24 Central locking system
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Start lock-out
Important!
Removing the electronic key from the steering lock
activates the start lock-out. The engine cannot be
started.
Inserting the electronic key in the steering lock
deactivates the start lock-out.
Note:
In case the engine cannot be started (vehicle’s battery is
in order), the system is not operational. Contact an
authorized Mercedes-Benz Center or call 1-800-FOR-
MERCedes (in the USA) or 1-800-387-0100 (in Canada).General notes on the central locking system
If the electronic key is inserted in the steering lock, the
vehicle cannot be locked or unlocked with the remote
control.
If the vehicle cannot be locked or unlocked:
•Aim transmitter eye at a receiver of either door
handle. Check the batteries of the electronic key, see
page 285, or synchronize the remote control, see
page 287.
•Use the mechanical key to unlock the driver’s door.
To start the engine, insert the electronic key in the
steering lock. There could be a slight delay until the
electronic key can be turned in the steering lock.
Important!
When unlocking the driver’s door with the mechanical
key, the exterior lamps will flash and the alarm will
sound.
To cancel the alarm, insert the electronic key in the
steering lock or press buttonŒ or‹ on the
electronic key.
ProCarManuals.com

30 Central locking system
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Panic button
To activate press and hold button (1) for at least one
second. An audible alarm and blinking exterior lamps
will operate for approximately 3 minutes.
To deactivate press button (1) again, or insert electronic
key in steering lock.Note:
For operation in the USA only: This device complies
with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Any unauthorized modification to this device could void
to the user’s authority to operate the equipment.
Mechanical keys
The mechanical keys work only in the driver’s door,
trunk, and storage compartment locks.
Notes:
The mechanical key does not operate the central locking
system or antitheft alarm system.
The fuel filler flap cannot be locked or unlocked with
the mechanical key.
P80.35-2035-26
1
ProCarManuals.com

31 Central locking system
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Doors
1Opening – pull handle
2Unlocking driver’s door
3Locking driver’s door
4Individual door from inside:
•Push lock button down to lock.
•Pull inside door handle to unlock.Important!
The mechanical key does not operate the central locking
system or antitheft alarm system.
When you lock the driver’s door with the mechanical
key, the door lock button should move down.
The passenger door must be locked with the door lock
button – the driver’s door can only be locked when it is
closed.
1
1 2 3
ProCarManuals.com

32 Central locking system
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
If the vehicle has previously been locked from the
outside, opening a door from the inside will trigger the
alarm. When opening a door while the central locking
system is in the:
•selective unlocking mode, only that individual door
is unlocked. The remaining door, the trunk and fuel
filler flap remain locked,
•global unlocking mode, both doors, the trunk and
fuel filler flap are unlocked.
Notes:
When opening a door, the door window lowers slightly.
After closing the door, the window closes again.
In case of a malfunction in the central locking system
the doors can be locked and unlocked individually.To lock, push down lock button and turn mechanical key
in driver’s door lock to position 3. In addition lock the
trunk.
To unlock, pull inside door handle and turn mechanical
key in driver’s door lock to position 2.
When unlocking the driver’s door with the mechanical
key, the exterior lamps will flash and the alarm will
sound.
To cancel the alarm, insert the electronic key in the
steering lock or press buttonŒ or‹ on the
electronic key.
ProCarManuals.com

33 Central locking system
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Central locking switch
1Locking
2Unlocking
The central locking switch is located in the center
console.
The doors and trunk can only be locked with the central
locking switch, if both doors are closed.
If the vehicle was previously locked with the central
locking switch, while in the selective remote control
mode, only the door opened from the inside is unlocked.If the vehicle was previously locked with the central
locking switch, while in the global remote control mode,
the complete vehicle is unlocked when a door is opened
from the inside.
Notes:
If the vehicle was previously locked with the remote
control, the doors and trunk cannot be unlocked with
the central locking switch.
If the vehicle has previously been locked from the
outside, opening a door with the inside door handle will
trigger the alarm. To cancel the alarm, insert the
electronic key in the steering lock or press buttonŒ
or‹ on the electronic key.
The fuel filler flap cannot be locked or unlocked with
the central locking switch.
Wa r n i n g !
When leaving the vehicle, always remove the
electronic key from the steering lock, and lock your
vehicle. Do not leave children unattended in the
vehicle, or with access to an unlocked vehicle.
Unsupervised use of vehicle equipment may cause
an accident and/or serious personal injury.
ProCarManuals.com
