Page 50 of 240
3. At the back of the headlamp, pull
back and up slightly on the two
retainer pins to release the
headlamp assembly from the vehicle
and pull headlamp forward.
4. Rotate the bulb socket
counterclockwise and remove from
lamp assembly.
5. Carefully pull bulb straight out of
the socket and push in the new
bulb.
6. To complete installation, follow
the removal procedure in reverse
order.
Replacing license plate lamp bulbs
1. Remove two screws, grommets
and the license plate lamp assembly
from the trunk lid.
2. Carefully pull the bulb from the
socket and push in the new bulb.
3. Install the lamp assembly on
trunk lid with two grommets,
ensuring the grommets are pushed
all the way in to the trunk lid and
secure with two screws.
Lights
50
Page 51 of 240
Replacing high-mount brakelamp bulbs
1. Open luggage compartment.
Note the number of the pin-type
retainers before removal.
2. Remove the pin-type retainers
from the lower back trim panel.
3. Carefully pull down the lower
back trim panel.
4. Lower the bracket and module
tray assembly.
Lights
51
Page 52 of 240
5. Carefully remove the bulb socket
from the lamp assembly.
6. Carefully pull the bulb from the
socket and push in the new bulb.
To install, reverse the removal
procedure.
Replacing backup lamp bulbs
For bulb replacement, see a dealer or qualified technician.
Replacing tail lamp/turn lamp bulbs
For bulb replacement, see a dealer or qualified technician.
Lights
52
Page 236 of 240
dipstick ....................................194
filter, specifications ........196, 224
recommendations ...................196
refill capacities ........................224
specifications ..................226±227
Exhaust fumes ..........................137
F
Floor mats ...................................57
Fluid capacities .........................224
Fuel ............................................204
calculating fuel economy .85, 209
cap ...........................................206
capacity ...................................224
choosing the right fuel ...........207
comparisons with EPA fuel
economy estimates .................212
detergent in fuel .....................208
filling your vehicle with
fuel ...........................204, 206, 209
filter, specifications ........209, 224
fuel filler door override ............89
fuel filler door release ..............89
fuel pump shut-off switch .....155
gauge .........................................15
improving fuel economy ........209
octane rating ...................207, 227
quality ......................................208
running out of fuel .................208
safety information relating to
automotive fuels .....................204
Fuses ..................................156±157
G
Garage door opener ....................68
Gas cap (see Fuel cap) ............206Gas mileage (see Fuel
economy) ...................................209
Gauges .........................................14
engine coolant temperature
gauge .........................................14
fuel gauge ..................................15
odometer ...................................15
speedometer .............................15
tachometer ................................15
GAWR (Gross Axle Weight
Rating) .......................................148
definition .................................148
driving with a heavy load ......148
location ....................................148
GVWR (Gross Vehicle Weight
Rating) .......................................148
calculating ...............................148
definition .................................148
driving with a heavy load ......148
location ....................................148
H
Hazard flashers .........................155
Head restraints .........................103
Headlamps ...................................40
aiming ..................................42±43
autolamp system .......................41
bulb specifications ....................46
daytime running lights .............40
flash to pass ..............................41
high beam ...........................13, 40
replacing bulbs .........................47
turning on and off ..............13, 40
warning chime ..........................13
Heating ........................................33
HomeLink universal
transceiver (see Garage door
opener) ............................68, 70±71
Index
236
Page 237 of 240
Hood ..........................................192
I
Ignition ...............................133, 227
Infant seats (see Safety
seats) .........................................126
Inspection/maintenance (I/M)
testing ........................................213
Instrument panel
cleaning ...................................187
cluster ................................10, 188
lighting up panel and
interior .......................................41
J
Jack ............................................163
positioning ...............................163
storage .....................................163
Jump-starting your vehicle ......167
K
Keyless entry system .................94
autolock .....................................97
keypad .......................................94
programming entry code .........95
Keys .........................87, 97±98, 100
key in ignition chime ...............14
positions of the ignition .........133
L
Lamps
autolamp system .......................41
bulb replacement
specifications chart ..................46
cargo lamps ...............................41
daytime running light ...............40headlamps .................................40
headlamps, flash to pass ..........41
instrument panel, dimming .....41
interior lamps .....................45, 47
replacing bulbs ....... 46±47, 49±52
Lane change indicator (see
Turn signal) .................................44
Lights, warning and indicator ....10
air bag ........................................12
anti-lock brakes (ABS) ....11, 139
brake ..........................................11
charging system ........................12
high beam .................................13
oil pressure ...............................12
safety belt .................................12
service engine soon ..................10
traction control active ..............12
turn signal indicator .................13
Load limits .................................148
GAWR ......................................148
GVWR ......................................148
trailer towing ..........................148
Locks
autolock .....................................97
childproof ..................................87
doors ..........................................87
Lubricant specifications ...226±227
Lug nuts, anti-theft ...................166
Lumbar support, seats .............105
M
Message center ...............76, 78, 84
air leveling disabled .................76
air ride switch off .....................76
check air ride system ...............76
check air suspension ................76
menu button .............................83
reset button ..............................84
Index
237
