2-39 Rainsense
II Wipers (If Equipped)
The moisture sensor is mounted on the interior of the
windshield below the rearview mirror and is used to
automatically operate the wipers. This system operates
by monitoring the amount of moisture build
-up on
the windshield. Wipes occur as needed to clear the
windshield depending on the driving conditions and
the sensitivity setting. In light rain or snow, fewer wipes
will occur. In heavy rain or snow, wipes will occur more
frequently. The system will operate in the delay, low
speed and high speed modes. If the system is left on
for long periods of time, occasional wipes may occur
without any moisture on the windshield. This is normal
and indicates that the Rainsense system is active.
The Rainsense system is activated by turning the wiper
control band to one of the five sensitivity levels within
the delay area. The delay position closest to OFF/MIST
is the lowest sensitivity setting, level one. This allows
more rain or snow to collect on the windshield between
wipes. You can increase the sensitivity of the system and
the frequency of wipes by turning the wiper control
band away from you to the higher sensitivity levels.
The highest sensitivity setting, level five, is closest to
the LO position. A single wipe will occur each time you
turn the wiper control band to a higher sensitivity level
to indicate that the sensitivity level has been increased.
NOTICE:
The wipers must be turned off when going
through a car wash to avoid damage.
The MIST and wash cycles operate as normal and are
not affected by the Rainsense function. The system can
be overridden at any time by manually changing the
wiper control to LO or HI speed.
NOTICE:
Do not place stickers or other items on the
exterior glass surface directly in front of the
rainsensor. Doing this could cause the rainsensor
to malfunction.

2-50 Battery Load Management
The battery load management feature is designed to
monitor the vehicle's electrical load and determine when
the battery is in a heavy discharge condition. During
times of high electrical loading, the engine may idle at a
higher rpm setting than normal to make sure the battery
charges. High electrical loads may occur when several
of the following are on: headlamps, high beams, rear
window defogger, fan at high speed, heated seats (if
equipped) and engine cooling fans.
If your vehicle's battery remains in a heavy discharge
condition for a long period of time, the fan, rear
defogger, heated seats and heated mirrors will be
disabled and the DIC will display BATTERY SAVER
ACTIVE. This can happen either under long periods of
idling or low speed driving with high electrical loading,
or in the event of a charging system fault.
Mirrors
Day/Night Manual Rearview Mirror
When you are sitting in a comfortable driving position,
adjust the mirror so you can see clearly behind your
vehicle. The day
-night adjustment allows you to adjust the
mirror to avoid glare from the headlamps behind you.
Electrochromic Day/Night Rearview Mirror
(If Equipped)
Your vehicle may have an automatic electrochromic
day/night rearview mirror. Your vehicle's mirror may
also contain OnStar

controls.
This is the on/off button for mirrors equipped with
OnStar controls.
When this feature is turned on, the mirror automatically
changes to reduce glare from headlamps behind you.
A photocell on the mirror senses when it is becoming
dark outside. Another photocell built into the mirror face
senses when headlamps are behind you.
At night, when the glare is too high, the mirror will
gradually darken to reduce glare (this change may take a
few seconds). The mirror will return to its clear daytime
state when the glare is reduced.
Mirror Operation
To turn on the automatic dimming feature, press AUTO
(or the on/off button for mirrors equipped with OnStar
controls). To turn off automatic dimming, press OFF
(or the on/off button for mirrors equipped with OnStar
controls). The indicator light will be illuminated when
this feature is active.

2-51 Electrochromic Day/Night Rearview Mirror
with Compass (If Equipped)
Your vehicle may have an electrochromic inside
rearview mirror with a compass. Your vehicle's mirror
may also contain OnStar

controls.
This is the on/off button for mirrors equipped with
OnStar controls.
Pressing the MIRROR button located at the bottom of
the mirror (or the on/off button for mirrors equipped
with OnStar controls), turns the automatic dimming
feature on or off.
The mirror also includes an eight
-point compass display
in the upper right corner of the mirror face. When on,
the compass automatically calibrates as the vehicle
is driven.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause the
liquid cleaner to enter the mirror housing.
Mirror Operation
To turn on the automatic dimming feature, press
the MIRROR button located at the bottom of the
mirror (or press and hold the on/off button for aboutthree seconds for mirrors equipped with OnStar controls).
To turn off automatic dimming, press MIRROR (or press
and hold the on/off button for about three seconds for
mirrors equipped with OnStar controls) again. The green
indicator light will be illuminated when this feature is
active. The automatic dimming feature will be active each
time the vehicle is started.
Compass Operation
Press COMPASS (or the on/off button for mirrors
equipped with OnStar controls) once to turn the
compass on or off.
When the ignition and the compass feature are on, the
compass will show two character boxes for
approximately two seconds. After two seconds, the
mirror will display the compass heading.
Compass Calibration
If, after two seconds, the display does not show a
compass heading (N for North, for example), there may
be a strong magnetic field interfering with the compass.
Such interference may be caused by a magnetic antenna
mount, magnetic note pad holder or a similar magnetic
item. If the letter C should ever appear in the compass
window, the compass may need calibration.

2-53 Power Remote Control Mirrors
The controls for the power
remote mirrors are located
on the driver's door armrest.
Press the left or right side of the L/R selector switch
located beneath the control pad to choose the left or
right mirror.
To adjust the mirror, press one of the four arrows located
on the control pad to move the mirror in the direction
you want it to go. When finished adjusting the mirrors,
leave the L/R selector switch in the center position, to
prevent unwanted mirror movement in case the control
pad is accidentally bumped while driving. Adjust each
outside mirror so that you can see a little of your
vehicle, and the area behind your vehicle.
Parallel Park Assist Mirror (If Equipped)
If you have the Memory Seat and Mirrors feature,
the passenger's outside rearview mirror includes a
tilt
-down feature that operates when the shift lever is
in REVERSE (R). This feature assists the driver,
improving rear obstacle detection. When the vehicle is
shifted out of REVERSE (R), the passenger mirror will
return to its original position after a five
-second delay.
This delay prevents movement of the mirror if multiple
gear transitions (REVERSE (R) to AUTOMATIC
OVERDRIVE (
) to REVERSE (R)) occur
during a parallel parking maneuver. This feature can
be programmed on or off through the personal choice
selection menu. See ªDIC Personal Choice Programmingº
in the Index for programming instructions.

2-54 Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from
the driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder
before changing lanes.
Automatic Dimming/Heated Outside
Rearview Mirror (If Equipped)
If you have this feature, the outside driver's mirror will
adjust for the glare of headlamps behind you. This
feature is controlled using the on and off settings on
the automatic electrochromic day/night rearview mirror.
See ªElectrochromic Day/Night Rearview Mirrorº
earlier in this section.
When you operate the rear window defogger, a defogger
also warms the heated driver's and passenger's outside
rearview mirrors to help clear them of ice and snow.
Storage Compartments
Glove Box
Use the door key to lock and unlock the glove box.
To open, lift the latch release on the left side of the
glove box door.

4-16
Driving at Night
Night driving is more dangerous than day driving.
One reason is that some drivers are likely to be
impaired
-- by alcohol or drugs, with night vision
problems, or by fatigue.Here are some tips on night driving.

Drive defensively.

Don't drink and drive.

Adjust your inside rearview mirror to reduce the
glare from headlamps behind you.

Since you can't see as well, you may need to
slow down and keep more space between you and
other vehicles.

Slow down, especially on higher speed roads. Your
headlamps can light up only so much road ahead.

In remote areas, watch for animals.

If you're tired, pull off the road in a safe place
and rest.

4-24
Highway Hypnosis
Is there actually such a condition as ªhighway hypnosisº?
Or is it just plain falling asleep at the wheel? Call it
highway hypnosis, lack of awareness, or whatever.
There is something about an easy stretch of road with
the same scenery, along with the hum of the tires on the
road, the drone of the engine, and the rush of the wind
against the vehicle that can make you sleepy. Don't let
it happen to you! If it does, your vehicle can leave the
road in less than a second, and you could crash and
be injured.
What can you do about highway hypnosis? First, be
aware that it can happen.
Then here are some tips:

Make sure your vehicle is well ventilated, with a
comfortably cool interior.

Keep your eyes moving. Scan the road ahead and
to the sides. Check your rearview mirrors and your
instruments frequently.

If you get sleepy, pull off the road into a rest, service
or parking area and take a nap, get some exercise, or
both. For safety, treat drowsiness on the highway as
an emergency.
Hill and Mountain Roads
Driving on steep hills or mountains is different from
driving in flat or rolling terrain.
