2002 JEEP LIBERTY sensor

A/C COMPRESSOR CLUTCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C3 18DB/BK A/C COMPRESSOR CLUTCH RELAY OUTPUT
2 Z246 18BK/GY GROUND
A/C HIGH PRESSURE SWITCH (DIESEL) - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 C18 20DB A/C PRESSURE SIGNAL
2 C21 18DB/OR A/C SWITCH SENSE
A/C LOW PRESSURE SWITCH - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 C21 18DB/OR A/C SWITCH SENSE
2 Z142 18BK/WT (RHD) GROUND
2 Z212 18BK/OR (LHD) GROUND
A/C PRESSURE TRANSDUCER (GAS) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K6 18VT/WT 5 VOLT SUPPLY
3 C18 18DB A/C PRESSURE SIGNAL
4- -
A/C-HEATER CONTROL C1 - BLACK 7 WAY
CAV CIRCUIT FUNCTION
1 Z8 12BK/VT GROUND
2 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
3 C6 12LB BLOWER MOTOR M2 DRIVER
4 C5 14LG BLOWER MOTOR M1 DRIVER
5 C4 14TN BLOWER MOTOR LOW DRIVER
6 C19 18BR A/C ON/OFF CONTROL
7 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-5

A/C-HEATER CONTROL C2 - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1 C35 20DG/YL MODE DOOR DRIVER (A)
2 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
3- -
4- -
5- -
6 C79 20VT/BK REAR WINDOW DEFOGGER CONTROL
7- -
8 Z12 20BK/TN GROUND
9- -
10 - -
11 - -
12 C16 20LB/YL FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
ACCELERATOR PEDAL POSITION SENSOR (DIESEL) - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 K4 18BK/LB SENSOR GROUND
5 K151 20WT LOW IDLE POSITION SWITCH SENSE
6- -
7 K81 20VT/TN ACCELERATOR PEDAL POSITION SENSOR SIGNAL
8 K255 20WT/DG ACCELERATOR PEDAL POSITION SENSOR GROUND
9- -
10 K852 20VT/WT ACCELERATOR PEDAL POSITION SENSOR 5 VOLT
SUPPLY
AIRBAG CONTROL MODULE C1 (ORC C1) - YELLOW 23 WAY
CAV CIRCUIT FUNCTION
1 R45 18DG/LB DRIVER SQUIB 1 LINE 2
2 R43 18BK/LB DRIVER SQUIB 1 LINE 1
3- -
4- -
5 R53 18OR/YL DRIVER SEAT BELT TENSIONER LINE 2
6 R55 18OR/BK DRIVER SEAT BELT TENSIONER LINE 1
7 R61 18OR/LB DRIVER SQUIB 2 LINE 1
8 R63 18TN/LB DRIVER SQUIB 2 LINE 2
9 R62 18OR/YL PASSENGER SQUIB 2 LINE 2
10 R64 18TN/YL PASSENGER SQUIB 2 LINE 1
11 R42 18BK/YL PASSENGER SQUIB 1 LINE 1
12 R44 18DG/YL PASSENGER SQUIB 1 LINE 2
13 - -
14 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
15 F23 18DB/YL FUSED IGNITION SWITCH OUTPUT (RUN)
16 Z6 18BK/PK GROUND
8Wa - 80 - 6 8W-80 CONNECTOR PIN-OUTSKJ

AIRBAG CONTROL MODULE C1 (ORC C1) - YELLOW 23 WAY
CAV CIRCUIT FUNCTION
17 - -
18 - -
19 - -
20 - -
21 D25 18YL/VT/OR PCI BUS
22 - -
23 - -
AIRBAG CONTROL MODULE C2 (ORC C2) - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1- -
2 R59 20LB DRIVER SEAT BELT SWITCH GROUND
3 R57 20DG DRIVER SEAT BELT SWITCH SENSE
4- -
5 R60 20VT PASSENGER SEAT BELT SWITCH GROUND
6 R58 20GY PASSENGER SEAT BELT SWITCH SENSE
7 R48 20TN RIGHT FRONT IMPACT SENSOR SIGNAL
8 R46 20BR/LB RIGHT FRONT IMPACT SENSOR GROUND
9- -
10 - -
11 R47 20DB/LB LEFT FRONT IMPACT SENSOR GROUND
12 R49 20LB/OR LEFT FRONT IMPACT SENSOR SIGNAL
AMBIENT TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G31 18VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
2 G32 18DB/OR AMBIENT TEMPERATURE SENSOR RETURN
ANTENNA (EXCEPT BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 X30 BK RADIO ANTENNA CORE
2 X31 BK RADIO ANTENNA SHIELD
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-7

ANTENNA MODULE C1 (BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 F85 16VT/WT FUSED IGNITION SWITCH OUTPUT (RUN--ACC)
2- -
ANTENNA MODULE C2 (BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 X30 BK RADIO ANTENNA CORE
2 X31 BK RADIO ANTENNA SHIELD
ASH RECEIVER LAMP-2WAY
CAV CIRCUIT FUNCTION
1 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
2 Z158 20BK/GY GROUND
BACK-UP LAMP SWITCH (M/T) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN)
2 L10 18BR/LG BACK-UP LAMP FEED
BATTERY TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K118 18PK/YL BATTERY TEMPERATURE SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
8Wa - 80 - 8 8W-80 CONNECTOR PIN-OUTSKJ

BODY CONTROL MODULE C1 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
16 D19 20VT/OR BODY CONTROL MODULE FLASH ENABLE
17 P101 20OR/PK FLIP-UP GLASS RELEASE SWITCH SENSE
18 - -
19 - -
20 B22 18LG/YL VEHICLE SPEED OUTPUT
21 G69 20BK/OR VTSS INDICATOR DRIVER
22 - -
23 C79 20VT/BK REAR WINDOW DEFOGGER CONTROL
24 C19 18BR A/C ON/OFF CONTROL
25 Z3 16BK/OR GROUND
26 P100 18OR/BR FLIP-UP GLASS RELEASE MOTOR DRIVER
BODY CONTROL MODULE C2 - GRAY 22 WAY
CAV CIRCUIT FUNCTION
1 Y66 20GY (EXCEPT BASE) RKE ANTENNA
2 G910 20VT/BR TAILGATE SWITCH GROUND
3- -
4 L80 20WT/DG HEADLAMP SWITCH RETURN
5 L307 20LG/OR HEADLAMP SWITCH MUX
6 G72 18DG/OR (LHD PREMIUM) RIGHT CYLINDER LOCK SWITCH MUX
6 G73 18LG/OR (RHD) RIGHT CYLINDER LOCK SWITCH MUX
7 L27 20WT/TN (EXCEPT BASE) FRONT FOG LAMP SWITCH SENSE
8 E21 20OR/RD PANEL LAMPS DIMMER SWITCH MUX
9 G72 18DG/OR (RHD) LEFT CYLINDER LOCK SWITCH MUX
9 G73 18LG/OR (LHD PREMIUM) LEFT CYLINDER LOCK SWITCH MUX
10 V52 20DG/RD FRONT WIPER SWITCH MUX
11 X10 20RD/DB (EXCEPT BASE) RADIO CONTROL MUX RETURN
12 Y66 20GY (EXCEPT BASE) RKE ANTENNA
13 - -
14 - -
15 G32 20DB/OR (EXCEPT BASE) AMBIENT TEMPERATURE SENSOR RETURN
16 - -
17 G71 18VT/YL TAILGATE CYLINDER LOCK SWITCH MUX
18 G31 20VT/LG (EXCEPT BASE) AMBIENT TEMPERATURE SENSOR SIGNAL
19 L324 20WT/LG HIGH BEAM SWITCH SENSE
20 F512 18PK/OR VEHICLE SPEED SENSOR SUPPLY
21 B12 18DG/OR VEHICLE SPEED SIGNAL
22 X20 20RD/BK (EXCEPT BASE) RADIO CONTROL MUX
BODY CONTROL MODULE C3 (PREMIUM)-6WAY
CAV CIRCUIT FUNCTION
1 Y60 RKE DATA
2 Y62 RKE SUPPLY
3 Y61 RKE PROGRAM
4 Y63 RKE GROUND
5 Y64 RKE ANTENNA (+)
6 Y65 RKE ANTENNA (-)
8Wa - 80 - 10 8W-80 CONNECTOR PIN-OUTSKJ

BOOST PRESSURE SENSOR (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
3 K6 18VT/WT SENSOR REFERENCE VOLTAGE B
4 K37 20DB/YL BOOST PRESSURE SENSOR SIGNAL
BRAKE LAMP SWITCH - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 F32 18PK/DB FUSED B(+)
2 L50 18WT/TN (GAS) BRAKE LAMP SWITCH OUTPUT
2 L50 18WT/TN (DIESEL) PRIMARY BRAKE SWITCH SIGNAL
3 V30 18DB/RD SPEED CONTROL BRAKE SWITCH OUTPUT
4 V32 18YL/RD SPEED CONTROL SUPPLY
5 Z3 18BK/OR GROUND
6 K29 18WT/PK (GAS) BRAKE SWITCH SENSE
6 K29 18WT/PK (DIESEL) SECONDARY BRAKE SWITCH SIGNAL
BRAKE PRESSURE SWITCH (ABS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2 S43 18LB/YL FLUID PRESSURE SWITCH SIGNAL
C100 (RHD) - GRAY (INSTRUMENT PANEL SIDE)
CAV CIRCUIT
1 L43 18VT
2 F1 20DB
3 M1 18PK
4 B22 18LG/YL
5 L44 18VT/RD
6 V16 18VT/YL
7 V55 16TN/RD
8 G32 20DB/OR
9 D20 20LG
10 D25 18YL/VT/BR
11 V14 18RD/VT
12 L13 18BR/YL
13 G70 20BR/TN
14 G11 20WT/BK
15 K4 20BK/LB
16 L50 18WT/TN
17 L62 18BR/RD
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-11

C317 (EXCEPT BUILT-UP-EXPORT) - LT. GRAY
(REAR LIGHTING SIDE)
CAV CIRCUIT
1 L77 18BK/YL
2 Z151 18BK/WT
C317 (EXCEPT BUILT-UP-EXPORT) - LT. GRAY
(LICENSE LAMP SIDE)
CAV CIRCUIT
1 L77 18BR/YL
2 Z151 18BK/WT
CABIN HEATER (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C151 18DB/WT CABIN HEATER RELAY OUTPUT
2 Z186 12BK/OR GROUND
CAMSHAFT POSITION SENSOR (2.4L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K7 18OR 5 VOLT SUPPLY
2 K4 18BK/LB SENSOR GROUND
3 K44 18TN/YL CAMSHAFT POSITION SENSOR SIGNAL
CAMSHAFT POSITION SENSOR (3.7L) - LT. GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 K44 18TN/YL CAMSHAFT POSITION SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-47

CAMSHAFT POSITION SENSOR (DIESEL)-3WAY
CAV CIRCUIT FUNCTION
1 K944 20BK/LB CAMSHAFT POSITION SENSOR GROUND
2 K44 20TN/YL CAMSHAFT POSITION SENSOR SIGNAL
3 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
CAPACITOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
2 Z55 14BK/WT GROUND
CARGO LAMP (EXCEPT BASE) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M3 20PK/DB REAR COURTESY LAMP CONTROL
3 M2 20YL COURTESY LAMP DRIVER
CD CHANGER - GREEN 12 WAY
CAV CIRCUIT FUNCTION
1 X41 20WT/DG AUDIO OUT LEFT
2- -
3- -
4 Z17 20BK GROUND
5 X112 20RD IGNITION SWITCH OUTPUT
6 X160 20YL B(+)
7 X40 20WT/RD AUDIO OUT RIGHT
8 Z30 20WT/BK GROUND
9- -
10 - -
11 Z9 20BK/DB GROUND
12 D25 20YL/VT PCI BUS
8Wa - 80 - 48 8W-80 CONNECTOR PIN-OUTSKJ
