2002 FORD EXPLORER oil capacities

MOTORCRAFT PART NUMBERS
Component 4.0L SOHC V6 engine 4.6L V8 engine
Air filter element FA-1695 FA-1695
Fuel filter FG-986B FG-986B
Battery BXT-65-650 BXT-65-650
Oil filter FL-820S FL-820S
PCV valve EV-243 F6ZE-6C324-CA
Spark plugs* AGSF-22PP ** AWSF-32P
* Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
** If a spark plug is removed for inspection, it must be reinstalled in the
same cylinder. If a spark plug needs to be replaced, use only spark plugs
with the service number suffix letter as shown on the engine decal.
REFILL CAPACITIES
Fluid Ford Part Name Application Capacity
Brake fluid and
Clutch fluid (if
equipped)High Performance
DOT 3 Motor
Vehicle Brake
FluidAll Fill to line on
reservoir
Engine oil
(including filter
change)Motorcraft SAE
5W-30 Super
Premium Motor Oil4.0L 4.7L
(5.0 quarts)
Motorcraft SAE
5W-20 Super
Premium Motor Oil4.6L 5.7L
(6.0 quarts)
Fuel tank N/A All 85.2L
(22.5 gallons)
Power steering
fluidMotorcraft
MERCONtAT FAll Fill between
the MIN and
MAX lines on
reservoir
Transmission
fluid
1Motorcraft
MERCONtAT F5-speed manual 2.4L
(5.1 pints)2
Motorcraft
MERCONtVATFAutomatic
transmissions
only.12.0L
(12.7 quarts)3
Capacities and specifications
283

ItemFord Part
Name or
equivalentFord Part
NumberFord
Specification
4.0L Engine oilMotorcraft SAE
5W30 Super
Premium Motor
OilXO-5W30-QSPWSS-M2C153-G
with API
Certification
Mark
4.6L Engine oilMotorcraft SAE
5W20 Super
Premium Motor
OilXO -5W20-QSPWSS-M2C153-H
with API
Certification
Mark
Automatic
transmission
2
Motorcraft
MERCONtV
AT FXT-5-QM MERCONtV
Power steering
fluidMotorcraft
MERCONt
Multi-Purpose
AT FXT-2-QDX MERCONt
Ford
conventional and
Traction-Lok
rear axles75W-140 High
performance
synthetic rear
axle lubricant
3,43,4 3,4
Front axle
(4X4)Motorcraft SAE
80W-90
Premium Rear
Axle LubricantXY-80W90-QL WSP-M2C197-A
Transfer case
(4X4)Motorcraft
MERCONt
Multi-Purpose
AT FXT-2-QDX MERCONt
5-speed manual
transmissionMotorcraft
MERCONt
Multi-Purpose
AT FXT-2-QDX MERCONt
Transfer case
Front Output
Slip ShaftPremium
Long-Life GreaseXG-1-C or
XG-1-KESA-M1C75-B
Windshield
washer fluidUltra-clear
Windshield
Washer
ConcentrateC9AZ-19550-AC ESR-M17P5-A
Capacities and specifications
286
