3-16
To set treble to the middle position, press and hold
P
-TYPE LIST AUDIO control. The radio will produce
one beep and set the display level to the middle position.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST AUDIO
control when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
When you use this control, the radio's AUTO TONE
setting will return to manual.
AUTO TONE: This feature allows you to choose preset
bass and treble equalization settings designed for rock,
news, pop, jazz, classical and country stations.
Each time you press the AUTO TONE button, this
feature will change to one of the preset equalization
settings previously listed.
To return the bass and treble to the manual mode, press
and release the P
-TYPE LIST AUDIO control. See
ªSetting Preset Stationsº listed previously to program
the auto tone feature.Adjusting the Speakers (Balance/Fade)
To adjust the balance, press and release the P
-TYPE
LIST AUDIO control until BAL appears on the display.
Turn the control clockwise to move the sound to the
right speakers and counterclockwise to move the sound
to the left speakers.
The middle position balances the sound between the
speakers. To set the balance to the middle position, press
the P
-TYPE LIST AUDIO control briefly, then press it
again and hold it until the radio emits one beep. The
balance will be set to the middle position and the display
will show the speaker balance.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST AUDIO
control when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
To adjust the fade, press and release the P
-TYPE LIST
AUDIO control until FADE appears on the display. Turn
the control clockwise to move the sound to the front
speakers and counterclockwise to move the sound to the
rear speakers.

3-18
Accessing RDS
To access RDS stations perform the following steps:
1. Push the SEEK TYPE button or turn the P
-TYPE
LIST AUDIO control to display the program
type list.
2. Turn the control either clockwise or
counterclockwise to select a program type. The list
is alphabetical. If you select ANY TYPE your radio
will seek to the first PTY available.
3. Push the SEEK TYPE button to activate search.
VOL PWR: Turn this control clockwise to increase
volume when RDS interrupts regular play. Turn it
counterclockwise to decrease volume.
P
-TYPE LIST AUDIO: Turn this control clockwise or
counterclockwise to select the Program Type (PTY) you
want to listen to. TYPE and a PTY will appear on the
display. Press the SEEK TYPE button and the radio
will seek to the first RDS broadcaster of the selected
program type. If the radio cannot find the desired
program type, NONE will appear on the display and the
radio will return to the last station you were listening to.AM FM: The AM FM button operates the alternate
frequency feature. This feature allows the radio to
switch automatically to a stronger station with the same
programming. Alternate frequency is off by default from
the factory. Press and hold AM FM for two seconds to
turn alternate frequency on or off. AF ON or AF OFF
will appear on the display and the radio will beep once.
The radio will not switch automatically to other stations
when alternate frequency is off.
SEEK TYPE: Press this button to go to a station with
the last selected PTY; TYPE and the last selected PTY
will appear on the display, if it is not already showing.
Press SEEK TYPE a second time to seek. If a station
with the selected PTY is not found, the radio will return
to the original station and display NONE.
RDS Radio Announcements
(Alert): Alert warns of national or local emergencies.
You will not be able to turn off alert announcements.
ALERT! appears on the display when an alert
announcement plays. When an alert announcement
comes on the tuned radio station, you will hear it, even
if the volume is muted or a cassette tape or compact disc
is playing. If the cassette tape or compact disc player is
playing, play will stop for the announcement and resume
when the announcement is finished.

3-22 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
System (RDS) and Automatic Tone Control
(If Equipped)
Standard Radio--Bose
not shown
Playing the Radio
VOL PWR: Press this control to turn the system on and
off. Turn this control clockwise to increase volume.
Turn it counterclockwise to decrease volume.AUTO VOL: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive.
Set the volume at the desired level. Press AUTO VOL to
adjust the SCV. AVOL will appear on the display. Each
time you press AUTO VOL, another volume setting
(LOW, MEDIUM, HIGH or OFF) will appear on the
display. The volume level should always sound the same
to you as you drive. Each volume setting allows for
more volume compensation at faster vehicle speeds.
NONE will appear on the display if the radio cannot
determine the vehicle speed. If you don't want to use
SCV, select OFF.
If your vehicle has the Bose radio, your audio system
monitors the noise inside your vehicle. Then, automatic
volume automatically adjusts the volume of your radio
so that it always sounds the same to you. To use
automatic volume, press the AUTO VOL button until
AVOL ON appears on the display. To turn the automatic
volume off, press the AUTO VOL button until AVOL
OFF appears on the display.

3-23
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display will show your selection.
TUNE DISP: Turn this control to choose radio stations.
Pressing this control will also display an RDS station
frequency or program type when the radio is on.
Pressing this control when the ignition is off will display
the clock.
 SEEK PSCAN
: To seek, press the right arrow to
tune to the next station and the left arrow to tune to the
previous station and stay there.
To scan your preset stations, press and hold one of the
arrows for more than two seconds. The radio will
produce one beep. Use preset scan to listen to each of
your favorite stations stored on your pushbuttons for a
few seconds. The radio will scan through each of the
stations stored on your pushbuttons, except those
stations with weak reception. Press one of the arrows or
one of the pushbuttons again to stop scanning. SCAN
will be displayed whenever the tuner is in the preset
scan mode. The channel number (P1 through P6) will
appear with the frequency. In FM mode, this function
will scan through the current band such as FM1 or FM2.Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press AUTO TONE to choose the bass and treble
equalization that best suits the type of station you are
listening to.
5. Press and hold one of the six numbered pushbuttons.
The radio will produce one beep. Whenever you
press that numbered pushbutton, the station you set
will return and the bass and treble equalization that
you selected will also be automatically selected for
that pushbutton.
6. Repeat the steps for each pushbutton.

3-24
Setting the Tone (Bass/Treble)
P
-TYPE LIST AUDIO: To adjust the bass, press and
release the P
-TYPE LIST AUDIO control until BASS
appears on the display. Then turn the control clockwise
to increase bass and counterclockwise to decrease bass.
The display will show the bass level.
To set the bass to the middle position, press and hold the
P
-TYPE LIST AUDIO control. The radio will produce
one beep and set the display level to the middle position.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST AUDIO
control when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
To adjust the treble, press and release the P
-TYPE
LIST AUDIO control until TREB appears on the
display. Turn the control clockwise to increase treble
and counterclockwise to decrease treble. The display
will show the treble level. If a station is weak or noisy,
you may want to decrease the treble.
To set treble to the middle position, press and hold
P
-TYPE LIST AUDIO control. The radio will produce
one beep and set the display level to the middle position.To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST AUDIO
control when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
When you use this control, the radio's AUTO TONE
setting will return to manual.
AUTO TONE: This feature allows you to choose preset
bass and treble equalization settings designed for rock,
news, pop, jazz, classical and country stations.
Each time you press the AUTO TONE button, this
feature will change to one of the preset equalization
settings previously listed.
To return the bass and treble to the manual mode, press
and release the P
-TYPE LIST AUDIO control. See
ªSetting Preset Stationsº listed previously to program
the auto tone feature.
If your vehicle has the Bose radio, your audio system
allows you to choose from four different equalization
settings: talk, driver, normal and spatial. These settings
can be used while listening to the radio, the cassette tape
or CD player.

3-25
Press the AUTO TONE button to scroll through your
choices. Select TALK when listening to non
-musical
material such as news, talk shows, sports broadcasts and
books on tape. This setting makes spoken words sound
very clear. Select DRIVER to give the driver the best
possible sound qualities. Select NORMAL to enhance
the stereo effect. Select SPATIAL to make the listening
space seem larger. When NORMAL is displayed, the
system will provide the best overall Bose performance.
The radio saves separate AUTO TONE settings for each
preset and source.
Adjusting the Speakers (Balance/Fade)
To adjust the balance, press and release the P
-TYPE
LIST AUDIO control until BAL appears on the display.
Turn the control clockwise to move the sound to the
right speakers and counterclockwise to move the sound
to the left speakers.
The middle position balances the sound between the
speakers. To set the balance to the middle position, press
the P
-TYPE LIST AUDIO control briefly, then press it
again and hold it until the radio emits one beep. The
balance will be set to the middle position and the display
will show the speaker balance.To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST AUDIO
control when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
To adjust the fade, press and release the P
-TYPE LIST
AUDIO control until FADE appears on the display. Turn
the control clockwise to move the sound to the front
speakers and counterclockwise to move the sound to the
rear speakers.
The middle position balances the sound between the
speakers. To set the fade to the middle position, press
the P
-TYPE LIST AUDIO control briefly, then press it
again and hold it until the radio emits one beep. The
fade will be set to the middle position and the display
will show the speaker balance.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST AUDIO
control when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.

3-27
VOL PWR: Turn this control clockwise to increase
volume when RDS interrupts regular play. Turn it
counterclockwise to decrease volume.
P
-TYPE LIST AUDIO: Turn this control clockwise
or counterclockwise to select the Program Type (PTY)
you want to listen to. TYPE and a PTY will appear on
the display. Press the SEEK TYPE button and the radio
will seek to the first RDS broadcaster of the selected
program type. If the radio cannot find the desired
program type, NONE will appear on the display and the
radio will return to the last station you were listening to.
AM FM: The AM FM button operates the alternate
frequency feature. This feature allows the radio to
switch automatically to a stronger station with the same
programming. Alternate frequency is off by default from
the factory. Press and hold AM FM for two seconds to
turn alternate frequency on or off. AF ON or AF OFF
will appear on the display and the radio will beep once.
The radio will not switch automatically to other stations
when alternate frequency is off.SEEK TYPE: Press this button to go to a station with
the last selected PTY; TYPE and the last selected PTY
will appear on the display, if it is not already showing.
Press SEEK TYPE a second time to seek. If a station
with the selected PTY is not found, the radio will return
to the original station and display NONE.
RDS Radio Announcements
(Alert): Alert warns of national or local emergencies.
You will not be able to turn off alert announcements.
ALERT! appears on the display when an alert
announcement plays. When an alert announcement
comes on the tuned radio station, you will hear it, even
if the volume is muted or a cassette tape or compact disc
is playing. If the cassette tape or compact disc player is
playing, play will stop for the announcement and resume
when the announcement is finished.
This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.

3-30
5 SIDE: Press this button to play the other side of
the tape.
6
RDM: Press this button to reduce background
noise. NR ON will appear on the display. Press it again
to turn Dolby off. NR OFF will appear on the display.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
 SEEK PSCAN
: SEEK PSCAN (right arrow) is
the same as 2 NEXT, and SEEK PSCAN (left arrow) is
the same as 1 PREV. If the button is held or pressed
more than once, the player will continue moving
forward or backward through the tape. SEEK and a
positive or negative number will appear on the display.
AM FM: Press this button to play the radio when a
tape is in the player. The tape will stop but remain in
the player.
TAPE CD: With a tape in the player and the radio
playing, press this button to play a tape. Press AM FM
to return to the radio when a tape is playing. Press TAPE
CD to switch between the tape and compact disc if both
are loaded. The inactive tape or CD will remain safely
inside the radio for future listening.
EJT: Press this button to remove a tape. The radio
will play. Eject may be activated with the radio off.
Cassette tapes may be loaded with the radio off if this
button is pressed first.
Cassette Tape Messages
(CHK TAPE): If CHK TAPE appears on the radio
display, the tape won't play because of one of the
following errors.
The tape is tight and the player can't turn the tape
hubs. Remove the tape. Hold the tape with the open
end down and try to turn the right hub
counterclockwise with a pencil. Turn the tape over
and repeat. If the hubs do not turn easily, your tape
may be damaged and should not be used in the
player. Try a new tape to make sure your player is
working properly.
The tape is broken. Try a new tape.
The tape is wrapped around the tape head. Attempt
to get the cassette out. Try a new tape.
