2-59
NOTICE:
When using accessory power outlets:
Loading of any electrical equipment should
not exceed the maximum fuse rating.
Be sure to turn off any electrical equipment
when not in use. Leaving electrical
equipment on for extended periods can
drain the battery.
When adding electrical equipment, be sure to follow
the proper installation instructions included with
the equipment.
Auxiliary Power Connection
(Power Drop)
Your vehicle is equipped with an auxiliary power
connection. This feature provides power, ground and
accessory wires which can be accessed to add
aftermarket electrical equipment to your vehicle.
It is located on the
passenger's side of
the vehicle, under the
glove box, and is labeled
with a wire function and
fuse rating.
2-65
The Instrument Panel -- Your Information System
The main components of the instrument panel are the following:
A. Exterior Lamps Control
B. Turn Signal/Multifunction Lever
C. Instrument Panel Cluster
D. Audio Steering Wheel Controls
(If Equipped)E. Air Vents
F. Side Window Defogger Vent
G. Hood Release
H. Tilt Wheel Lever
I. HornJ. Audio System
K. Ashtray
L. Climate Control
M. Glove Box
N. Instrument Panel Fuse Block
