SECTION 1 ± 4
47
INSTRUMENTS AND CONTROLS
Interior equipment
Vanity mirrors48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Interior lights 49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Personal lights 49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Ignition switch light 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Clock 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . .
Outside temperature display 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlet 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Glove box 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Garage door opener 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Cup holders 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Warning reflector holder 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tie±down hooks 59
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Floor mat 59
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
First±aid kit holder 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Luggage stowage precautions 61
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INTERIOR EQUIPMENT
51
OUTSIDE TEMPERATURE DISPLAY
SV14006

Vehicles sold in U.S.A.
SS14009

Vehicles sold in Canada
This display shows the outside temperature when the
ignition switch is on.The displayed temperature ranges from ±30
C (±22F) up to
50 C (122 F). The display flashes for 10 seconds when the
outside temperature goes down below 3 C (37F) or less and
informs you that the outside temperature is low. The warning
is repeated whenever the temperature rises to at least +5 C
(+41 F) and then sinks again to +3 C ( 3 7 F). If the
temperature does not appear on the display or it shows º± ±º,
take your vehicle to your Lexus dealer.
CAUTION
The outside air temperature indicator is designed to
inform you when the air temperature is near freezing.
This indicator does not detect the presence of ice on the
road. Drivers must exercise great caution in driving on
roads which are wet, slippery or icy.

INTERIOR EQUIPMENT
57
FCC ID: CB2V94800
CANADA: 1763 102 264
This device complies with FCC Rules Part 15.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
that may be received, including interference that
may cause undesired operation. WARNING: This
transmitter has been tested and complies with
FCC and DOC/MDC rules. Changes or
modifications not expressly approved by the
party responsible for compliance could void the
user's authority to operate the device.
CUP HOLDERS
SS14015

Front
To use the cup holder, open the cup holder lid.
You can use it as an accessory box by removing the holder
inside.

INTERIOR EQUIPMENT
58
SS14018

Rear
To use the cup holder, push the cup holder portion of the
center console box.
The cup holder is designed for holding cups or drink±cans
securely in its holes.
CAUTION
Do not place anything else other than cups or
drink±cans in the cup holder, as such items may be
thrown about in the compartment and possibly injure
people in the vehicle during sudden braking or in an
accident.
 Rear only: To reduce the chance of injury in case of
an accident or sudden stop while driving, keep the
cup holder closed when not in use.
WARNING REFLECTOR HOLDER
SS14092

1To loosen 2To tighten
This belt is designed to hold the warning reflector.
To loosen: Pull the buckle forward.
To tighten: Pull on the belt.
Although the warning reflector itself is not included as an
original equipment, this belt can be used to store the warning
reflector.
Make sure the warning reflector is securely held.

COMFORT ADJUSTMENT
89
SV16061
This indicator comes on when the ignition key is turned to
the ºACCº or ºONº position. It goes off after about 6
seconds. This means the front seat belt pretensioners are
operating properly.
The warning light system monitors the airbag sensor
assembly, front airbag sensors, side airbag sensors, front seat
belt pretensioner assemblies, inflators, warning light,
interconnecting wiring and power sources. (For details, see
ºService reminder indicators and warning buzzersº on page
38.)
SV16068

1Front airbag sensors
2Front seat belt pretensioner assemblies
3SRS warning light
4Airbag sensor assembly
The front seat belt pretensioner system consists mainly of the
above components and their locations are shown in the
illustration.
The front seat belt pretensioners are controlled by the airbag
sensor assembly. The airbag sensor assembly consists of a
safing sensor and airbag sensor.
When the front seat belt pretensioners are activated, an
operating noise may be heard and a small amount of
smoke±like gas may be released. This gas is harmless and
does not indicate that a fire is occurring.
Once the front seat belt pretensioners have been activated, the
seat belt retractors remain locked.

COMFORT ADJUSTMENT
93
SJ16009

Side airbags
In response to a severe side impact, the side airbags for
the driver or front passenger work together with the seat
belts to help reduce injury by inflating. The side airbags
help to reduce injuries mainly to the driver or front
passenger's chest.
The side airbag on the passenger seat is activated even with
no passenger in the front seat.
Be sure to wear your seat belt.
CAUTION
The side airbags inflate with considerable force. To
avoid potential death or serious injury when they inflate,
the driver and front passenger must:
 Wear their seat belts properly.
 Remain properly seated with their back upright and
against the seat at all times.
SV16061
The indicator comes on when the ignition key is turned to
the ºACCº or ºONº position. It goes off after about 6
seconds. This means the SRS airbags are operating
properly.
The SRS warning light system monitors the airbag sensor
assembly, front airbag sensors, side airbag sensors, door side
airbag sensors, front seat belt pretensioner assemblies,
inflators, warning light, interconnecting wiring and power
sources. (For details, see ºService reminder indicators and
warning buzzersº on page 38.)

COMFORT ADJUSTMENT
96
SV16021

1Hitting a curb, edge of pavement or hard material
2Falling into or jumping over a deep hole
3Landing hard or vehicle falling
The SRS front airbags may deploy if a serious impact
occurs to the underside of your vehicle. Some examples
are shown in the illustration.
SV16022

1Side airbag modules (airbag and inflator)
2Airbag module for front passenger (airbag and inflator)
3Side airbag sensors
4Airbag module for driver (airbag and inflator)
5SRS warning light
6Airbag sensor assembly
7Front airbag sensors
The SRS airbag system consists mainly of the above
components, and their locations are shown in the illustration.
The airbag sensor assembly consists of a safing sensor and
airbag sensors.
In a severe frontal impact, the driver and front passenger
airbag sensors detect deceleration and the system triggers the
front airbag inflators. In a severe side impact, the side airbag
sensor triggers the side airbag inflator. At this time a chemical
reaction in the inflators quickly fills the airbags with non±toxic
gas to help restrain the forward or lateral motion of the
occupants.

STARTING AND DRIVING
1743: Third range
The most suitable gear is selected automatically
between first and third gears according to the vehicle
speed or the running condition.
Slight engine braking will be obtained on a downhill
road.
Smooth running with less shifting will be obtained on an
uphill.
2: Second range First or second gear will be selected automatically
according to the vehicle speed or the running condition.
This range is used in the case that the engine braking is
necessary.
The gear position being used is shown on the instrument
cluster.
Each time you push the switch located on the front of the
steering wheel, the transmission downshifts (from º5º) to º4º\
,
º3º and then º2º.
When you push the switch located on the back of the steering
wheel, the transmission upshifts to º3º, º4º and then º5º\
.
For the precautions on each position, see the description on
the next page. Warning tone sounds twice in any of the following cases:

You attempt to downshift the transmission when it is not
possible to downshift due to the high vehicle speed.
 You attempt to downshift from º2º position.
 You attempt to upshift from º5º position.
If the ºMº indicator flashes, there is a problem somewhere
in the system. In this case, it should be noted that you
cannot downshift or upshift the transmission using the
switches on the steering wheel. Consult with your Lexus
dealer as soon as possible. The transmission works
exactly in the same way as when you put the selector lever
in the ºDº position.
CAUTION
Be careful when downshifting on a slippery surface.
The abrupt change in engine speed could cause the
vehicle to spin or skid.
