WARNING LIGHTS AND CHIMES
Standard instrument cluster
Optional instrument cluster
Service engine soon
Your vehicle is equipped with a
computer that monitors the engine's
emission control system. This
system is commonly known as the
On Board Diagnostics System (OBD
II). The OBD II system protects the
environment by ensuring that your vehicle continues to meet
government emission standards. The OBD II system also assists the
service technician in properly servicing your vehicle.
O/D
OFF
DOOR
AJARCHECK
GAGE
4X4
LOW
4X4
HIGH
CHECK
FUEL
CAPTHEFT
BRAKE
SERVICE
ENGINE
SOON
TRIP
O/D
OFF
4X4
LOW
4X4
HIGH
CHECK
FUEL
CAPTHEFT
BRAKE
SERVICE
ENGINE
SOON
SERVICE
ENGINE
SOON
Instrumentation
8
Driver side temperature selection
The display window indicates the selected temperature and manual
control of fan speed (
) if automatic fan speed is not desired.
To control the temperature, select any temperature between 16ÉC (60ÉF)
and 32ÉC (90ÉF) by pressing the temperature control on the driver side
of the system.
Passenger side temperature selection
To control the temperature, select
any temperature between 16ÉC
(60ÉF) and 32ÉC (90ÉF) by pressing
the temperature control on the
passenger side of the system.
Temperature conversion
Press the Fahrenheit/Celsius (ÉF ÉC)
control to switch between
Fahrenheit and Celsius temperature
on the DEATC display only. The
temperature in Celsius will be
displayed in half-degree increments.
The English/Metric control on the
trip computer and message center
(if equipped) will not change the
DEATC temperature display. Refer toElectronic Message Centerin the
Instrumentationchapter.
AUTO
OFFDUAL A/C
R EXT
F C
FF
A/C
DUAL
R
F
AUTO OFFEXT
F C
C
,
Controls and features
