2002 LINCOLN BLACKWOOD power tonneau

Power tonneau cover controls
The operation of the left and right
tonneau cover controls are identical.
Press the
portion of the control
to fully open the power tonneau
cover.
Press the
portion of the control
to fully close the power tonneau.
To disable the tonneau cover
controls when using your valet key,
lock the key switch in the center
console with your master key.
Courtesy/map lamps
The courtesy lamp lights when:
²any door is opened.
²the instrument panel dimmer
switch is held up until the
courtesy lamps come on.
²the remote entry controls are
pressed and the ignition is OFF.
To turn on the map lamps, press the
control next to each lamp.
ROOF
ROOF
Controls and features
63

The outside edge of the tonneau cover, or the top edge of the
pickup box, must remain clear of excessive ice, snow, dirt, or
other debris to ensure proper closure of the tonneau cover and prevent
damage to the vehicle.
NOTE:Slide-in campers cannot be installed on this vehicle.
PICKUP BOX STORAGE COMPARTMENT
The storage compartments are located inside the pickup box.
1. To open, push the button on the
storage compartment to pop up the
knob.
2. Turn knob counterclockwise to
unlock and pull the storage
compartment open.
3. To close, follow steps 1 and 2 in
reverse order.
POWER HARD TONNEAU COVER
The tonneau cover has been designed to enclose the cargo area.
To avoid damage to the cover, do not operate the vehicle unless the
cover is fully secured.
Controls and features
74

Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
The remote entry system allows you to:
²lock or unlock all vehicle doors without a key.
²open the power tonneau cover.
²activate the personal alarm.
The remote entry and power tonneau cover feature will operate with the
vehicle in P (Park) or N (Neutral) and the ignition in any position. The
panic control feature only operates with the ignition in the OFF position.
If there is any potential remote keyless entry problem with your vehicle,
ensureALL key fobs(remote entry transmitters) are brought to the
dealership, to aid in troubleshooting.
Unlocking the doors
Press this control to unlock the
driver door. The interior lamps will
illuminate.
The memory mirrors/seat will also
be moved to position 1, 2 or 3
depending upon which remote entry
transmitter (1, 2 or 3) is used.
Press the control a second time
within three seconds to unlock all
doors.
Opening power tonneau cover
Press the right control to open the
power tonneau cover.
Press the left control to close the
power tonneau cover.
Controls and features
81

Locking the doors
Press this control to lock all doors.
The doors will lock and the lamps
will flash.
To confirm doors are closed and
locked, press this control a second
time within three seconds. The
door(s) will lock again, the horn will
chirp once and the lamps will flash.
If any of the doors or tonneau cover
are open or ajar, the horn will make
two quick chirps, reminding you to properly close the doors and tonneau
cover.
Power door trim switch inhibit
Twenty seconds after the ignition is OFF and the doors are closed and
locked, the power door switch UNLOCK function will not work (the
LOCK function will still work).
The UNLOCK function will operate again after the door becomes ajar,
the ignition is turned ON or a valid UNLOCK command is received from
the key fob or key pad.
Deactivating/activating power door trim switch inhibit
1. Turn the ignition key to ON, then
press the UNLOCK button 3 times.
2. Turn the ignition key to OFF,
then press the UNLOCK button 3
times.
3. Turn the ignition key to ON,
within five seconds press the LOCK
button 2 times.
The user should receive 2horn
chirpsto indicate the system has
been disabled or 2 chirps followed by a honk to indicate the system has
been enabled.
Pressing the power door UNLOCK/LOCK button 2 times again will toggle
the trim switch inhibit states.
Turn ignition to OFF to exit programming.
UL
Controls and features
82

Autolock
This feature automatically locks all vehicle doors when:
²all doors are closed
²the engine is running
²you shift into any gear putting the vehicle motion.
Relock
The autolock feature repeats when:
²any door, except the drivers, is opened then closed while the engine is
running and
²you put the vehicle in motion.
Deactivating/activating the autolock feature
Before following the procedure, make sure that the ignition is OFF and
all vehicle doors and the tonneau cover are closed.
You must complete steps 1-7 within 30 seconds or the procedure will
have to be repeated. If the procedure needs to be repeated, you must
wait 30 seconds.
1. Turn the ignition key to ON.
2. Press the power door unlock control three times.
3. Turn the ignition key from ON to OFF.
4. Press the power door unlock control three times.
5. Turn the ignition back to ON. The horn will chirp.
6. Press the unlock control, then press the lock control. The horn will
chirp once if autolock was deactivated or twice (one short and one long
chirp) if autolock was activated.
7. Turn the ignition to OFF. The horn will chirp once to confirm the
procedure is complete.
Illuminated entry
The illuminated entry system will turn on the interior lights when the
remote transmitter unlock control is pressed.
The illuminated entry system will turn off the interior lights if the
ignition switch is turned to the ON position, or if the remote transmitter
lock control is pressed, or after 25 seconds of illumination.
Controls and features
85

The inside lights will not turn off if:
²they have been turned on with the dimmer control or
²any door is open or
²the power tonneau cover is open.
The battery save feature will turn off the interior lights 45 minutes after
the last door is closed, even if the dimmer control is on.
Memory seat/mirrors/adjustable pedal feature
The memory feature allows automatic positioning of the driver seat, side
mirrors and adjustable pedals to three programmable positions.
²To program position one, move the driver seat, both side mirrors, and
adjustable pedals to the desired positions. Press the SET control. The
SET control indicator light will briefly illuminate. While the light is
illuminated, press control 1.
²To program position two, repeat the previous procedure using control
2.
²To program position three, repeat the previous procedure but press
controls 1 and 2 simultaneously.
The memory feature also allows you to recall previously stored positions
with your remote transmitter(s). Up to three remote transmitters can be
activated to utilize the memory recall positions.
Press the memory feature control to move to the previously stored
seat/mirror/adjustable pedal positions.
Activating/deactivating the memory feature on your remote
transmitter
The memory feature from the remote transmitter can be turned off/on,
however, the memory control buttons will continue to operate. Before
following the procedure, make sure that the ignition is OFF and all doors
are closed. You must complete steps 1±7 within 30 seconds or the
procedure will have to be repeated. If the procedure needs to be
repeated, you must wait 30 seconds.
1. Turn the ignition key to ON.
2. Press the power door unlock control three times.
3. Turn the ignition key from ON to OFF.
4. Press the power door unlock control three times.
Controls and features
86

5. Turn the ignition back to ON. The horn will chirp.
6. Press the power door unlock control two times, then press the power
lock control once. The horn will chirp twice if the memory feature was
deactivated or three times (two short and one long chirp) if the memory
feature was activated.
7. Turn ignition to OFF. The horn will chirp once to confirm the
procedure is complete.
KEYLESS ENTRY SYSTEM
With the keyless entry keypad, you can:
²lock or unlock the vehicle doors without using the key.
²open the tonneau cover.
Your vehicle has a factory set 5 digit code that operates the keyless entry
system. You can also program your own 5 digit personal entry code. The
factory-set code is located:
²on the owner's wallet card in the glove compartment
²taped to the computer module
²or at your dealer.
When pressing the controls on the keyless entry keypad, press the
middle of the controls to ensure a good activation.
Anti-scan feature
The keyless entry pad is disabled for
1 minute after 7 unsuccessful
attempts at entering a valid key
code. The keypad will flash during
this 1 minute mode. However, the 7/8 and 9/0 controls will still lock the
vehicle.
Anti-scan will turned off after:
²one minute of keypad inactivity
²the keyfob UNLOCK button is pressed.
²the ignition is turned to the ON position
123
45678
90
Controls and features
87

Opening/closing the tonneau cover with the keyless entry system
To open the tonneau cover, enter
the factory set code or personal
code (driver door unlocks) and
press the 5/6 control within five
seconds.
To close the tonneau cover, enter
the factory set code or personal
code (driver door unlocks) and
press the 9/0 control within five
seconds.
Locking the doors with the keyless entry system
It is not necessary to enter the
factory or personal code prior to
locking all doors. To lock the doors:
²Press the 7/8 control and the 9/0
control at the same time.
Activating/deactivating autolock with the keyless entry system
Before following the activation or deactivation procedures, make sure
that the anti-theft system (if equipped) is not armed, ignition is off, and
all vehicle doors and power tonneau cover are closed.
1. Enter 5 digit entry code
2. Press and hold 7/8 control
3. Press and release 3/4 control while holding 7/8 control
4. Release 7/8 control.
The horn will chirp once if autolock was deactivated or twice (one short
and one long chirp) if autolock was activated.
To re-activate autolock, repeat steps 1±4.
123
45678
90
123
45678
90
123
45678
90
