1-56
2. Push the latch plate into the buckle until it clicks.
In the third row, if the belt stops before it reaches the
buckle, tilt the latch plate and keep pulling until you
can buckle it.
Third Row Outside Passenger Position
Pull up on the latch plate to make sure it is secure.When the shoulder belt is pulled out all the way, it
will lock. If it does, let it go back all the way and
start again. If the belt is not long enough, see ªSafety
Belt Extenderº at the end of this section. Make sure
the release button on the buckle is positioned so you
would be able to unbuckle the safety belt quickly if
you ever had to.
3. To make the lap part tight, pull down on the buckle
end of the belt as you pull up on the shoulder part.

2-106 Anti-Lock Brake System Warning Light
The anti-lock brake
system warning light
should come on for
a few seconds when
you turn the ignition
key to RUN.
If the anti
-lock brake system warning light stays on
longer than normal after you've started your engine, turn
the ignition off. Or, if the light comes on and stays on
when you're driving, stop as soon as possible and turn
the ignition off. Then start the engine again to reset the
system. If the light still stays on, or comes on again
while you're driving, the anti
-lock brake system needs
service and you don't have anti
-lock brakes.
The anti
-lock brake system warning light should come
on briefly when you turn the ignition key to RUN. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.
Traction Control System Warning
Light (Option)
United States Canada
The traction control system warning light may come on
for the following reasons:

If you turn the system off by pressing the TCS
button located in the instrument panel switchbank
the warning light will come on and stay on. To turn
the system back on, press the button again. The
warning light should go off. See ªTraction Control
Systemº in the Index for more information.

3-22
4 FWD (Forward): Press and hold this pushbutton to
advance quickly within a track. Press and hold this
pushbutton for less than two seconds to advance at
six times the normal playing speed. Press and hold it
for more than two seconds to advance at 17 times the
normal playing speed. Release it to play the track.
The display will show ET and the elapsed time.
6 RDM (Random): Press this pushbutton to hear the
tracks in random, rather than sequential, order. RDM
ON will appear on the display. RDM T and the track
number will appear on the display when each track starts
to play. Press RDM again to turn off random play.
RDM OFF will appear on the display.
 SEEK
: Press the left arrow to go to the start of the
current or previous track. Press the right arrow to go to
the start of the next track. If either of the arrows is held
or pressed more then once, the player will continue
moving backward or forward through the CD.DISP (Display): Press this knob to see how long the
current track has been playing. ET and the elapsed time
will appear on the display. To change what is normally
shown on the display (track or elapsed time), press the
knob until you see the display you want, then hold the
knob for two seconds. The radio will produce one beep.
BAND: Press this button to listen to the radio
when a CD is playing. The CD will stop but remain
in the player.
CD AUX (Auxiliary): Press this button to play a CD
when listening to the radio. The inactive CD will remain
safely inside the radio for future listening. EJT (Eject): Press this button to stop a CD when it
is playing or to eject a CD when it is not playing. Eject
may be activated with either the ignition or radio off.
CDs may be loaded with the radio and ignition off if this
button is pressed first.

3-33
4 FWD (Forward): Press and hold this pushbutton to
advance quickly within a track. Press and hold this
pushbutton for less than two seconds to advance at six
times the normal playing speed. Press and hold it for
more than two seconds to advance at 17 times the
normal playing speed. Release it to play the passage.
The display will show ET and the elapsed time.
6 RDM (Random): Press this pushbutton to hear the
tracks in random, rather than sequential, order. RDM
ON will appear on the display. RDM T and the track
number will appear on the display when each track starts
to play. Press it again to turn off random play. RDM
OFF will appear on the display.
 SEEK
: The right arrow is the same as the NEXT
pushbutton, and the left arrow is the same as the PREV
pushbutton. If either of the SEEK arrows is held or
pressed more then once, the player will continue moving
backward or forward through the CD.
DISP (Display): Press this knob to see how long the
current track has been playing. ET and the elapsed time
will appear on the display. To change what is normally
shown on the display (track or elapsed time), press this
knob until you see the display you want, then hold this
knob for two seconds. The radio will produce one beep.
BAND: Press this button to listen to the radio when a disc
is playing. The disc will stop but remain in the player.TAPE CD: Press this button to play a CD when
listening to the radio. Press TAPE CD to switch between
the tape and compact disc if both are loaded. The
inactive tape or CD will remain safely inside the radio
for future listening.
EJT (Eject): Press this button, located to the right
of the CD slot, to eject a CD. Eject may be activated with
either the ignition or radio off. CDs may be loaded with
the radio and ignition off if this button is pressed first.
Compact Disc Messages
If the disc comes out, it could be for one of the
following reasons:
If you're driving on a very rough road. When the
road becomes smooth the disc should play.
If it's very hot. When the temperature returns to
normal, the disc should play.
The disc is upside down.
It is dirty, scratched or wet.
The air is very humid. (If so, wait about an hour and
try again.)
If the CD is not playing correctly, for any other
reason, try a known good CD.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer.

3-40
To load more than one disc but less than six, complete
Steps 1 through 3. When you have finished loading
discs, with the radio on or off, press the LOAD side of
the LOAD CD button to cancel the loading function.
The radio will begin to play the last CD loaded.
When a disc is inserted, the CD symbol will be
displayed. If more than one disc has been loaded, a
number for each disc will be displayed. If you select an
equalization setting for your disc, it will be activated
each time you play a disc.
If the radio is on or off, the last disc loaded will begin to
play automatically.
As each new track starts to play, the track number will
appear on the display.
Playing a Specific Loaded Compact Disc
For every CD loaded, a number will appear on the radio
display. To play a specific CD, first press the CD AUX
button to start playing a CD. Then press the numbered
pushbutton that corresponds to the CD you want to play.
A small bar will appear under the CD number that is
playing, and the track number will appear.
If an error appears on the radio display, see ªCompact
Disc Messagesº later in this section.LOAD CD (Eject): The CD eject side of this
button will eject a disc or discs, if you have multiple
discs loaded. To eject a disc or discs from the disc
player, perform one of the following steps:

Press and release the CD eject side of the LOAD CD
button to eject the disc that is currently playing, or

to eject all of the discs, press the CD eject side of the
LOAD CD button for two seconds, you will hear a
beep, and the light will flash to let you know when a
disc is being ejected.
When the CD eject side of the LOAD CD button is
pressed, the receiver will eject the disc and REMOVE
CD will be displayed. You can now remove the disc. If
the disc is not removed, after 25 seconds, the disc will
be automatically pulled back into the receiver. If you try
to push the disc back into the receiver, before the 25
second time period is complete, the receiver will sense
an error and will try to eject the disc several times
before stopping.
Do not repeatedly press the CD eject side of the LOAD
CD eject button to eject a disc after you have tried to
push it in manually. The receivers 25
-second eject timer
will reset at each press of eject, which will cause the
receiver to not eject the disc until the 25
-second time
period has elapsed.

3-41
Once the player stops and the disc is ejected, remove the
disc. After removing the disc, press the PWR knob off
and then on again. This will clear the disc
-sensing
feature and enable discs to be loaded into the
player again.

REV (Reverse): Press and hold this button to reverse
quickly within a track. You will hear sound at a reduced
volume. Release it to play the passage. The display will
show elapsed time.
FWD  (Forward): Press and hold this button to
advance quickly within a track. You will hear sound at a
reduced volume. Release it to play the passage. The
display will show elapsed time.
RPT (Repeat): With repeat, you can repeat one track or
an entire disc. To use repeat, do the following:

To repeat the track you are listening to, press and
release the RPT button. RPT will appear on the
display. Press RPT again to turn it off.

To repeat the disc you are listening to, press and hold
the RPT button for two seconds. RPT will appear on
the display. Press RPT again to turn if off.RDM (Random): With random, you can listen to the
tracks in random, rather than sequential order, on one
disc or on all of the discs. To use random, do one of
the following:

To play the tracks on the disc you are listening to in
random order, press and hold RDM for more than
two seconds. You will hear a beep and RANDOM
ONE will appear on the display. Press RDM again to
turn if off.

Press and release the RDM button to play the tracks
on all of the discs that are loaded in random order.
RANDOM ALL will appear on the display. Press
RDM to turn it off.
AUTO EQ (Automatic Equalization): Press AUTO
EQ to select the desired preset equalization setting while
playing a compact disc. The equalization will be
automatically set whenever you play a compact disc. For
more information on AUTO EQ, see ªAUTO EQº listed
previously in this section.


SEEK : To seek, press the left arrow while
playing a CD to go to the start of the current track, if
more than ten seconds have passed. Press the right arrow
to go to the next track. If you press the button more than
once, the player will continue moving backward or
forward through the disc.

3-46
Battery Replacement
To change the batteries, do the following:
1. Slide open the battery door located on the left side of
the headphones.
2. Remove the batteries from the compartment.
3. Replace the two AAA batteries. Make sure that they
are installed correctly.
If the headphones are to be stored for a long period
of time, remove the batteries and keep them in a cool,
dry place.
Stereo RCA Jacks
The RCA jacks are located on the faceplate of the DVD
player. They allow you to hook up an auxiliary device
such as a camcorder or a video game unit. You may
require adapter connectors or cables to connect your
auxiliary device to the RCA jacks. Refer to the
manufacturer's instructions for proper usage.
The entertainment system will always start in the
auxiliary mode. To use the auxiliary function, connect a
camcorder or a video game unit to the RCA jacks and
turn on the auxiliary device. If you want to view a DVD,insert the DVD into the DVD player. The system will
automatically switch to DVD and start to play. To return
to the auxiliary device, just press the stop button to stop
the DVD or use the remote control. See ªRemote
Controlº later in this section for more information.
Audio Speakers
Only one audio source can be heard through the
speakers at one time.
Audio from the radio, cassette or CD player will be
heard through all speakers when the front audio system
is being used and the rear seat audio system is off.
Sound from the DVD player or an auxiliary device can
be heard through all speakers when the front audio
system and rear seat audio are off and a DVD or
auxiliary device is playing.
When the front audio system is on, to hear the DVD,
auxiliary device or the rear seat audio system you must
use the headphones. With the rear seat audio system on,
the speaker in the overhead console and the rear
speakers are muted.
The speaker in the overhead console is set at a low level
and is not intended to be heard at a high volume.

3-48 DVD Player
The DVD player is located in the front floor console.
The DVD player can be controlled by the buttons on
the DVD player and by the buttons on the remote
control. See ªRemote Controlº later in this section
for more information.The DVD player works while the ignition is in RUN
or ACCESSORY and while RAP is active. See
ªRetained Accessory Power (RAP)º in the Index
for more information.
The entertainment system is only compatible with
DVDs authorized for use in the United States and
Canada. Regular audio CDs can also be played by the
DVD player. Home recorded CDs (CDRs) may not
play in this DVD player. Try the audio system
CD player instead.
DVD Player Buttons
PWR (Power): Press this button to turn the DVD
player on, to change to an auxiliary device or to turn the
system off. (Play/Pause): Press this button to start play.
Press while playing to pause. Press it again to continue
playing.
(Stop/Eject): Press this button to stop playing.
Press the button a second time to eject the disc.
