2002 FORD MUSTANG ECO mode

Light turns on solid:
Temporary malfunctions may cause the light to
illuminate. Examples are:
1. The vehicle has run out of fuel.
2. Poor fuel quality or water in the fuel.
3. The fuel cap may not have been properly installed
and securely tightened.
These temporary malfunctions can be corrected by
filling the fuel tank with high quality fuel of the
recommended octane and/or properly installing and
securely tightening the fuel cap. After three driving
cycles without these or any other temporary
malfunctions present, the light should turn off. (A
driving cycle consists of a cold engine startup
followed by mixed city/highway driving.) No
additional vehicle service is required.
If the light remains on, have your vehicle serviced at
the first available opportunity.
Light is blinking:
Engine misfire is occurring which could damage your
catalytic converter. You should drive in a moderate
fashion (avoid heavy acceleration and deceleration)
and have your vehicle serviced at the first available
opportunity.
Under engine misfire conditions, excessive
exhaust temperatures could damage the
catalytic converter, the fuel system, interior floor
coverings or other vehicle components, possibly
causing a fire.
Instrument Cluster
12

Tachometer
Indicates the engine speed in revolutions per
minute.
Driving with your tachometer pointer at the top of
the scale or in the red zone may damage the engine.
²Base instrument
cluster gauge
²Optional instrument
cluster gauge
Trip odometer
Registers the
kilometers (miles) of
individual journeys.
Press and release the
reset button until a ªTº
appears in the display
(this represents the
trip mode). Press and
hold the button for
three seconds to reset.
0
00000 00
4
5
6
7 3
2
1RPMX1000
SELECT/RESET
.
0
00000 00
4
5
6
7
8 3
2
1RPMX1000
SELECT/RESET
.
0
00000 00
4
5
6
7
8 3
2
1RPMX1000
SELECT/RESET
.
Instrument Cluster
19

Seek function for CD or CD changer
(if equipped)
²Pressto seek to
the previous track of
the current disc. If a
selection has been
playing for three
seconds or more and you press
, the CD
changer will replay that selection from the
beginning.
²Press
to seek forward to the next track of the
current disc. After the last track has been
completed, the first track of the current disc will
automatically replay.
Scan function
The scan function
works in radio, tape or
CD mode.
Scan function in radio mode
Press the SCAN control to hear a brief sampling of
all listenable stations on the frequency band. Press
the control again to stop the scan mode.
Scan function in tape mode
Press the SCAN control to hear a short sampling of
all selections on the tape. (The tape scans in a
forward direction. At the end of the tape's first side,
direction automatically reverses to the opposite side
of the tape.) To stop on a particular selection, press
the control again.
Scan function in CD or CD changer mode
(if equipped)
Press the SCAN control to hear a short sampling of
all selections on the CD. (The CD scans in a forward
direction, wrapping back to the first track at the end
of the CD.) To stop on a particular selection, press
the control again.
SCAN
Entertainment Systems
23

To set the minute,
press and hold the CLK
control and press
TUNE:
²
to decrease
minutes and
²
to increase
minutes.
If your vehicle has a
separate clock, (other than the digital radio display),
the CLK control will not function in the above
manner.
The CLK control will
allow you to switch
between media display
mode (radio station,
stereo information,
etc.) and clock display
mode (time). When in
clock mode, the media information will display for 10
seconds, when the radio is turned on, and then
revert to clock information. Any time that the media
is changed, (new radio station, etc.), the media
information will again display for 10 seconds before
reverting back to the clock. In media mode, the
media information will always be displayed.
Tune adjust
The tune control works in radio mode.
AUTO
CLK
AUTO
CLK
Entertainment Systems
26

MP3 file directory structure
The MACHtMP3 music system recognizes MP3 disc
file and directory (folder) structure as follows:
²There are two different modes for MP3 disc
playback: MP3 flat file mode (default) and MP3
directory mode.
²MP3 flat file mode ignores any directory structure
present on the MP3 disc. The player sequentially
numbers each MP3 track on the disc (denoted by
the .mp3 file extension) from T001 to T255.
²MP3 directory mode represents a directory
structure consisting of one level of directories
(folders). The CD player sequentially numbers all
MP3 tracks on the disc (denoted by .mp3
extension) and all directories containing MP3
files, from 01±01 to 99±99. The first two digits
denote the directory number and the last two
digits denote the track number wtihin that
directory.
²Creating discs with only one level of
subdirectories will help with navigation through
the disc files.
Seek function
The seek function control works in radio, CD, MP3
flat file mode and MP3 directory modes.
Seek function in radio mode
²Pressto find the
next listenable
station down the
frequency band.
²Press
to find the
next listenable station up the frequency band.
Entertainment Systems
33

Seek function in CD, MP3 flat file and MP3
directory modes
²Pressto select
and play the
previous track on
the disc. If the
current track is the
first track on the
disc, pressing
will select the last track on the
disc.
²Press
to select and play the next track on the
disc. If the current track is the last track on the
disc, pressing
will select the first track on the
disc.
Press and hold the SEEK control to quickly seek
through all tracks in MP3 flat file mode or all tracks
in the current MP3 directory.
Note:If a track has been playing for three seconds
or more and you press
on the SEEK control, the
player will replay that track from the beginning.
Scan function
The scan function works in radio, CD, MP3 flat file
and MP3 directory modes.
Scan function in radio mode
Press SCN to engage
scan mode and to hear
a brief sampling of all
listenable stations on
the frequency band. When the top of the band is
reached, the tuner will continue to scan from the
lowest frequency upward.
Press SCN again to disengage scan mode.
Entertainment Systems
34

The MP3 icon will blink in the display while the
MACHttrack function is enabled.
When the desired track is reached, the selected
track will begin play after a two second delay.
To disengage the MACHttrack function, press the
TRACK control again.
Repeat track function
This function works in MP3 flat file mode or MP3
directory mode and allows you repeat the current
track on the MP3 disc.
Repeat track function in MP3 flat file mode and
MP3 directory mode.
Press the REPEAT
control to repeat the
current track. The
repeat icon will display
and the current track will continue to repeat until
the repeat function is disengaged.
Press the REPEAT control again to disengage the
feature.
Error messages
You may experience an error message for the
following situations:
²NO DISC when the CD control is pressed and
there is not a CD present.
²DISC ERR when there is a damaged or unreadable
disc. Such as, data discs containing no .mp3 files,
or for data discs containing more than 255 files or
directories.
²CD ERR for any other disc malfunction.
Saving and naming MP3 files
²Your MACHtMP3 music system supports discs
containing up to 255 files in 255 directories. Discs
containing more than 255 files will not play.
Entertainment Systems
44

²NEWSкvoice-onlyº type of sound with a limited
audio band
Press the DSP control again to access the occupancy
modes. Use the SEL control to optimize the sound
based upon the occupants in the vehicle.
The following occupancy modes can be selected for
the MACH 460 Sound System:
²ALL SEATS
²DRIVER SEAT
²REAR SEATS
The following occupancy modes can be selected for
the MACH 1000 Sound System:
²ALL SEATS
²DRIVER SEAT
²MACH 1000
MACH 1000 mode raises the bass response of the
trunk mounted subwoofers.
CD units are designed to play commercially
pressed 12cm audio compact discs only. Due to
technical incompatibility, certain recordable
and re-recordable compact discs may not
function correctly when used in Ford CD
players. Irregular shaped CDs, CDs with a
scratch protection film attached, and CDs with
homemade paper (adhesive) labels should not
be inserted into the CD player. The label may
peel and cause the CD to become jammed. It is
recommended that homemade CDs be identified
with permanent marker rather than adhesive
labels. Please contact your dealer for further
information.
TROUBLESHOOTING THE CD PLAYER
(IF EQUIPPED)
The laser beam used in the compact disc
player is harmful to the eyes. Do not
attempt to disassemble the case.
Entertainment Systems
62
