2002 BMW M3 COUPE technical data

5n

OverviewControlsMaintenanceRepairsDataIndex

Controls and features
Operation, maintenance

Lamps:

Parking lamps/Low beams80
Instrument lighting81
High beams/Standing lamps81
Fog lamps82
Interior lamps82
Reading lamps82

Controlling the climate for
pleasant driving:

Air conditioner83
Automatic climate control86
Roller sun blind89

Interior conveniences:

Sound system90
Glove compartment90
Storage compartments91
Cellular phone92
Ashtray, front92
Ashtray, rear93
Clothes hooks93

Loading and transporting:

Through-loading system94
Ski bag95
Cargo loading96
Roof-mounted luggage rack97

Special operating instructions:

Break-in procedure100
Driving notes101
Antilock Brake System101
Brake system102

Wheels and tires:

Tire inflation pressure103
Tire condition103
Tire replacement104
Wheel and tire
combinations105
Special characteristics of winter
tires106
Snow chains106

In the engine compartment:

Hood107
Engine compartment
essentials108
Washer fluids109
Engine oil110
Coolant112
Brake fluid113

Maintenance:

The BMW Maintenance
System114

Laws and regulations:

Technical modifications115
California Proposition
65 Warning115
OBD interface socket116

Contents

Owner service procedures
Technical data
Index

Replacement procedures:

Onboard tool kit120
Windshield wiper blades120
Lamps and bulbs120
Repairing a flat tire126
Battery130
Fuses130

Giving and receiving
assistance:

Jump-starting131
Towing the vehicle132Engine data136
Dimensions137
Weights138
Capacities139Everything from A to Z142

13n

OverviewControlsMaintenanceRepairsDataIndex

Overview
Controls and features
Operation, maintenance
Owner service procedures
Index Technical data



Overview

27n
OverviewControlsMaintenanceRepairsDataIndex
Overview
Controls and features
Operation, maintenance
Owner service procedures
Index Technical data

97n
OverviewControlsMaintenanceRepairsDataIndex
Cargo loading Roof-mounted luggage rack
*
Securing the cargo in the luggage
compartment >For small, light items, use the rubber-
lined non-skid side of the floor mat or
secure with a luggage compartment
net
* or elastic straps, refer to
page 36
>For large, heavy pieces, see your
BMW center for load-securing
devices
*. Lashing eyes (arrow) are
provided at the inner corners of the
luggage compartment for attaching
these load-securing devices.
Read and comply with the information
enclosed with the load-securing
devices.
A special luggage system is available
as an option for your BMW. Please
observe the precautions included with
the installation instructions.AnchorsAccess to the anchors:
To fold up the covers (arrow), please
use the tool which is provided with the
luggage system.Loading and driving notesBecause roof racks raise the center of
gravity of the vehicle when loaded, they
exercise a major effect on its handling
and steering response.
When loading, be sure to remember not
to exceed the approved roof weight,
the approved gross vehicle weight or
the axle loads. You will find the specifi-
cations under "Technical Data" on
page 138.
Make sure that the load is not too
heavy, and attempt to distribute it
evenly. Always load the heaviest pieces
first (on the bottom). Be sure that
adequate clearance is maintained for
raising the sliding/tilt sunroof, and that
objects do not project into the opening
path of the luggage compartment lid.
Secure the roof luggage correctly
and securely to prevent it from
shifting or being lost during driving
(danger for following traffic).<
Drive smoothly and avoid sudden
acceleration or braking. Do not corner
at high speeds.

99n
OverviewControlsMaintenanceRepairsDataIndex
Overview
Controls and features
Operation, maintenance
Owner service procedures
Index Technical data
Mainte-

107n
OverviewControlsMaintenanceRepairsDataIndex
To releasePull the lever located under the left-
hand side of the instrument panel.
Do not attempt to service your
vehicle if you do not have the
required technical background. Failure
to work in an informed, professional
manner when servicing components
and materials constitutes a safety
hazard for vehicle occupants and other
road users. If you are not familiar with
the guidelines, please have the opera-
tions performed by your BMW center.<
To openPull the release handle and open the
hood.
To closePull the hood downwards and allow the
hood to fall from a minimum height of
12 in (30 cm) so that it audibly engages.
Check for proper locking by pulling on
the hood at the left and right above the
headlamps.
To avoid injuries, be sure that the
travel path of the hood is clear
when it is closed, as with all closing
procedures.
If it is determined that the hood is not
completely closed while driving, stop
immediately and close it securely.<
It is not possible to accelerate
from a standing stop using
SMG II
* when the hood is open.<
Hood

115n
OverviewControlsMaintenanceRepairsDataIndex
Technical modifications California Proposition 65 WarningLight-Emitting Diodes (LEDs)Light-emitting diodes installed behind
translucent lenses serve as the light
source for many of the controls and
displays in your vehicle. The concept
behind their operation is related to that
employed for lasers, and they are offi-
cially designated as Class 1 light-emit-
ting diodes.
Do not remove the protective lens
and avoid staring directly at the
unfiltered beam for extended periods
(several hours), as inflammation of the
iris could result.<
California laws require us to state the
following warning:
Engine exhaust, some of its
constituents, and certain vehicle
components contain or emit chemicals
known to the State of California to
cause cancer and birth defects or other
reproductive harm.<
