2002 BMW 325i SEDAN warning

Contents

© 2001 Bayerische Motoren Werke
Aktiengesellschaft
Munich, Germany
Reprinting, including excerpts, only with the
written consent of BMW AG, Munich.
Order No. 01 41 0 156 168
US English VIII/01
Printed in Germany
Printed on environmentally friendly paper
(bleached without chlorine, suitable for recycling).
Overview
Controls and features

Cockpit14
Instrument cluster15
Indicator and warning lamps17
Multifunction steering wheel
(MFL)21
Hazard warning triangle22
Refueling22
Fuel specifications23
Tire inflation pressures24

Opening and closing:

Keys28
Central locking system28
Opening and closing Ð via the
remote control29
Opening and closing Ð via the
door lock31
Opening and closing Ð from the
inside32
Luggage compartment lid33
Luggage compartment35
Alarm system36
Electric power windows37
Sliding/tilt sunroof39

Adjustments:

Correct sitting posture41
Seats41
Manual seat adjustment42
Power seat adjustment43
Lumbar support43
Head restraints44
Safety belts45
Seat and mirror memory46
Seat heating47
Steering wheel47
Mirrors48

Passenger safety systems:

Airbags49
Transporting children safely52
Vehicle Memory, Key
Memory55

Driving:

Ignition lock56
Starting the engine56
Switching off the engine57
Parking brake58
Manual transmission58
Automatic transmission with
Steptronic59
Indicator/Headlamp flasher61
Washer/Wiper system/Rain
sensor62
Cruise control64

Everything under control:

Odometer66
Tachometer66
Energy control66
Fuel gauge67
Temperature gauge67
Service Interval Display67
Check Control68
Clock68
Computer69

Technology for safety and
driving convenience:

Park Distance Control (PDC)71
Automatic Stability Control plus
Traction (ASC+T)72
Dynamic Stability Control
(DSC)73

Contents

5n

OverviewControlsMaintenanceRepairsDataIndex

Controls and features
Operation, maintenance

Hill Descent Control (HDC)77
Tire Pressure Monitor (RDC)78
Flat Tire Monitor80

Lamps:

Parking lamps/Low beams82
Instrument lighting83
High beams/Standing lamps83
Fog lamps83
Interior lamps84

Controlling the climate for
pleasant driving:

Air conditioning85
Automatic climate control88
Roller sun blind91

Interior conveniences:

Premium sound system91
Glove compartment92
Storage compartments92
Cellular phone94
Ashtray, front95
Ashtray, rear95

Loading and transporting:

Through-loading system96
Ski bag97
Cargo loading99
Roof-mounted luggage rack100

Special operating instructions:

Break-in procedures104
Driving notes105
Antilock Brake System
(ABS)105
Brake system106

Wheels and tires:

Tire inflation pressures107
Tire condition107
Tire replacement108
Wheel and tire
combinations110
Winter tires111

In the engine compartment:

Hood112
Engine compartment
essentials113
Washer fluids114
Engine oil115
Coolant117
Brake fluid118

Maintenance:

The BMW Maintenance
System119

Laws and regulations:

Technical modifications120
California Proposition
65 Warning120
OBD interface socket121

14n
1 Parking lamps/Low beams82
2

>

Turn signals61

>

Standing lamps83

>

High beams83

>

Headlamp flasher61

>

Computer693 Washer/Wiper system/Rain
sensor62
4 Hazard warning flashers
5 Central locking system286 Rear window defroster86, 90
7 Horn, the entire surface
8 Adjusting the steering wheel47
9 Fog lamps83

Cockpit

15n

OverviewControlsMaintenanceRepairsDataIndex

1 Fuel gauge67
2 Indicator lamp for turn signals203 Speedometer
4 Indicator and warning
lamps17 to 205 Tachometer and Energy control66
6 Engine coolant temperature
gauge67

Instrument cluster

16n

Instrument cluster

7 Indicator and warning
lamps17 to 20
8 Reset trip odometer to zero66
9 Check Control display6810 Display for

>

Trip odometer/odometer66

>

Clock68

>

Service Interval67

>

Computer6911 Selector lever and program display
for automatic transmission18, 61
12 Control button for the clock68
13 Indicator and warning
lamps17 to 20

17n

OverviewControlsMaintenanceRepairsDataIndex

Indicator and warning lamps

Technology that monitors itself

The system runs an operational check
on the indicator and warning lamps
identified with the

l

symbol each time
you switch on the ignition. They each
light up once for different periods of
time.
If a fault should occur in one of these
systems, the corresponding lamp does
not go out after the engine is started, or
it lights up while the vehicle is moving.
You will see how to react to this below.

Red: stop immediately

Battery charge current



l

The battery is no longer being
charged. Indicates a defective
alternator drive belt or a problem with
the alternator's charge circuit. Please
contact the nearest BMW center.
If the drive belt is defective, stop
and switch off the engine immedi-
ately to prevent overheating and
serious engine damage. If the drive belt
is defective, increased steering effort is
also required.

<

Engine oil pressure


l

Stop the vehicle immediately
and switch off the engine.
Check the engine oil level; top off as
required. If the oil level is correct:
please contact the nearest BMW
center.
Do not continue driving, as the
engine could sustain serious
damage from inadequate lubrication.

<
Brake warning lamp
l
If the lamp comes on when the
parking brake is not engaged:
check the brake fluid level. Before
driving further, be sure to comply with
the instructions on pages 106 and 118
Brake warning lamp for Cana-
dian models.
Tire Pressure Monitor (RDC)/
Flat Tire Monitor
l
In addition, an acoustic signal is
sounded: a tire failure has occurred.
Reduce vehicle speed immediately and
stop the vehicle. Avoid hard brake
applications. As you steer the vehicle,
use caution and avoid overcorrecting.
For additional information: refer to
pages 78 and 80

18n

Indicator and warning lamps

Red and yellow: continue driving
cautiously

The brake warning lamp comes
on together with the yellow indi-
cator lamps for ABS and
ASC+T/DSC:
The entire ABS, CBC, ASC+T/
DSC and


ADB/ADB-X/DBC


control system has failed.
Continue driving cautiously and
defensively. Avoid hard brake applica-
tions. Please have the system checked
by your BMW center as soon as
possible.
For additional information: refer to
pages 72, 73
CBC, ABS and ASC+T/DSC and
ADB/ADB-X/DBC indicator and
warning lamps for Canadian
models.

Red: an important reminder

Parking brake warning lamp
Comes on when the parking
brake is applied Ð an additional
acoustic signal sounds when starting
off.
For additional information: refer to
page 58
Parking brake warning lamp for
Canadian models.
Fasten safety belts

l

An acoustic warning also
sounds in some versions. Lights
up either for several seconds or until
the belt is engaged, depending upon
version.
For additional information on safety
belts: refer to page 45
Airbags

l

Please have the system
inspected by your BMW center.
For additional information: refer to
page 49

Orange: consult the nearest
BMW center

Automatic transmission
The transmission has
responded to a malfunction by
reverting to operation in its emergency
default program. Please consult the
nearest BMW center.
For additional information: refer to
page 59

19n

OverviewControlsMaintenanceRepairsDataIndex

Indicator and warning lamps

Yellow: check as soon as possible

Antilock Brake System (ABS)

l

ABS has been deactivated in
response to system malfunction.
Conventional braking performance
remains available with no loss of effi-
ciency. Please have the system
inspected at your BMW center.
For additional information: refer to
page 105
ABS warning lamp for Canadian
models.
Engine oil level
Comes on while driving: the
engine oil level has fallen to the
absolute minimum; refill as soon as
possible. Do not drive more than
approx. 30 miles (50 km) until you do.
For additional information: refer to
page 115
Engine oil level
Comes on after the engine has
been shut off: add engine oil at
your earliest opportunity (next time you
stop to refuel). For additional informa-
tion: refer to page 115
Brake pads

l

Have the brake pads checked.
For additional information: refer
to page 106

Tire Pressure Monitor (RDC)/
Flat Tire Monitor

l

Check tire inflation pressures,
refer to pages 24, 78, 80
Automatic Stability Control plus
Traction (ASC+T)/Dynamic
Stability Control (DSC)


l

Indicator lamp flashes:
The system is actively regulating drive
torque and braking force.
The indicator lamp stays lit:
ASC+T has been switched off with the
button or it is defective, or the DSC has
been switched off, ADB is operational.
Please consult the nearest BMW center
in case of a malfunction.
For additional information: beginning on
page 72
BMW 325xi, 330xi:
DSC has been switched off manually or
there is a system malfunction.
ADB-X is operational in its standby
mode. If the warning lamp fails to go
out when you press the DSC button
again, this indicates a system malfunc-
tion affecting both DSC and ADB-X.
Please consult the nearest BMW
center.
For additional information: refer to
page 75

Indicator lamp for Automatic
Stability Control plus Traction
(ASC+T)/Dynamic Stability
Control (DSC) and brake warning
lamp

l

The indicator lamps remain on:
The DSC


and ADB/DBC have been
switched off with the button or are defec-
tive.
Please consult the nearest BMW center.
For additional information: refer to
page 73
BMW 325xi, 330xi:
DSC and ADB-X system malfunction.
There is no provision for deactivating
ADB-X.
Please consult the nearest BMW center.
For additional information: refer to
page 75
DSC and ADB indicator and
warning lamps for Canadian
models.
Dynamic Brake Control (DBC)

l

Malfunction in DBC system.
Conventional braking efficiency
is available and unrestricted.
Have the system repaired at your BMW
center as soon as possible. For addi-
tional information: refer to page 74
