2002 BUICK LESABRE remote control

1-4
If you have the independent front cushion moved down
as far as it will go, you may feel the lumbar support
higher in your back. Readjust the location of the cushion
until you are comfortable. You may also want to adjust
the seatback for maximum comfort.
Memory Seat and Mirrors (If Equipped)
If your vehicle has this feature, the controls are located
on the driver's door panel, and are used to program and
recall memory settings for the driver's seating, outside
mirror positions and comfort controls. See ªComfort
Controlsº in the Index for more information.To save your seat and mirror positions into memory, use
the following procedure:
1. First identify the DRIVER # on the Driver
Information Center (DIC) by pressing the MEMORY
button (1 or 2) or by pressing the button with the
unlock symbol on the remote keyless entry
transmitter. See ªDriver Information Center (DIC)º
in the Index.
2. Adjust the driver's seat and lumbar position to a safe
and comfortable driving position. Adjust both outside
mirrors to suit you. See ªMirrorsº in the Index.
3. Press and hold the MEMORY button (1 or 2)
corresponding with your DRIVER # displayed on the
DIC for longer than three seconds. You will hear two
beeps confirming that the seat and mirror positions
have been entered into memory.
To set the seat and mirror positions for a second driver,
follow the previous steps, but start by pressing the
button with the unlock symbol on the transmitter that
displays the other DRIVER # on the DIC. Be sure to use
the MEMORY button (1 or 2) which corresponds to the
DRIVER # identified by the second transmitter.

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-10 Remote Keyless Entry System
2
-16 Trunk
2
-17 Theft
2
-18 Content Theft-Deterrent (If Equipped)
2
-20 PASS-Key
III
2
-22 New Vehicle ªBreak-Inº
2
-22 Ignition Positions
2
-24 Starting Your Engine
2
-25 Engine Coolant Heater (If Equipped)
2
-26 Automatic Transaxle Operation
2
-29 Parking Brake
2
-30 Shifting Into PARK (P)
2
-33 Shifting Out of PARK (P)
2
-33 Parking Over Things That Burn
2
-34 Engine Exhaust2
-34 Running Your Engine While You're Parked
2
-35 Tilt Wheel
2
-36 Turn Signal/Multifunction Lever
2
-43 Exterior Lamps
2
-47 Interior Lamps
2
-50 Mirrors
2
-54 Storage Compartments
2
-58 OnStar
System (If Equipped)
2
-61 Sunroof (Option)
2
-62 HomeLink
Transmitter (If Equipped)
2
-66 The Instrument Panel -- Your
Information System
2
-68 Instrument Panel Clusters
2
-71 Warning Lights, Gages and Indicators
2
-82 Driver Information Center (DIC)
(If Equipped)
2
-92 Head-Up Display (HUD) (If Equipped)

2-16
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on VENT. That will force outside air into
your vehicle. See ªComfort Controlsº in
the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Trunk Lock Release
To unlock the trunk from the outside, insert the master
key and turn it clockwise.
Remote Trunk Release and Trunk Lockout
The TRUNK release button
is located on the driver's
door trim map pocket.
Push this button to open the trunk. The transaxle must
be in PARK (P) or NEUTRAL (N) for the remote trunk
release button to work.
To lock the trunk from inside your vehicle, insert the
master key and turn it clockwise to LOCK. The VALET
key will not work in this procedure.
Trunk Security Override
The remote keyless entry transmitter, will open the trunk
even if the trunk release lockout switch is in LOCK.

2-47
Interior Lamps
Instrument Panel Brightness Control
The lever for this feature is
located to the left of the
steering column.
The brightness of the instrument panel lights can be
adjusted by sliding the INTERIOR lever from LO to HI.
The instrument panel lights will be on only when the
parking lamps are on. The interior courtesy lamps can
be turned on by sliding the INTERIOR lever all the
way to the top, to HI.
Courtesy Lamps
If it is dark enough outside, when any door is opened,
several lamps go on. They make it easy for you to enter
and leave the vehicle. You can also turn these lamps on
by sliding the INTERIOR lever all the way to the top.
Illuminated Entry
If it is dark enough outside when you press the button
with the unlock symbol on the remote keyless entry
transmitter, the interior courtesy lamps will turn on and
stay on for approximately 40 seconds. The lamps will
turn off immediately by pressing the button with the
lock symbol on the remote keyless entry transmitter,
turning the ignition key to RUN or activating the
power door locks.
Delayed Entry Lighting
If it is dark enough outside when you open the door, the
interior lamps will turn on. When you close the door
with the ignition off, the interior lamps will stay on for
up to 25 seconds or until the ignition is turned to an on
position. When the lamps turn off as a result of the
25 second timer or the ignition switch being turned on,
the lighting will deactivate via the theater dimming
effect. Locking the doors will override the delayed entry
lighting feature and the lamps will turn off right away.

2-53 Power Remote Control Mirrors
The controls for the power
remote mirrors are located
on the driver's door armrest.
Press the left or right side of the L/R selector switch
located beneath the control pad to choose the left or
right mirror.
To adjust the mirror, press one of the four arrows located
on the control pad to move the mirror in the direction
you want it to go. When finished adjusting the mirrors,
leave the L/R selector switch in the center position, to
prevent unwanted mirror movement in case the control
pad is accidentally bumped while driving. Adjust each
outside mirror so that you can see a little of your
vehicle, and the area behind your vehicle.
Parallel Park Assist Mirror (If Equipped)
If you have the Memory Seat and Mirrors feature,
the passenger's outside rearview mirror includes a
tilt
-down feature that operates when the shift lever is
in REVERSE (R). This feature assists the driver,
improving rear obstacle detection. When the vehicle is
shifted out of REVERSE (R), the passenger mirror will
return to its original position after a five
-second delay.
This delay prevents movement of the mirror if multiple
gear transitions (REVERSE (R) to AUTOMATIC
OVERDRIVE (
) to REVERSE (R)) occur
during a parallel parking maneuver. This feature can
be programmed on or off through the personal choice
selection menu. See ªDIC Personal Choice Programmingº
in the Index for programming instructions.

2-86
When the STABILITY SYSTEM ACTIVE message is
on, you should continue to steer in the direction you
want to go. The system is designed to help you in bad
weather or other difficult driving situations by making
the most of whatever road conditions will permit. If the
STABILITY SYSTEM ACTIVE message comes on,
you'll know that something has caused your vehicle to
start to spin, so you should consider slowing down.
DIC Personal Choice Programming
The DIC can be used to program the following personal
choice features available with your vehicle:

Automatic Door Locks

Window Lockout

Security Feedback

Delayed Locking

Perimeter Lighting

Memory Seats (If Equipped)

Tilt Mirrors (If Equipped)

Driver ID ON/OFF

Language SelectionFor vehicles not equipped with a DIC, see ªPersonal
Choice Programmingº in the Index.
The personal choice settings displayed on the DIC are
determined by the transmitter used to enter the vehicle.
Each remote keyless entry transmitter was
pre
-programmed to belong to DRIVER 1 or DRIVER 2
and is numbered on the back. After the button with the
unlock symbol on a remote keyless entry transmitter is
pressed and the ignition is in RUN, the DIC will display
the identified driver and recall the settings previously
programmed for that driver. The settings can also be
recalled by briefly pressing one of the MEMORY
buttons located on the driver's door.
If you unlock the vehicle using your door key instead of
your transmitter, the DIC will not change drivers and
will recall the information from the last transmitter used
or the last driver using the memory seat controls. If this
happens and you were not the last driver of the vehicle,
simply press your correct driver number on the memory
seat controls or press the button with the unlock symbol
on your remote keyless entry transmitter.

2-87
Use the following steps for personal choice
programming instructions.
1. Turn the ignition on and keep the transaxle
in PARK (P).
2. Inform the DIC which driver you are by pressing
the button with the unlock symbol on your remote
keyless entry transmitter or the appropriate memory
seat control.
3. Press and hold the ENG/MET button for five
seconds. WELCOME TO BUICK OPTION
FEATURE will appear in the display.
4. The first choice to be made will be DRIVER ID 1
or 2. Press the ENG/MET button to toggle between
your selections within a display and RESET to
choose the current selection and move on to the
next personal choice feature.
If you would like to exit the selection mode without
moving through each of the personal choice features,
simply press a different button on the DIC or turn off the
ignition. Whatever personal choices you made will still
be retained, even without passing through each of the
features. In order for your personal choices to save, you
must press RESET after making your selections.If you happen to move past a selection you would like
to make a personal choice for, press the button with the
unlock symbol on your remote keyless entry transmitter
or press the appropriate driver number on the seat
control. This will return you to the beginning of the
option feature programming mode.
Automatic Door Locks
The door lock modes when shifting in and out of
PARK (P), can be changed through the DIC. You
can change these modes by different selections of the
following DIC displays:

AUTO DOOR LOCKS
-- OFF/ON

UNLOCK
-- OFF/ON

UNLOCK
-- KEY OFF/PARK

DOOR TO UNLOCK
-- DRIVER/ALL
If you choose OFF for AUTO DOOR LOCKS,
your door locks will operate normally with no
automatic feature.
If you choose ON for AUTO DOOR LOCKS, ON for
UNLOCK and KEY OFF, your doors will lock every
time you shift out of PARK (P), and the doors will
unlock every time you stop and turn the ignition to OFF.

2-90
Perimeter Lighting
When the button with the unlock symbol on the remote
keyless entry transmitter is pressed, the DRL
(high
-beams at reduced intensity), parking lamps and
back
-up lamps will turn on if it is dark enough
according to the Twilight Sentinel.
You can control activation of this feature by choosing
OFF or ON when the PERIMETER LIGHTS choice is
displayed on the DIC. Make your choice by pressing the
ENG/MET button and record your choice by pressing
the RESET button. You will then be prompted to choose
a TIMEOUT period. See ªExterior Lightsº following for
more information.
For more information on this feature, see ªPerimeter
Lightingº in the Index.
Exterior Lights
The EXTERIOR LIGHTS/TIMEOUT feature can be
changed to a desired setting by using the ENG/MET to
toggle from 5 to 30 seconds. Each toggle will increase
the time by five seconds. Once the desired timeout is
displayed, press RESET to record your choice and move
on to the next personal choice feature.Memory Seat Recall (If Equipped)
This feature recalls the position of your seat. When this
feature is active, the memory seat and mirror positions
will be recalled for the identified driver when the remote
keyless entry transmitter is used to enter the vehicle.
You can program this feature to be active by choosing
ON when the SEAT RECALL choice appears, or
inactive by choosing OFF when the SEAT RECALL
choice appears on the DIC. Make your choices by
pressing the ENG/MET button and store them to
memory by pressing the RESET button.
You can also program this feature to recall your memory
seat position or the exit seat position.
MEMORY: Choose ON when the SEAT RECALL
choice appears, and then choose MEMORY when the
RECALL POSITION choice appears.
