2-10 Operation
Use the remote keyless
entry transmitter to
open or lock your
vehicle's doors or
trunk from a distance.
Remote Keyless
Entry Transmitter
LOCK: Press the LOCK button to lock all the doors.
UNLOCK: Press the UNLOCK button on the remote
keyless transmitter once to unlock the driver's door and
turn on the interior lamps See ªIllumination and Remote
Activationº in the Index for more details. Pause for
about one second, then press UNLOCK again within
five seconds to unlock the passenger door.
(Panic Alarm): Press the button with the horn
symbol to activate an alarm on the remote keyless
transmitter. The ignition must be in OFF or ACC for the
panic alarm to work. When you press the panic button
on the remote keyless entry transmitter, the headlamps
will flash, the horn will honk repeatedly and your
interior lamps will illuminate attracting attention if you
need it. The alarm will continue until one of the
following occurs:

The panic alarm button on the remote keyless entry
transmitter is pressed a second time,

the vehicle's ignition is turned to ON or

an alarm period of 110 seconds has elapsed.
(Trunk Release): Press the button on the remote
keyless transmitter with the vehicle symbol on it to
release the trunk.
Operating the remote keyless entry transmitter may
interact with the content theft
- deterrent system (if your
vehicle has this option). See ªContent Theft
-Deterrent
Systemº in the Index.

2-11
Transmitter Verification (If Equipped)
This feature provides feedback to the holder of the
remote keyless entry transmitter that a command has
been received by the keyless entry receiver. The
headlamps and back
-up lamps will flash on every lock
and the first unlock command, and the horn will sound
once for every lock and twice for the first unlock
command. Silent operation and other options may be
selected for this feature (see ªVehicle Customization
Settingsº in the Index).
If your vehicle has the optional content theft
-deterrent
system, the first time the remote unlock is received,
three flashes and chirps will be seen to indicate an alarm
condition has occurred since last arming. See ªContent
Theft
-Deterrent Systemº in the Index.
Illumination on Remote Activation
This feature provides interior illumination when a
remote keyless entry unlock command is received and
executed, the trunk release button is pressed or when
the panic alarm is activated. The interior lamps will
illuminate until the ignition is turned to ON or untilan illumination period of 40 seconds has elapsed or the
doors are locked with the power door lock switch or the
remote keyless entry transmitter. If a door is opened
during the illumination period, the timed illumination
will be canceled, and the interior lamps will remain on
while the door is open.
Matching Transmitter(s) to Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have a maximum of four
transmitters matched to it.
If you prefer, you can complete this procedure yourself.
See ªVehicle Customization Settingsº in the Index for
more information.

2-19
Content Theft-Deterrent (Option)
Your vehicle may have the optional content
theft
-deterrent alarm system.
With this system, a light on the radio will flash.
This light reminds you to activate the theft
-deterrent
system. Here's how to do it:
1. Open the door.
2. Lock the door with the power door lock switch or the
remote keyless entry transmitter. The light on the
radio should come on and stay on. If you are using
the remote keyless entry transmitter, the door does
not need to be open.
3. Close all doors. The light on the radio will slowly
flash once the system is armed.
Once armed, the alarm will go off if someone tries to
enter the vehicle (without using the remote keyless entry
transmitter or a key) or turns the ignition on with an
incorrect key. The horn will sound and the headlamps and
back
-up lamps will flash for approximately two minutes.When the alarm is armed, the trunk may be opened with
the remote keyless entry transmitter. If you use the key
to open the trunk, the alarm will sound. The power door
lock switches are also disabled. You must use your
remote keyless entry transmitter or your key to unlock
the doors when the system is armed.
Arming with the Power Lock Switch
Your alarm system will arm when you use either power
lock switch to lock the doors while any door or the trunk
is open and the key is removed from the ignition.
The light on the radio flashes quickly to let you know
when the system is ready to arm with the power door
lock switches. The light on the radio will stop flashing
and stay on when you press the bottom of the power
lock switch, to let you know the system is arming.
After all doors and the trunk are closed and locked, the
light on the radio will flash slowly to let you know the
system is armed.

2-20 Arming with the Remote Keyless
Entry Transmitter
Your alarm system will arm when you use your remote
keyless entry transmitter to lock the doors, if the key is
not in the ignition. The light on the radio will turn on to
let you know the system is arming. After all doors and
the trunk are closed and locked, the light on the radio
will begin flashing at a very slow rate to let you know
the system is armed.
Disarming with the Remote Keyless
Entry Transmitter
Your alarm system will disarm when you use your
remote keyless entry transmitter to unlock the doors.
The light on the radio will go off to let you know the
system is no longer armed.
The first time a remote UNLOCK command is
received, three flashes will be seen and three horn chirps
heard to indicate an alarm condition has occurred since
last arming.
Disarming with Your Key
Your alarm system will disarm when you use your key
to unlock the doors. The light on the radio will go off to
let you know the system is no longer armed.
Vehicle Customization Settings
Some of the convenience features can be reset or
customized to perform according to your preference.
Features you can program depend upon the options
that came with your vehicle. The following list shows
features that can be reset or customized along with
the options.

Settings (Available for All)

Oil Life Reset (Available for All)

Low Tire Pressure Reset (If Equipped)

Delayed Headlamp Illumination (Available for All)

Automatic Door Lock and Unlock (Available for All)

Remote Visual Verification (Available with Remote
Keyless Entry)

Remote Audible Verification (Available with Remote
Keyless Entry)

Content Theft Operation (Optional with Content
Theft System)

Trunk Jamb (Optional with Content Theft System)

2-22
TIRE MON (Tire Inflation Monitor Reset): This feature
allows you to reset the tire pressure monitor after checking all
tire pressures, see ªTiresº in the Index. To clear the LOW
TIRE PRESSURE light from the instrument panel cluster
and reset the low tire pressure monitor:
1. Scroll, using the SEEK up or down arrows, until
TIRE MON appears on the display.
2. Press the PREV or NEXT button to enter the
submenu. RESET will be displayed.
3. Press the DISP button to reset. A chime will be heard
to verify the new setting and DONE will be
displayed for one second.
The low tire pressure monitor is now reset. You can
either exit the programming mode by following the
instructions later in this section or program the next
feature available on your vehicle.
LT DELAY (Delayed Headlamp Illumination): This
feature allows the headlamps and parking lamps to stay
on for a fixed amount of time after you exit the vehicle.
Programmable Modes
Mode 1: OFF
-- Turns feature off.
Mode 2: 30 SEC
-- 30 seconds.
Mode 3: 60 SEC
-- 60 seconds.Before your vehicle was shipped from the factory, it was
programmed to Mode 2. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Scroll, using the SEEK up or down arrows, until LT
DELAY appears on the display.
2. Press the PREV or NEXT button to enter the submenu.
The current selection will have an asterisk (*) next to
it. If you do not wish to change the current mode, you
can either exit the programming mode by following the
directions later in this section or program the next
feature available on your vehicle.
3. Scroll, using the PREV or NEXT buttons, through
the modes to change the current mode.
4. With your preference displayed, press the DISP
button to select. A chime will be heard to verify the
new setting. The new selection will be displayed
with an asterisk (*) for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.

2-47
Tilt Wheel
A tilt steering wheel allows you to adjust the steering
wheel before you drive. You can raise the steering wheel
to the highest level to give your legs more room when
you exit and enter. The lever to adjust it is located on the
left side of the steering column.
To adjust the wheel, hold
the steering wheel and pull
the lever. Move the steering
wheel to a comfortable
level, then release the lever
to lock the wheel into place.
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:

Turn Signal and Lane
-Change Indicator

Headlamp High/Low
-Beam Changer

Flash
-to-Pass Feature

Windshield Wipers

Windshield Washer

Cruise Control (If Equipped)
For more information on the exterior lamps, see
ªExterior Lampsº later in this section.

2-48 Turn Signal and Lane-Change Indicator
The turn signal has two upward (for right) and
two downward (for left) positions. These positions
allow you to signal a turn or a lane change.
To signal a turn, move the lever all the way up or down.
When the turn is finished, the lever will return automatically.
An arrow on the instrument
panel cluster will flash in
the direction of the turn or
lane change.
To signal a lane change, just raise or lower the lever
until the arrow starts to flash. Hold it there until you
complete your lane change. The lever will return by
itself when you release it.
If the arrow flashes faster than normal as you signal a
turn or a lane change, a signal bulb may be burned out
and other drivers won't see your turn signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check for burned
-out bulbs and then check
the fuse (see ªFuses and Circuit Breakersº in the Index).Turn Signal On Chime
If you leave either one of your turn signals on and drive
more than 3/4 mile (1.2 km), a chime will sound to
alert you.
Headlamp High/Low-Beam Changer
To change your headlamps from low beams to high
beams, or high to low, pull the multifunction lever all
the way toward you. Then release it.
When the high beams are
on, this light on the
instrument panel cluster
also will be on.
This light works only when the ignition key is in the ON
position, and your fog lamps (if equipped) will not be
illuminated when your high beams are on.

2-49
Flash-to-Pass Feature
With the turn signal lever in the low-beam position, pull
the lever toward you momentarily to switch to
high
-beams (to signal that you are going to pass).
If you have the headlamps on, they will return to
low
-beams when you release the lever.
This feature operates even when the headlamps are off.
Windshield Wipers
The windshield wipers will operate with the ignition in
ACC or ON.
WIPER: To operate the windshield wipers, turn the
band labeled WIPER, located on the multifunction lever,
upward or downward.
OFF: To stop the wipers turn the band to OFF.
The five marks between OFF and LO are delay settings.
For a longer delay between wiping cycles, turn the band
downward. For a shorter delay between wiping cycles
turn the band upward.LO (Low Speed): Turn the band up to LO for a steady
wiping at a low speed.
HI (High Speed): Turn the band up to HI for a steady
wiping at a high speed.
MIST: Turn the band downward to MIST for a single
wiping cycle. Hold the band at this setting until the
windshield wipers start, then release it. The windshield
wipers will stop after one wipe. If additional cycles are
needed, hold the band on MIST longer.
Be sure to clear ice and snow from the wiper blades
before using them. Hold the band at this setting until the
windshield wipers start, then release it. The windshield
wipers will stop after one wipe. If additional cycles are
needed, hold the band on MIST longer.
Heavy snow or ice can overload your wipers. A circuit
breaker will stop them until the motor cools. Clear away
snow or ice to prevent an overload. If your blades
become damaged, get new blades or blade inserts.
