High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.
Your car’s exhaust contains carbon
monoxide gas. You should have no
problem with carbon monoxide
entering the car in normal driving if
you maintain your car properly.
Have the exhaust system inspected
f or leaks whenever:
The car is raised f or an oil change.
You notice a change in the sound
of the exhaust.
Thecarwasinanaccidentthat
may have damaged the underside. If you must sit in your parked car,
even in an unconf ined area, with the
engine running, adjust the heating
and cooling system as f ollows:
With the trunk lid open, air f low can
pull exhaust gas into your car’s
interior and create a hazardous
condition. If you must drive with the
trunk lid open, open all the windows
and set the heating and cooling
system as shown below.
Select the Fresh Air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
1.2.3.4.
Carbon Monoxide Hazard
Driver and Passenger Saf ety54
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even killyou.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.

Bef ore you begin driving your Honda,
youshouldknowwhatgasolineto
use, and how to check the levels of
important f luids. You also need to
know how to properly store luggage
or packages. The inf ormation in this
section will help you. If you plan to
add any accessories to your car,
please read the inf ormation in this
section f irst..............................
Break-in Period . 164
.........................................
Gasoline . 164
.........
Service Station Procedures . 165
................
Filling the Fuel Tank . 165
....................
Opening the Hood . 166
...............................
Oil Check . 168
.........
Engine Coolant Check . 169
...............................
Fuel Economy . 170
.....................
Vehicle Condition . 170
...........................
Driving Habits . 170
...
Accessories and Modif ications . 171
.............................
Carrying Cargo . 173
Bef ore Driving
Bef ore Driving163

Wipe the dipstick with a clean
cloth or paper towel.Insert it all the way back in its tube.
Remove the dipstick (orange
handle).
Check the engine oil level every time
you f ill the car with f uel. Wait a f ew
minutes af ter turning the engine of f
bef ore you check the oil.
2.
3.
1.
Oil Check
Service Station Procedures
Bef ore Driving168
DDIIPPSSTTIICCKK

Remove the dipstick again and
check the level. It should be
between the upper and lower
marks.Look at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, see
on page f or
inf ormation on adding the proper
coolant.
If it is near or below the lower mark,
see on page . Refer to
on page f or inf ormation
on checking other items in your
Honda.
4. 209 213207
A dding
Engine Coolant
A dding Oil Owner Maintenance
Checks
Engine Coolant Check
Service Station Procedures
Bef ore Driving169
LLOOWWEERRMMAARRKK
MMAAXX
UUPPPPEERRMMAARRKK
RREESSEERRVVEETTAANNKK
MMIINN

µ
Î ÎÌ ÌÌ
Î
Î
Maint enance200
Service at the indicated distance or time whichever comes first. miles x1,000
km x 1,000
months 1016
508070
112 110176
Check oil and coolant at each fuel stop
Check engine oil and coolant
Replace engine oil
Rotate tires (Check tire inflation and condition at least once per month)
Replace engine oil filter
Inspect front and rear brakes
Check parking brake adjustment
Visually inspect the following items:
Tie rod ends, steering gear box and boots
Suspension components
Driveshaft boots
Brake hoses and lines (including ABS)
All fluid levels and condition of fluidsExhaust system
Fuel lines and connections
Inspect and adjust drive belts
Replace dust and pollen filter
Replace transmission fluid
Replace air cleaner element
Replace spark plugs
Inspect valve clearance
Replace timing belt, and inspect water pump
Inspect idle speed
Replace engine coolant
Replace brake fluid
Replace at 120,000 miles (192,000 km) or 6 years, then every 90,000 miles (144,000 km) or 5 years.
See Dust and Pollen Filter on page for replacement information under special driving conditions.
See information on maintenance and emissions warranty, last column, page .
Service the following items at the recommended intervals
Every 3 years (independent of mileage)
At 120,000 miles (192,000 km) or 10 years,
then every 60,000 miles (96,000 km) or 5 years Every 110,000 miles (176,000 km) or 7 years
Inspect every 110,000 miles (176,000 km), otherwise adjust only if noisy Every 110,000 miles (176,000 km)Every 30,000 miles (48,000 km)
20 32
30484064 609680
128 90
144 100160 120192
24 48 72
12 36 60
1:2: : 235
199
M/T
A/T
1
2
Maintenance Schedule for Normal Conditions

µµ
Ø ØØØØØØØØØ Ø ØØØØ Ø
Ø Ø Ø Ø Ø Ø Ø
Ì Ì
Î
ÎÌ
Maint enance201
U.S. Owners
Canadian Owners A, B, C, D, E
A B C DE
Refer to page to determine which schedule to use.
Use the Maintenance Schedule for Severe Conditions.
Service at the indicated distance or time, whichever comes first.
Service at the indicated distance or time, whichever comes first. Do the items in as required for each distance/time.
10,000 mi/16,000 km/1 yr
20,000 mi/32,000 km/1 yr
30,000 mi/48,000 km
30,000 mi/48,000 km/2 yrs
40,000 mi/64,000 km/2 yrs
3yrs
50,000 mi/80,000 km/3 yrs
60,000 mi/96,000 km
60,000 mi/96,000 km/3 yrs
70,000 mi/112,000 km/4 yrs
80,000 mi/128,000 km/4 yrs
90,000 mi/144,000 km
90,000 mi/144,000 km/5 yrs
100,000 mi/160,000 km/5 yrs
110,000 mi/176,000 km
6yrs
110,000 mi/176,000 km/6 yrs
110,000 mi/176,000 km/7 yrs
120,000 mi/192,000 km
120,000 mi/192,000 km/6 yrs
120,000 mi/192,000 km/10 yrs Replace engine oil.
Rotate tires (follow pattern on page 241 ).
Replace engine oil filter.
Inspect front and rear brakes.
Check parking brake adjustment.
Inspect tie rod ends, steering gear box and boots.
Inspect suspension components.
Inspect driveshaft boots.
Inspect brake hoses and lines (including ABS).
Check all fluid levels, condition of fluids, and check
for leaks.
Inspect exhaust system.
Inspect fuel lines and connections.
Inspect and adjust drive belts.
Replace dust and pollen filter .
Replace air cleaner element every 30,000 mi/48,000
km (independent of time).
Replace brake fluid every 3 years (independent ofmileage).
Do items in A.
Do items in A, B.
Do item in D.
Do items in A, C.
Do items in A, B.
Do item in E.
Do items in A.
Do item in D.
DoitemsinA,B,C.
Do items in A.
Do items in A, B.
Do item in D.
Do items in A, C.
Do items in A, B.
Inspect valve clearance, cold engine.
Replace spark plugs.
Do item in E.
Do items in A. Replace timing belt, and inspect water pump.
Inspect idle speed.
Do item in D. Replace transmission fluid (M/T).
Replace transmission fluid (A/T), then
replace every 90,000 mi/144,000 km/5 yrs.
DoitemsinA,B,C. Replace engine coolant, then replace every
60,000mi/96,000km/5yrs.
198
1
See Dust and Pollen Filter on page for replacement
information under special driving conditions.
See information on maintenance and emissions warranty, last
column, page .
Check engine oil and coolant at each fuel stop.
Check and adjust valve clearance, cold engine, only if noisy.
NOTE: 1:
: 235
199
Maintenance Schedule for Normal Conditions (listed by distance/time)

µ
Î ÎÌÌÌ
Î
ÌÎ
Maint enance202
Service at the indicated distance or time whichever comes first. miles x 1,000
km x 1,000
months
Replace every 5,000 miles (8,000 km) or 6 monthsCheck oil and coolant at each fuel stop
1016
508070
112 110176
Check engine oil and coolant
Replace engine oil
Rotate tires (Check tire inflation and condition at least once per month)
Replace engine oil filter
Inspect front and rear brakes
Lubricate all hinges, locks, and latches
Visually inspect the following items: Tie rod ends, steering gear box and boots
Suspension components
Driveshaft boots
Check parking brake adjustment
Visually inspect the following items: Brake hoses and lines (including ABS)
All fluid levels and condition of fluidsExhaust system, Fuel lines and connections
Lights and controls, Vehicle underbody
Inspect and adjust drive belts
Replace dust and pollen filter
Replace transmission fluid
Replace air cleaner element
Replace spark plugs
Inspect valve clearance
Replace timing belt , and inspect water pump
Inspect idle speed
Replace engine coolant
Replace brake fluid
See information on maintenance and emissions warranty, last column, page .
See Timing Belt on page for replacement information under special driving conditions.
See Dust and Pollen Filter on page for replacement information under special driving conditions. At 120,000 miles (192,000 km) or 10 years,
then every 60,000 miles (96,000 km) or 5 years Every 3 years (independent of mileage)
Every 110,000 miles (176,000 km) or 7 years
Inspect every 110,000 miles (176,000 km), otherwise adjust only if noisy Every 110,000 miles (176,000 km)
Every 15,000 miles (24,000 km) in dusty conditions,
otherwise use normal schedule
Service the following items at the recommended intervals
At 60,000 miles (96,000 km) or 3 years, then every 30,000 miles (48,000 km) or 2 years
20 32
3048 4064 6096 80
128 90
144 100160 120192
24 48 72
12 36 60
1:2: : 235
237 199
M/T
A/T
1
2
Maintenance Schedule for Severe Conditions

µµ
Ø ØØØØ Ø ØØØØØ Ø ØØØØØØ Ø
Ø Ø Ø
Ì Ì
Î
CONT INUED
Maint enance203
U.S. Owners
Canadian Owners A, B, C, D, E, F
AB CD EF
Refer to page to determine which schedule to use.
Use the Maintenance Schedule for Severe Conditions.
Service at the indicated distance or time, whichever comes first.
Service at the indicated distance or time, whichever comes first. Do the items in as required for each distance/time.
5,000 mi/8,000 km
10,000 mi/16,000 km/1 yr
15,000 mi/24,000 km
20,000 mi/32,000 km/1 yr
25,000 mi/40,000 km
30,000 mi/48,000 km
30,000 mi/48,000 km/2 yrs
35,000 mi/56,000 km
40,000 mi/64,000 km/2 yrs
45,000 mi/72,000 km3ys
50,000 mi/80,000 km/3 yrs
55,000 mi/88,000 km
60,000 mi/96,000 km
60,000 mi/96,000 km/3 yrs
65,000 mi/104,000 km
70,000 mi/112,000 km/4 yrs
75,000 mi/120,000 km
80,000 mi/128,000 km/4 yrs
85,000 mi/136,000 km
90,000 mi/144,000 km
90,000 mi/144,000 km/5 yrs Replace engine oil.
Replace engine oil filter.
Inspect front and rear brakes.
Rotate tires (follow pattern on page 241 ).
Lubricate all hinges, locks, and latches with
multipurpose grease.
Inspect tie rod ends, steering gear box and boots.
Inspect suspension components.
Inspect driveshaft boots.
Check parking brake adjustment.
Inspect brake hoses and lines (including ABS).
Check all fluid levels, condition of fluids, and check
for leaks.
Inspect exhaust system.
Inspect fuel lines and connections.
Check all lights.
Inspect the underbody.
Inspect and adjust drive belts.
Replace dust and pollen filter .
Replace air cleaner element every 15,000 mi/
24,000 km (independent of time).
Replace brake fluid every 3 years (independent ofmileage).
Do items in A.
Do items in A, B.
Do items in A, E.
DoitemsinA,B,C.
Do items in A.
Do item in E.
DoitemsinA,B,D.
Do items in A.
DoitemsinA,B,C.
Do items in A, E.
Do item in F.
Do items in A, B.
Do items in A.
Do item in E.
Replace transmission fluid (M/T).
Replace transmission fluid (A/T), then
replace every 30,000 mi/48,000 km/2 yrs.
DoitemsinA,B,C,D.
Do items in A.
Do items in A, B.
Do items in A, E.
DoitemsinA,B,C.
Do items in A.
Do item in E. Replace transmission fluid (A/T).
DoitemsinA,B,D.
198
1
Maintenance Schedule for Severe Conditions (listed by distance/time)
