2002 CADILLAC DEVILLE remote control

1-5 Memory Seat, Mirrors and Steering Wheel
(If Equipped)
The controls for these
features are located on the
driver's door panel, and are
used to program and recall
memory settings for the
driver's seating positions.
Use the following steps to program each button:
1. Adjust the driver's seat (including the seatback
recliner, lumbar, head restraint and shoulder belt
height adjustments), both outside mirrors and the
steering wheel to a comfortable position.
2. Press the SET button.3. Within five seconds, press button 1. A single beep
will sound through the driver's side front speaker to
let you know that the position has been stored.
A second mirror, seating and steering wheel position can
be programmed by repeating the above steps and
pressing button 2 (for driver 2). Each time a memory
button is pressed, a single beep will sound. Each time
button 1 or 2 is pressed and released while the vehicle
is in PARK (P), the memory positions will be recalled.
If the vehicle is not in PARK (P), the memory buttons
must be pressed and held to recall the stored positions.
If you use the remote keyless entry transmitter to enter
your vehicle, automatic seat and mirror movement will
occur. The numbers on the back of the transmitters,
1 and 2, correspond to the numbers on the buttons on
the door panel.
When the key is placed in the ignition in OFF if you
have entered the vehicle without using the remote
keyless entry transmitter, the seats and mirrors will
automatically adjust to the programmed position of
the last driver.
To stop recall movement of the memory feature at
any time, press one of the power seat controls or
memory buttons.

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything
is working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-5 Keys
2
-7 Door Locks
2
-10 Remote Keyless Entry System
2
-14 Trunk
2
-17 Theft
2
-18 Theft-Deterrent System
2
-20 PASS-Key
III
2
-22 New Vehicle ªBreak-Inº
2
-23 Ignition Positions
2
-25 Starting Your Engine
2
-26 Engine Coolant Heater (If Equipped)
2
-28 Automatic Transaxle Operation
2
-34 Parking Brake
2
-36 Shifting Into PARK (P)
2
-39 Shifting Out of PARK (P)
2
-39 Parking Over Things That Burn
2
-40 Engine Exhaust
2
-40 Running Your Engine While You're Parked2
-41 Tilt Wheel
2
-43 Turn Signal/Multifunction Lever
2
-50 Exterior Lamps
2
-56 Interior Lamps
2
-59 Mirrors
2
-63 Storage Compartments
2
-67 Rear Power Sunshade (If Equipped)
2
-70 Cellular Telephone (Option)
2
-70 OnStar
System (If Equipped)
2
-74 Sunroof (Option)
2
-75 HomeLink
Transmitter (If Equipped)
2
-78 The Instrument Panel -- Your
Information System
2
-85 Warning Lights, Gages and Indicators
2
-100 Driver Information Center (DIC)
2
-129 Navigation (Option)
2
-130 Night Vision System (Option)
2
-133 Ultrasonic Rear Parking
Assist (URPA) (Option)

2-14
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on AUTO and the temperature between
65F (18C) and 85F (29C). That will
force outside air into your vehicle. See
ªComfort Controlsº in the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Trunk Lock Release
The trunk lock release
button is located to the left
of the steering wheel on the
instrument panel.
Press the button to open the trunk. To use this feature,
your vehicle must be in PARK (P) or NEUTRAL (N)
and the valet lockout switch must be off.
You can also press the button with the trunk symbol on
the remote keyless entry transmitter to open the trunk.
To disable this feature, see ªValet Lockout Switchº in
the Index.

2-56
Interior Lamps
Instrument Panel Brightness Knob
This feature controls the brightness of the instrument
panel lights.
The knob for this feature is
located to the right of the
Twilight Sentinel lever.
Press the knob to release it to the outward position.
Turn the knob clockwise to brighten the lights or
counterclockwise to dim them. Press the knob to
return it to the original storage position.
Courtesy Lamps
The courtesy lamps are located on the headliner above
the rear seat. These lamps come on by turning the
instrument panel brightness knob fully clockwise or
when any door is opened and it is dark outside. Puddle
lamps are located on the bottom of the front and rear
door trim.
Illuminated Entry
The illuminated entry system turns on the courtesy
lamps and the backlighting to the door switches and to
the exterior lamp control when a door is opened or if
you press the remote keyless entry transmitter unlock
button. If activated due to the transmitter, the lighting
will remain active for about 40 seconds. Since the
illuminated entry system uses the light sensor, it must be
dark outside in order for the courtesy lamps to turn on.
The courtesy lamps turn off approximately 25 seconds
after the last door is closed. They will dim to off if the
ignition key is placed in ON, or immediately deactivate
if the power locks are activated.

2-61
3. Once the zone number appears in the display, press
the on/off button quickly until the correct zone
number appears in the display. Stop pressing the
button and the mirror will return to normal
operation. If C appears in the compass window, the
compass may need calibration. See ªCompass
Calibrationº listed previously.
Power Remote Control Mirror
The control on the driver's
door armrest operates both
outside rearview mirrors.
Press (R) on the selector switch to choose the right
mirror or (L) to choose the left mirror. The center
position is off and will not move the mirrors if the
control pad is touched.
To adjust the mirror, press the arrows on the control pad
in the direction you want the mirror to go. Adjust each
mirror so you can see the side of your vehicle and the
area behind your vehicle.

2-70
Cellular Telephone (Option)
With this option, your vehicle has been prewired for
dealer installation of a portable cellular telephone
system. The system has steering wheel telephone
controls and information output through the Driver
Information Center (DIC). Voice activation with remote
record and hands
-free operation are standard features.
For more information, contact your dealer. A user's
guide is provided with the telephone.
OnStar
System (If Equipped)
OnStar is a vehicle communications system that
offers a variety of services and provides a one
-touch
hands
-free communication link between you and the
OnStar Center. To receive OnStar services, a service
subscription agreement is required and an additional
fee may be required. Services are available 24 hours a
day, 7 days a week. For more information,
call 1
-888-ONSTAR-7 (1-888-667-8277).
OnStar Services Button: Press this button once
to contact an advisor who will be able to assist you with
these services. If you are not quickly connected, the
system will automatically reset and redial. This ensures
connection to the center; there is no additional action
required. Press the Communication button to cancel the
automatic redial.
Emergency Button: In an emergency situation,
press the emergency service button. Upon receiving the
call, an advisor at the center will locate your vehicle and
assess the situation. If necessary, the advisor will alert
the nearest emergency service provider.

2-111
Vehicle Programming and
Personalization Features
Your vehicle is equipped with personalization that
allows you to program certain features to a preferred
setting for up to two people. The number of
programmable features varies depending upon which
model of the vehicle is purchased. On all vehicles,
features such as climate control settings, radio preset
settings, exterior lighting at unlock, remote lock and
unlock confirmation, and automatic door locks have
already been programmed for your convenience.
Some vehicles are equipped with additional features
that can be programmed including the seat position,
steering column position (if equipped) and outside
mirror position. The navigation screen preferences
(if equipped) will remain at the last set position.
If your vehicle is equipped with the ability to program
additional personalization features, the driver's
preferences are recalled by pressing the unlock button
on the remote keyless entry transmitter or by pressing
the appropriate memory button, 1 or 2, located on the
driver's door. Certain features can be programmed not
to recall until the key is placed in the ignition. To change
feature preferences you must use one of the
following procedures.Entering Feature Programming
To enter the feature programming mode, do
the following:
1. Turn the ignition to ON, making sure the vehicle is
in PARK (P).
2. If your vehicle has memory settings, press the
appropriate memory button, 1 or 2, located on
the driver's door panel. The DIC display will
show either 1 or 2 depending on which button
was selected.
3. Press the INFO button until FEATURE
PROGRAMMING appears on the DIC display.
4. Press the ON/OFF button to enter
FEATURE PROGRAMMING.

2-112
Remote Recall Memory (If Equipped)
This feature recalls any previously programmed seat and
mirror controls when the unlock button on the remote
keyless entry transmitter is pressed. The telescoping
steering column (if equipped) will return to its
programmed position when the key is inserted in the
ignition switch and turn to ON.
Programmable Modes
Mode 1: ON
Mode 2: OFFBefore your vehicle was shipped from the factory, it was
programmed to Mode 1. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which the vehicle
is programmed or to program the vehicle to a different
mode, do the following:
1. Enter FEATURE PROGRAMMING following the
instructions listed previously.
2. Press the down arrow on the INFO button until
REMOTE RECALL MEMORY appears on the
DIC display.
3. To turn on the feature, press the ON/OFF button
until ON appears on the DIC display. To turn it off,
press the ON/OFF button until OFF appears on
the display.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
