2002 BMW 325Ci CONVERTIBLE Repair convertible

31n
OverviewControlsMaintenanceRepairsDataIndex
Opening and closing Ð via the door lockOne turn of the key in the driver's door
lock unlocks the driver's door only.
Turning the key a second time unlocks
all of the remaining doors, the luggage
compartment lid and the fuel filler door.
Do not lock the vehicle if there are
passengers still inside, because
they would not be able to unlock the
doors.<
You can have a signal set to
confirm that the vehicle's locks
have engaged securely.<
Convenience operationYou can also operate the power
windows and the fully-automatic
convertible top via the door lock.
>To open: with the door closed, hold
the key in the "Unlock" position
>To close: with the door closed, hold
the key in the "Lock" position.
Watch the closing process care-
fully and be sure that no one is
trapped by the closing motion.
Releasing the key stops the opera-
tion.<
Manual operation (in the event of electrical malfunction)
Turn the key to the extreme left or right
to unlock/lock the driver's door.

35n
OverviewControlsMaintenanceRepairsDataIndex
Luggage compartmentLift the floor panel up and hook it1. Press the button (arrow)
2. Grab it by the handle and pull up
3. Raise and secure the floor panel by
using the fitting on the weatherstrip-
ping on the drip rail (arrow) to
suspend it.
Carefully replace the hanger in its
holder when lowering the floor
panel back into place.<
To enlarge the luggage
compartmentWith the convertible top closed, you
can enlarge the luggage compartment.
To do this, flip the handle outward and
press it down and toward the front of
the vehicle (arrow). The convertible top
compartment panel is now raised and
secured.
To get ready to open the convertible
top, follow the steps in reverse order.
Before lowering the convertible
top, always check to ensure that
the luggage compartment panel has
returned to its original position, refer to
page 40 or 43. Attempts to lower the
top with the panel folded up can lead to
vehicle damage.<

39n
OverviewControlsMaintenanceRepairsDataIndex
Manual convertible topThe fabric top offers the perfect protec-
tion against weather and one person
can open and close it easily and simply.
So that you will get the most out of
enjoying your convertible, here are a
few tips: it is advisable to close the
convertible top when the vehicle is
being parked. The closed convertible
top not only protects the passenger
compartment from unforeseeable
damage from the weather, it also
provides a certain degree of theft
protection.
In addition, keep valuables only in the
locked luggage compartment, even
with the convertible top closed.
Never mount a roof-mounted luggage
rack on the convertible top.
Closing the electric power
windows: to help ensure that the
windows seal securely, you should
either close the rear windows first or
close all four windows at the same
time.<
To open the convertible top
Never attempt to open or close
the convertible top unless the
vehicle is completely stationary. To
prevent vehicle damage the top
compartment's lock will not disengage
unless the luggage compartment lid is
closed.<
1. Flip the locking handle out (refer to
illustration), and turn it as far as the
end stop will allow
2. Raise the convertible top a little bit
(release the tension)
3. To unlock, press the button with igni-
tion key in position 1. The top
compartment lid's lock disengages
and the lid itself rises a small
distance. The side windows will
lower slightly
If the indicator lamp lights up
when you press the button, this
indicates that the top compartment's
floor panel has been raised, preventing
the lock from disengaging, refer to
page 35. You should respond by folding
the top compartment panel back to its
original position and then reclosing the
luggage compartment lid.<

41n
OverviewControlsMaintenanceRepairsDataIndex
Manual convertible topAs soon as the top convertible
compartment lid closes the central
locking system will release the lock to
allow renewed access to the luggage
compartment.
To avoid fabric damage stemming
from extended exposure to mois-
ture, you should never retract the
convertible top when it is wet, refer also
to the "Caring for your vehicle"
manual.<
To close the convertible top1. Turn the ignition key to position 1
2. Press the button to unlock it. The
convertible top will be unlocked and
the side windows will lower slightly
3. Open the convertible top compart-
ment lid all the way
4. Lift the convertible top out by the
lateral guide section 1 and the front
convertible top frame 2, swinging it
forward until you encounter percep-
tible resistance
To avoid damaging the side trim,
always fold the convertible top
forward before folding the rear frame
brace up into its vertical position.<
5. Either close the slightly lowered side
windows or put them at the desired
height
6. Press down slightly on the convert-
ible top compartment lid from above
(arrow). The closing process will then
be carried out automatically, refer to
page 40
Operate the convertible top
compartment lid from above only
in order to avoid any pinching.<
As soon as the top convertible
compartment lid closes the central
locking system will release the lock to
allow renewed access to the luggage
compartment.<
7. Holding on to the locking handle, pull
the front part of the convertible top
frame up onto the windshield frame,
and lock the convertible top by
turning the handle until you hear the
convertible top engage and lock.
The system automatically presses the
top's rear frame against the convertible
top compartment lid, pretensioning it to
ensure that it seals tightly.

43n
OverviewControlsMaintenanceRepairsDataIndex
Fully-automatic convertible top
*
When closing the electric power
windows while underway, always
remember to either start by closing the
rear windows or to close all of them at
once. Failure to adhere to this
sequence can prevent the windows
from sealing tightly at high speeds.<
At higher speeds, the ensuing
vacuum in the passenger
compartment can cause the convertible
top to begin fluttering. Increase the air
supply via the ventilation controls so
that a vacuum does not occur in the
vehicle.<
1 Close
2 OpenTo open and closeFrom ignition key position 1 and with
the vehicle stationary.
To avoid placing unnecessary loads on
the battery, you should avoid operating
the top when the engine is switched off.
1. Read and comply with the preceding
safety precautions
2. Before opening the convertible top,
ensure that the convertible top
compartment panel is back down
into its original position, refer to
page 35
3. Ensure that the luggage compart-
ment lid is closed
4. Maintain pressure on the corre-
sponding button for the convertible
top operation. The red indicator lamp
flashes whenever the convertible top
mechanism is in operation. It goes
out when the opening or closing
process has been completed.
If it continues flashing after the
control button is released, the
process has not completed opening
or closing. The operation can be
resumed in the desired direction by
pressing the button again.
If the yellow indicator lamp lights up
continuously with the button
pressed, the convertible top
compartment panel has been raised
and the top cannot be moved, refer
to step 2.
The convertible top stops moving
immediately when the button is
released. You can resume operation in
the desired direction by pressing the
button again.<

45n
OverviewControlsMaintenanceRepairsDataIndex
Fully-automatic convertible top
*
If the mechanism for the convert-
ible top compartment lid does not
unlock, then insert the Allen wrench 1
into the recess 2 and turn clockwise to
release it
2. If the luggage compartment lid is
closed, open the convertible top
compartment lid up as far as the stop
will allow
3. Lift out the convertible top by holding
on to the lateral guide section 1 and
the front convertible top frame 2.
Position the rear convertible top
frame vertically and close the
convertible top compartment lid. Flip
the rear convertible top frame down-
ward
4. Use a screwdriver to lift out the cover
panel that is in the center of the front
convertible top frame
5. Insert the Allen wrench (stored next
to the emergency lock; refer to
page 44) in the 6-point socket
(arrow)
6. Pull down on the front convertible
top frame as far as possible.
Complete the closing process by
continuing to turn the wrench to the
left. Turn until the front convertible
top frame has locked onto the wind-
shield frame. The system automati-
cally presses the top's rear frame
against the convertible top compart-
ment lid, pretensioning it to ensure
that it seals tightly.

47n
OverviewControlsMaintenanceRepairsDataIndex
Wind deflector2. Flip out both sides and lock into
place. It is essential for the two
components marked in the illustra-
tion (arrows) to mesh at this point
3. Hold the wind deflector so that the
smaller half points toward the front
and guide the mounting pin for the
side piece into the proper opening
4. Pull back on the mounting pin for the
other side piece by using a slide, so
that the mounting pin can be guided
into the opening provided
5. Unlock the convertible top compart-
ment lid via the convertible top
control button, refer to page 43, and
open the convertible top compart-
ment lid
6. Flip the back half of the wind
deflector backward, so that the
mounts are lying on the vehicle
7. Close the convertible top compart-
ment lid via the convertible top
control button. The wind deflector is
now attached so that it is theft-proof.
Operate the convertible top
compartment lid from above only
in order to avoid any pinching.
With the wind deflector in place: to
avoid damaging the wind deflector
never push the front seats all the way
back.<
RemovalFollow the same procedure as when
installing, just reverse the steps.

103n
OverviewControlsMaintenanceRepairsDataIndex
Ski bag Cargo loading
When reattaching the cover, guide
both bars into the guide and press
the cover back into place. Secure the
safety belts in their holders again.<
Stowing cargo If you are transporting cargo in your
BMW:
>Load heavy cargo as far forward as
possible Ð directly behind the
luggage compartment partition Ð and
as low as possible
>Cover sharp edges and corners.
With the convertible top closed,
you can increase the space in the
luggage compartment, refer to page 35.
We recommend that you always fold
the convertible top compartment panel
down as soon as you have removed
your cargo from the luggage compart-
ment. This way, you can be sure that
you can always operate your convert-
ible top at any time.
At the same time, when the top is
raised you should fold the convertible
top compartment panel back up before
stowing large objects in the luggage
compartment; this precaution will help
reduce the likelihood of damage to
either the convertible top compartment
or your luggage.<
