2002 BMW 325Ci COUPE height adjustment

41n
OverviewControlsMaintenanceRepairsDataIndex
Manual seat adjustmentSeat adjustment1 Forward/backward adjustment
Pull the lever and slide the seat to the
desired position.
After you release the lever, move the
seat forward or backward slightly so
that it engages fully
2 Cushion height
Pull the lever and apply weight to
or remove weight from the seat as
required
3 Backrest angle
Pull the lever and apply weight to or
remove weight from the backrest to
reach the desired position.
BMW sports seat
* adjustment
You can also adjust the tilt angle and
the thigh support:
1 To tilt up:
Pull the lever up repeatedly,
continuing until the seat reaches the
desired tilt angle
2 To tilt down:
Push the lever down repeatedly,
continuing until the seat reaches the
desired tilt angle
3 Thigh support:
Pull the lever and adjust the position
of the cushion for thigh support as
desired.

42n
Power seat adjustment
*
Lumbar support*
Seat adjustment1 Forward/backward adjustment
2 Cushion height
3 Backrest angle
The head restraint is adjusted manually,
refer to page 43.
Please refer to the adjustment
instructions on page 40 to reduce
the risk of personal injury.<
BMW sports seat
* adjustment
1 Tilt angle
2 Forward/backward adjustment
3 Cushion height
4 Backrest angle
The thigh support and the head
restraint are adjusted manually, refer to
pages 41, 43.
Please refer to the adjustment
instructions on page 40 to reduce
the risk of personal injury.<
To adjustYou can adjust the backrest's contour
for additional support in the curvature
of your spine's lumbar region.
The upper hips and spinal column
receive supplementary support to help
you maintain a relaxed, upright posture.
>Press front/rear of switch: increase/
decrease curvature
>Press the upper/lower end of the
switch: increase the upper/lower
curvature.

44n
Safety beltsAlways wear your safety beltAlways fasten your safety belt before
starting off. As supplemental restraint
devices, the airbags are designed to
enhance the effectiveness of the safety
belts, and not to replace them.To closeMake sure you hear the catch engage in
the belt buckle.To open1. Press red button in the belt buckle
2. Hold the end of the belt
3. Guide belt back into the inertia reel.
The rear belt buckle with the word
CENTER is intended exclusively for
the passenger sitting in the middle.<
Adjusting safety belt heightUse the height adjustment mechanism
to adapt the shoulder strap to the ideal
level for your own body:
>Slide button up or down.
Please refer to the seat adjustment
instructions on page 40.
If the safety belt system has been
subjected to the stresses involved
in an accident or otherwise damaged:
have the entire safety belt mechanism
replaced by your BMW center, including
the safety belt tensioner. In addition,
have your BMW center inspect the safety
belt anchors. If a child-restraint system
was in the vehicle during an accident,
consult the manufacturer's instructions
regarding replacement.<

Everything from A to ZOil change intervals, see the
Service and Warranty
Information Booklet/
Warranty and Service
Guide Booklet
Oil dipstick109
Oil filter change135
OIL SERVICE65
Onboard computer66
refer to the "Onboard
Computer Owner's
Manual"
Onboard tool kit118
Opening and closing
from the inside32
via the door lock31
via the remote control29
Outlets, ventilation83
Outside temperature
display67
P
Paint care, refer to the
"Caring for your vehicle"
manual
Park assistant69
Park Distance Control
(PDC)69
Parking aid69
Parking brake56
Parking lamps77
bulb replacement119
PDC (Park Distance
Control)69
Performance132
Pocket light87
Power seat adjustment42
Power windows38
Premium sound system86
Protective function38 Q
Quality Grades102
R
Rain sensor60
RDC (Tire Pressure
Monitor)73
Reading lamps
front79
rear79
Rear center 3-point belt91
Rear fog lamps
bulb replacement121
Rear lamps121
Rear reading lamps79
Rear window
defroster81, 85
Rear-seat backrest,
removable91
Rearview mirror47
Recirculated-air mode81
Reclining seat40
Refueling22
Release backrest43
Releasing the fuel filler door
after an electrical
malfunction22
Remote control29
Removable rear-seat
backrest91 Remove window
condensation82, 84
Replace windshield wiper
blades118
Replacement keys28
Replacing lamps and
bulbs118
Reporting safety defects11
Reverse56
Roller sun blind86
Roof load capacity134
Roof-mounted luggage
rack94
S
Safety belts
correct use40
height adjustment44
Safety defects, reporting11
Safety tires103, 126
Seat adjustment40
Seat heating46
Seat memory45
Seats40
Securing cargo93
Securing child-restraint
system52
