2002 FORD EXPLORER climate control

Climate control features
Press TMP + or - to adjust
temperature.
Press
+ or - to adjust fan speed.
OVERHEAD CONSOLE (IF EQUIPPED)
The appearance of your vehicle's overhead console will vary according to
your option package.
Storage compartment
Press the latch to open the storage
compartment.
Controls and features
100

The fuses are coded as follows:
Fuse/Relay
LocationFuse Amp
RatingPassenger Compartment Fuse
Panel Description
1 30A Radio Sense, 4x4, ABS Control
Module
2 20A Folding Mirror, Moon Roof,
Heated Seats, Moon roof
3 20A Radio, Amplifier, Power Antenna
4 5A Digital Transmission Range Sensor
5 15A Flasher Relay (Turn, Hazards)
6 10A Right Horn
7 15A Heated Mirrors
8 30A Washer Pump Relays (Front and
Rear), Front Wiper Control
9 15A Rear Wiper Coil and Contact
10 10A Heated Backlight Relay Coil,
Heated Seat Module, Temp Blend
Actuator, A/C Clutch Contact
11 Ð Not Used
12 5A Foglamp Switch,4x4module
13 5A Over Drive Cancel Switch, GEM
Start, Flex Fuel Sender
14 5A PATS Module
15 5A 4 x 4, Memory Seat Disable
16 5A Power Mirror, Security Module
(turn), Manual Climate Control
17 15A Delayed Acc. Coil, Battery Saver,
Interior Lamps
18 10A Left Horn
19 Ð Not Used
20 5A Memory Module, GEM Module
21 5A Instrument Cluster, Compass,
Flasher Coil
22 Ð Not Used
23 15A Brake Pedal Position Switch
24 15A Cigar Lighter, OBD II
Roadside emergencies
210

Fuse/Relay
LocationFuse Amp
RatingPassenger Compartment Fuse
Panel Description
25 5A Mode, Temperature Actuator,
Auxiliary Climate Control, Trailer
Tow Battery Charge, Moon Roof
26 7.5A Park Aid, Brake Shift Interlock,
Approach Lamp Relay Coil
27 7.5A Electronic Compass Mirror,
Security Module, Digital
Transmission Range Sensor -
Backup Lamps
28 10A Air Bag Diagnostics
29 5A 4 x 4, GEM Module signal, ABS
Control Module, Moon Roof
30 5A Daytime Running Lamps (DRL),
Remote Solenoid, DEATC Climate
Controller
Roadside emergencies
211

Treadwear
The treadwear grade is a comparative rating based on the wear rate of
the tire when tested under controlled conditions on a specified
government test course. For example, a tire graded 150 would wear one
and one-half (1 1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends upon the actual
conditions of their use, however, and may depart significantly from the
norm due to variations in driving habits, service practices, and
differences in road characteristics and climate.
Traction AA A B C
The traction grades, from highest to lowest are AA, A, B, and C. Those
grades represent the tire's ability to stop on wet pavement as measured
under controlled conditions on specified government test surfaces of
asphalt and concrete. A tire marked C may have poor traction
performance.
The traction grade assigned to this tire is based on
straight-ahead braking traction tests, and does not include
acceleration, cornering, hydroplaning or peak traction characteristics.
Temperature A B C
The temperature grades are A (the highest), B, and C, representing the
tire's resistance to the generation of heat and its ability to dissipate heat
when tested under controlled conditions on a specified indoor laboratory
test wheel. Sustained high temperature can cause the material of the tire
to degenerate and reduce tire life, and excessive temperature can lead to
sudden tire failure. The grade C corresponds to a level of performance
which all passenger car tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A represent higher levels of
performance on the laboratory test wheel than the minimum required by
law.
The temperature grade for this tire is established for a tire that
is properly inflated and not overloaded. Excessive speed,
underinflation, or excessive loading, either separately or in
combination, can cause heat buildup and possible tire failure.
Maintenance and care
255

Do not replace your tires with ªhigh performanceº tires or larger
size tires.
Failure to follow these precautions may adversely affect the
handling of the vehicle and make it easier for the driver to lose
control and roll over.
Tires that are larger or smaller than your vehicle's original tires may also
affect the accuracy of your speedometer.
USING SNOW TIRES AND TRACTION DEVICES
Snow tires must be the same size and grade as the tires you
currently have on your vehicle.
The tires on your vehicle have all-weather treads to provide traction in
rain and snow. However, in some climates, using snow tires or traction
devices may be necessary. Ford offers tire cables as a Ford approved
accessory and recommends use of these or SAE class ªSº. See your
dealer or qualified service technician for more information on tire cables
for your vehicle.
Follow these guidelines when using snow tires and traction devices:
²Cables or chains should only be used on the rear wheels.
²Install cables or chains securely, verifying that the cables or chains do
not touch any wiring, brake lines or fuel lines.
²Drive cautiously. If you hear the cables or chains rub or bang against
the vehicle, stop and retighten them. If this does not work, remove the
cables or chains to prevent vehicle damage.
²Avoid overloading your vehicle.
²Remove the cables or chains when they are no longer needed.
²Do not use cables or chains on dry roads.
²Do not exceed 48 km/h (30 mph) with tire cables or chains on your
vehicle.
Consult your dealer for information on other Ford approved methods of
traction control.
Maintenance and care
258

Fluid Ford Part Name Application Capacity
Transfer case Motorcraft
MERCONtAT F4WD 1.4L
(1.5 quarts)
Engine coolant
4Premium Engine
Coolant4.0L SOHC V6
enginewithout
auxiliary
climate control15.4L
(16.3 quarts)
4.0L SOHC V6
enginewith
auxiliary
climate control17.2L
(18.2 quarts)
4.6L V8 engine
without
auxiliary
climate control17.6L
(18.6 quarts)
4.6L V8 engine
withauxiliary
climate control19.0L
(20.1 quarts)
Front axle
lubricantMotorcraft SAE
80W-90 Premium
Rear Axle
Lubricant4x4 vehicles 1.7L
(1.8 quarts)
Rear axle
lubricant
5Motorcraft SAE
75W-140 High
Performance
Synthetic Rear
Axle LubricantConventional
Axle61.7L (3.5 pints)
Limited slip
axle
61.5L
(3.25 pints)
Windshield
washer fluidUltra-Clear
Windshield Washer
ConcentrateAll 4.0L
(4.2 quarts)
1Ensure the correct automatic transmission fluid is used. MERCONtand
MERCONtV are not interchangeable. DO NOT mix MERCONtand
MERCONtV. Refer to your scheduled maintenance guide to determine
the correct service interval.
2Service refill capacity is determined by filling the transmission to the
bottom of the filler hole with the vehicle on a level surface.
3Indicates only approximate dry-fill capacity. Some applications may
vary based on cooler size and if equipped with an in-tank cooler. The
amount of transmission fluid and fluid level should be checked by a
qualified technician.
Capacities and specifications
284

Child safety seats ......................163
attaching with tether straps ..167
in front seat ............................165
in rear seat ..............................165
Cleaning your vehicle ...............277
engine compartment ..............278
exterior ....................................278
exterior lamps .........................280
instrument cluster lens ..........281
instrument panel ....................281
interior .....................................281
mirrors .....................................282
plastic parts ............................280
safety belts ..............................282
washing ....................................277
waxing .....................................278
wheels ......................................280
windows ..................................282
wiper blades ............................280
woodtone trim ........................282
Climate control (see Air
conditioning or Heating) ............33
Clock ..........................56, 62, 72, 86
Clutch
operation while driving ..........185
recommended shift speeds ....186
Compass, electronic ....................17
calibration .................................19
set zone adjustment ...........18, 20
Console ......................................112
overhead ..................................100
rear ..........................................113
Controls
power seat ...............................133
steering column ........................99
Coolant
checking and adding ..............241
refill capacities ................245, 283
specifications ..................285, 287Cruise control
(see Speed control) ....................90
Customer Assistance ................205
Ford accessories
for your vehicle ......................298
Ford Extended
Service Plan ............................291
Getting assistance outside
the U.S. and Canada ..............297
Getting roadside assistance ...205
Getting the
service you need ....................291
Ordering additional
owner's literature ...................302
The Dispute
Settlement Board ...................294
Utilizing the Mediation/
Arbitration Program ...............297
D
Daytime running lamps
(see Lamps) ................................28
Defrost
rear window ..............................50
Dipstick
automatic
transmission fluid ...................248
engine oil .................................235
Doors
door ajar warning .....................12
lubricant specifications ..........285
Driveline universal joint
and slip yoke .............................251
Driving under special
conditions ..................................193
mud ..........................................192
sand .........................................192
snow and ice ...................192±193
Index
305

Item Information
Required fuel Unleaded fuel only - 87 octane
Fuel tank capacity 85.2L (22.5 gallons)
4.0L Engine oil capacity
(includes filter change)4.7L (5.0 quarts). Use Motorcraft
SAE 5W-30 Super Premium Motor
Oil, Ford specification
WSS-M2C153-G.
4.6L Engine oil capacity
(includes filter change)5.7L (6.0 quarts). Use Motorcraft
SAE 5W-20 Super Premium Motor
Oil, Ford specification
WSS-M2C153-H.
Tire size and pressure Refer to the Certification Label on
inside of driver's door.
Hood release Pull handle under the instrument
panel.
Coolant capacity-(4.0L SOHC V6
engine without auxiliary climate
control)
1
15.4L (16.3 quarts)
Coolant capacity-(4.0L SOHC V6
engine with auxiliary climate
control)
1
17.2L (18.2 quarts)
Coolant capacity (4.6L V8 engine
without auxiliary climate control)
117.6L (18.6 quarts)
Coolant capacity (4.6L V8 engine
with auxiliary climate control)
119.0L (20.1 quarts)
Power steering fluid capacity Fill to line on reservoir. Use
Motorcraft MERCONtAT F.
Manual transmission
fluid capacity
22.4L (5.1 pints). Use Motorcraft
MERCONtAT F.
Automatic transmission fluid
capacity (5R55W transmission)
212.0L (12.7 quarts). Use
Motorcraft MERCONtV ATF.3
1
Use Ford Premium Engine Coolant (green or yellow in color). DO NOT
USE Ford Extended Life Engine Coolant (orange in color). Refer to
Adding engine coolant, in the Maintenance and Care chapter.
2Ensure the correct automatic transmission fluid is used. MERCONtand
MERCONtV are not interchangeable. DO NOT mix MERCONtand
Filling station information
311
