2002 CHEVROLET CAMARO remote control

2-13
Resynchronization
Resynchronization may be necessary due to the security
method used by the remote keyless entry system.
The transmitter does not send the same signal twice to
the receiver. The receiver will not respond to a signal
that has been sent previously. This prevents anyone
from recording and playing back the signal from
the transmitter.
To resynchronize the transmitter with the receiver,
do the following:
1. Stand close to the vehicle.
2. Press and hold the LOCK and UNLOCK buttons
on the transmitter at the same time for about
eight seconds.
The door locks should cycle and the interior lamps
should flash to confirm resynchronization.
If this does not happen, you may need to replace the
battery in your transmitter or match the transmitter to
your vehicle. See ªMatching Transmitter(s) to Your
Vehicleº in the Index.
Hatch
CAUTION:
It can be dangerous to drive with the hatch open
because carbon monoxide (CO) gas can come into
your vehicle. You can't see or smell CO. It can
cause unconsciousness and even death.
If you must drive with the hatch open or if
electrical wiring or other cable connections
must pass through the seal between the body
and the hatch:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on vent. That will force outside air into
your vehicle. See ªComfort Controlsº in
the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.

2-14 Hatch Release
Your door key opens the hatch from the outside. If your
vehicle has the content theft
-deterrent/alarm system and
the system is armed, opening the hatch this way will
trigger the alarm. First, disarm the system or use the
remote keyless entry transmitter to open the hatch. See
ªContent Theft
-Deterrent/Alarm Systemº in the Index.
Remote Hatch Release (If Equipped)
Press the button located
under the exterior lamp
control on the driver's side
below the instrument panel
to unlock the hatch from
inside your vehicle.If you have an automatic transmission, the shift lever
must be in PARK (P) or NEUTRAL (N) to use the
remote hatch release. If you have a manual transmission
and the ignition is in RUN, you must set the parking
brake before you can use the remote hatch release.
This button only works when the ignition is in RUN,
ACCESSORY or when RAP is active. See ªRetained
Accessory Power (RAP)º in the Index.NOTICE:
If you put things in the hatchback area, be sure
they won't break the glass when you close it.
Never slam the hatch down. You could break the
glass or damage the defogger grid (if equipped).
On vehicles with the content theft-deterrent/alarm
system the remote hatch release button will not
work while the system is armed. See ªContent
Theft
-Deterrent/Alarm Systemº in the Index.

2-61
Interior Lamps
Instrument Panel Brightness Control
This feature controls the brightness of the instrument
panel lights.
The thumbwheel for this feature is located on the
instrument panel to the left of the steering column.
Move the thumbwheel up or down to brighten or dim
the lights. If you move the thumbwheel all the way up,
your courtesy lamps will come on.
Courtesy Lamps
When either door is opened, several interior lamps go
on. These lamps are courtesy lamps. They make it easier
for you to enter and leave your vehicle.
Courtesy lamps include two map lamps on the inside
rearview mirror and other lamps throughout the interior
of your vehicle.
To prevent battery rundown, your interior lamps will be
disabled about 10 minutes after the ignition is turned to
OFF. The 10
-minute timer will be restarted if you do
any of the following:

Turn the ignition on.

Open either door.

Press any button on your remote keyless entry
transmitter (option).

Turn the interior lamps from off to on.

Open the hatch.

2-63
Power Remote Control Mirrors
(If Equipped)
The power mirror control is located on the driver's door.
To adjust either mirror, turn the selector switch to
L (left) or R (right). Then push the control in the
direction that you want the mirror to go.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.

2-83
The main components of your instrument panel are the following:
A. Air Vents
B. Exterior Lamp Control
C. Instrument Panel Cluster
D. Horn
E. Fog Lamp Switch (Option)
F. Acceleration Slip Regulation (ASR) Button (Option)
G. Audio System
H. Comfort Control System
I. Glove Box
J. Remote Hatch Release (If Equipped)K. Audio Steering Wheel Controls (If Equipped)
L. Rear Window Defogger Button
M. Convertible Top Switch (If Equipped)
N. Ashtray
O. Shift Lever (Automatic Transmission Shown)
P. Cupholders
Q. Storage Console
R. Parking Brake Lever
S. Cigarette Lighter
T. Accessory Power Outlet

6-66
Main Fuse BlockFuse Usage
STOP/HAZARD Hazard Flashers, Brake
Switch Assembly
TURN B/U Traction Control/Second
-Gear
Start Switch, Back
-Up Lamp
Switch, Turn Flasher, Daytime
Running Lamps (DRL) Module
STG
WHL CNTRLSteering Wheel Controls
RADIO ACCY Delco Monsoon Radio Amplifier,
Remote CD Player (Trunk)
TAIL LPS Daytime Running Lamps (DRL)
Module, Headlamp Switch
HVAC HVAC Selector Switch, Rear
Defogger Switch/Timer
PWR ACCY Parking Lamp Relay, Hatch
Release Relay, Power Mirror
Switch, Radio, Shock Sensor,
Instrument Cluster
