313 Technical data
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
1 Also permissible 225/45 ZR 17
2 Also permissible 245/40 ZR 17
3
3 Must not be used with snow chains.4 Also permissible 245/40 ZR 17 91 Y.
3
Model CLK 430
Rims front axle
(AMG light alloy)
Wheel offset:7
1/2 J x 17 H 2
1.46 in (37 mm)
Rims rear axle
(AMG light alloy)
Wheel offset:8
1/2 J x 17 H 2
1.18 in (30 mm)
Radial-ply tires:
summer tires, front axle
summer tires, rear axle225/45 R 17 91 W
1
245/40 R 17 91 W
2, 3, 4
Spare wheel
Rim (light alloy)
Wheel offset:7
1/2 J x 17 H 2
1.46 in (37 mm)
Summer tire:
Radial-ply tire 225/45 R 17 91 W
1
ProCarManuals.com
333 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex Shelf below rear window ..............................................246
Side marker lamp .......................................................... 281
Snow chains .................................................................... 207
Soft top ............................................................................ 158
Emergency operation ...............................................288
Lowering ..................................................................... 160
Raising ........................................................................ 162
SOS-call
See Tele Aid ............................................................... 178
Spare parts service ........................................................ 308
Spare wheel ........................................................... 256, 260
Spare wheel bolts ..........................................................260
Special settings (Automatic climate control) ............. 119
SRS indicator lamp ........................................................ 226
SRS malfunction .............................................................. 62
Start lock-out..................................................................... 24
Starting and turning off the engine ............................ 190
STEER. WHEEL ADJUST. - malfunction and
warning messages ........................................................ 239
Steering column, adjustable ........................................... 73
Steering lock ................................................................... 188
Storage compartment
Trunk floor ................................................................. 256
Storage compartments
Center console ........................................................... 148
Glove box .................................................................... 147Storage compartments, armrest and cup holder ....... 147
Stowing things in the vehicle...................................... 246
Sun visors ........................................................................ 146
Supplemental restraint system (SRS) ........................... 60
Synchronizing remote control .................................... 287
TTachometer ........................................................................ 83
Technical data ................................................................. 311
Electrical system ....................................................... 314
Main dimensions ...................................................... 315
Rims and tires ........................................................... 312
Weights ....................................................................... 315
Tele Aid ............................................................................ 178
Emergency calls ........................................................ 179
Information ................................................................ 183
Initiating an emergency call manually .................. 181
Roadside Assistance ................................................. 182
TELE AID - malfunction and
warning messages ........................................................ 243
Telephone .......................................................................... 92
General notes ............................................................. 153
Incoming call ............................................................... 96
Redialing....................................................................... 94
