2002 FORD EXPLORER hood open

²Press 7/8 and 9/0 controls on the
keyless entry pad at the same
time to lock the doors (when the
driver's door is closed).
²Open a door and press the power
door lock control to lock the
doors.
There is a 20 second countdown
when any of the above actions occur
before the vehicle becomes ARMED.
Each door/hood or liftgate arm
individually, and if any door/hood or
liftgate is open, then it must be
closed for it to be armed.
When you press the lock control
twice within three seconds on your
remote entry transmitter, the horn
will chirp once to let you know that
all doors/hood and liftgate are
closed.
If the doors/hood or liftgate are not
closed and you press the remote
entry transmitter twice to confirm
the doors are locked, the horn will
chirp twice to warn you that a
door/hood or liftgate is still open.
Disarming the system
You can disarm the system by any of the following actions:
²Unlock the doors by using your
remote entry transmitter.
Controls and features
126

²Unlock the doors by using your
keyless entry pad.
²Unlock the doors or liftgate with a key. Turn the key full travel
(toward the front of the vehicle) to make sure the alarm disarms.
²Turn ignition to ON.
²Press the PANIC control on the
remote entry transmitter. This
will only shut the horn OFF when
the alarm is sounding. The alarm
system will still be armed.
Triggering the anti-theft system
The armed system will be triggered if:
²Any door, liftgate or hood is opened without using the door key or the
remote entry transmitter.
SECURILOCKYPASSIVE ANTI-THEFT SYSTEM
SecuriLockypassive anti-theft system is an engine immobilization
system. This system prevents the engine from being started unless a
coded keyis used.
The SecuriLockypassive anti-theft system is not compatible with
non-Ford aftermarket remote start systems. Use of these systems may
result in vehicle starting problems and a loss of security protection.
Controls and features
127

OPENING THE HOOD
1. Inside the vehicle, pull the hood
(rearward) release handle located
under the bottom left corner of the
instrument panel.
Maintenance and care
231

ENGINE OIL
Checking the engine oil
Refer to the scheduled maintenance guide for the appropriate intervals
for checking the engine oil.
1. Make sure the vehicle is on level ground.
2. Turn the engine off and wait a few minutes for the oil to drain into the
oil pan.
3. Set the parking brake and ensure the gearshift is securely latched in P
(Park).
4. Open the hood. Protect yourself from engine heat.
5. Locate and carefully remove the engine oil level indicator (dipstick).
²4.0L V6 engine
Maintenance and care
235

Replacing headlamp bulbs
The high beam and low beam bulbs are located in the headlamp
assembly. Follow the same steps to replace either bulb:
To remove the headlamp bulb:
1. Make sure headlamp switch is in
OFF position, then open the hood.
2. At the back of the headlamp, pry
up the two retainer pins until they
stop to release the headlamp
assembly from the vehicle and pull
headlamp forward.
1. Disconnect the electrical
connector from the bulb by pushing
the center tab and pulling
downward.
2. Remove the old bulb from the
lamp assembly by turning to unlock
and pulling it straight out of the
lamp assembly.
To install the new bulb:
Handle a halogen headlamp bulb carefully and keep out of
children's reach. Grasp the bulb only by its plastic base and do
not touch the glass. The oil from your hand could cause the bulb to
break the next time the headlamps are operated.
Maintenance and care
271

If the bulb is accidentally touched, it should be cleaned with rubbing
alcohol before being used.
1. Install the new bulb in lamp assembly by pushing straight in and
turning to lock in position. You may need to turn the bulb slightly to
align the grooves in the plastic base with the tabs in the lamp assembly.
2. Connect the electrical connector to the bulb.
3. Install the headlamp on vehicle by aligning the lamp on the vehicle,
push rearward to fully seat the lamp assembly then push the two
retainer pins down.
4. Turn the headlamps on and make sure they work properly. If the
headlamp was correctly aligned before you changed the bulb, you should
not need to align it again.
Replacing front parking lamp/turn signal/sidemarker bulbs
1. Make sure headlamp switch is in
OFF position, then open the hood.
2. Remove screw from the lamp
assembly.
3. Disengage lamp assembly by
pulling forward.
4. Rotate bulb socket
counterclockwise and remove from
lamp assembly.
5. Carefully pull bulb straight out of
socket and push in the new bulb.
6. Install bulb socket in lamp
assembly by turning clockwise.
7. Align the parking lamp studs with
the plastic grommets on the vehicle and push rearward to snap in place.
8. Install screw on lamp assembly.
Replacing tail/brake/turn/backup lamp bulbs
The tail/brake//turn/backup bulbs are located in the tail lamp assembly,
one just below the other. Follow the same steps to replace either bulb:
Maintenance and care
272

VERTICAL AIM ADJUSTMENT
1. Park the vehicle on a level surface approximately 7.6 meters (25 feet)
from a vertical wall or screen directly in front of it.
²(A) Eight feet
²(B) Center height of lamp to ground
²(C) Twenty five feet
²(D) Horizontal reference line
2. Measure the height from the center of your headlamp to the ground
and mark a 2.4 meter (8 foot) horizontal reference line on the vertical
wall or screen at this height (a piece of masking tape works well). The
center of the lamp is marked by a 3.0 mm circle on the headlamp lens.
3. Turn on the low beam headlamps to illuminate the wall or screen and
open the hood.
A
D
B
C
Maintenance and care
276

odometer ...................................15
speedometer .............................14
tachometer ................................16
trip odometer ............................15
GAWR
(Gross Axle Weight Rating) .....194
calculating ...............................196
definition .................................194
driving with a heavy load ......194
location ....................................194
GVWR (Gross
Vehicle Weight Rating) .............194
calculating .......................194, 196
definition .................................194
driving with a heavy load ......194
location ....................................194
H
Hazard flashers .........................206
Head restraints .................131, 136
Headlamps ...................................28
aiming ......................................276
autolamp system .......................30
bulb specifications ..................274
daytime running lights .............28
flash to pass ..............................29
high beam ...........................11, 29
replacing bulbs .......................271
turning on and off ....................28
warning chime ..........................13
Heating ........................................33
heating and air
conditioning system .................33
HomeLink universal
transceiver (see
Garage door opener) ........103±107
Hood ..........................................231I
Ignition .................................89, 287
Infant seats
(see Safety seats) .....................163
Inspection/maintenance
(I/M) testing ..............................270
Instrument panel
cleaning ...................................281
cluster ..................................8, 281
lighting up
panel and interior .....................29
location of components ..............8
J
Jack ....................................217±218
positioning .......................217, 219
storage .....................217±218, 222
Jump-starting your vehicle ......222
K
Keyless entry system ...............121
autolock ...................................124
keypad .....................................121
locking and unlocking doors ..122
programming entry code .......121
Keys ...........................127±128, 130
key in ignition chime ...............13
positions of the ignition ...........89
L
Lamps
autolamp system .......................30
bulb replacement
specifications chart ................274
cargo lamps ...............................29
daytime running light ...............28
