2002 FORD EXPLORER headlamp

4. On the wall or screen you will
observe a light pattern with a
distinct horizonal edge of high
intensity light with a slight angle
towards the right. If this edge is not
at the horizontal reference line, the
beam will need to be adjusted.
5. Locate the vertical adjuster on
each headlamp, then usea4mm
socket/wrench to turn the adjuster either counterclockwise (to adjust
down) or clockwise (to adjust up) aligning the upper edge of the light
pattern up to the horizontal line.
6. HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS
NON-ADJUSTABLE.
7. Close the hood and turn off the lamps.
CLEANING AND CARING FOR YOUR VEHICLE
Refer to the Customer Assistance chapter for a list of Ford-approved
cleaners, polishes and waxes.
Washing your vehicle
Wash your vehicle regularly with
cold or lukewarm water. Never use
strong detergents or soap. If your
vehicle is particularly dirty, use a
quality car wash detergent. Always
use a clean sponge, washing glove
or similar device and plenty of water
for best results. To avoid spots,
avoid washing when the hood is still
warm, immediately after or during
exposure to strong sunlight.
During winter months, it is especially important to wash the vehicle on a
regular basis. Large quantities of dirt and road salt are difficult to
remove and also cause damage to the vehicle.
Any gasoline spilled on the vehicle or deposits such as bird droppings
should be washed and sponged off as soon as possible. Deposits not
removed promptly can cause damage to the vehicle's paintwork.
Maintenance and care
277

Comfort and convenience
Cargo net
Cargo organizers
Cargo shade
Cargo tray
Engine block heaters
Tire step
Travel equipment
Automatic headlamps with daytime running lights (DRL)
Cellular phone holder
Daytime running lights (DRL)
Factory luggage rack adaptors (bike and ski)
Heavy-duty battery
Home link visor
Inside mirror, electrochromic compass (with and without temperature
display)
Luggage/Cargo basket
Luggage rack cross bars
Neutral towing transfer case kit
Dog guard
Removable luggage rack adapters (bike and ski)
Running boards/bars
Seatback storage
Smoker's package
Soft luggage cover
Track rider bars (for luggage rack)
Trailer hitch (Class III)
Trailer hitch bars and balls
Trailer hitch mount bike carrier
Trailer hitch receiver cover
Trailer hitch wiring adaptor
Customer assistance
300

odometer ...................................15
speedometer .............................14
tachometer ................................16
trip odometer ............................15
GAWR
(Gross Axle Weight Rating) .....194
calculating ...............................196
definition .................................194
driving with a heavy load ......194
location ....................................194
GVWR (Gross
Vehicle Weight Rating) .............194
calculating .......................194, 196
definition .................................194
driving with a heavy load ......194
location ....................................194
H
Hazard flashers .........................206
Head restraints .................131, 136
Headlamps ...................................28
aiming ......................................276
autolamp system .......................30
bulb specifications ..................274
daytime running lights .............28
flash to pass ..............................29
high beam ...........................11, 29
replacing bulbs .......................271
turning on and off ....................28
warning chime ..........................13
Heating ........................................33
heating and air
conditioning system .................33
HomeLink universal
transceiver (see
Garage door opener) ........103±107
Hood ..........................................231I
Ignition .................................89, 287
Infant seats
(see Safety seats) .....................163
Inspection/maintenance
(I/M) testing ..............................270
Instrument panel
cleaning ...................................281
cluster ..................................8, 281
lighting up
panel and interior .....................29
location of components ..............8
J
Jack ....................................217±218
positioning .......................217, 219
storage .....................217±218, 222
Jump-starting your vehicle ......222
K
Keyless entry system ...............121
autolock ...................................124
keypad .....................................121
locking and unlocking doors ..122
programming entry code .......121
Keys ...........................127±128, 130
key in ignition chime ...............13
positions of the ignition ...........89
L
Lamps
autolamp system .......................30
bulb replacement
specifications chart ................274
cargo lamps ...............................29
daytime running light ...............28
Index
307

fog lamps ...................................28
headlamps .................................28
headlamps, flash to pass ..........29
instrument panel, dimming .....29
interior lamps .........................102
replacing bulbs ...............270±274
Lane change indicator
(see Turn signal) ........................89
Liftgate ..............................114, 117
Lights, warning and indicator ......8
air bag ........................................10
anti-lock brakes (ABS) ....11, 177
anti-theft ...................................11
brake ..........................................10
charging system ........................11
cruise indicator .........................12
door ajar ....................................12
fuel cap light .............................10
high beam .................................11
overdrive off ..............................12
safety belt .................................10
service engine soon ....................8
speed control ............................95
turn signal indicator .................11
Load limits .................................194
GAWR ......................................194
GVWR ......................................194
trailer towing ..........................194
Loading instructions .................196
Locks
autolock ...................................124
childproof ................................110
doors ........................................109
Lubricant specifications ...285, 287
Lumbar support, seats .............135
M
Manual transmission .................185fluid capacities ........................283
lubricant specifications ..........287
reverse .....................................187
Message center ...........................19
english/metric button ...............23
system check button ................24
warning messages .....................24
Mirrors .......................................108
automatic dimming
rearview mirror .......................107
cleaning ...................................282
fold away .................................111
heated ......................................111
programmable memory ..........117
side view mirrors (power) .....110
Moon roof ..................................102
Motorcraft parts ................265, 283
O
Octane rating ............................262
Odometer .....................................15
Oil (see Engine oil) ..................235
P
Panic alarm feature,
remote entry system ................117
Parking brake ............................177
Parts (see Motorcraft parts) ....283
Pedals (see Power
adjustable foot pedals) ...............30
Power adjustable foot pedals .....30
Power distribution box
(see Fuses) ...............................213
Power door locks ......................109
Power steering ..........................178
Index
308
