2002 BMW 320i turn signal

70n
Computer
*
Average fuel consumptionIf you continue to hold the button on the
turn signal lever, the average fuel
consumption last displayed is recalcu-
lated from that point in time.
RangeThe computer bases its calculations for
the cruising range on the operating
conditions in the preceding period and
on the remaining fuel in the tank.
Average speedIf you continue to hold the button, the
average speed last displayed is recal-
culated from that point in time.
Any time spent when the vehicle is
stationary and the engine is shut off is
ignored for the calculation.

81n
OverviewControlsMaintenanceRepairsDataIndex
Flat Tire Monitor
*
To activate/deactivate the systemThe Flat Tire Monitor automatically
assumes operation whenever you turn
the ignition key to position 2. Unless
manually deactivated, it is always on
during normal vehicle operation.
To deactivate the system: press the
button, the yellow indicator lamp comes
on.
To activate the system: press the
button again, the indicator lamp goes
out.
You should deactivate the system
before driving with snow chains, as the
chains can generate spurious warnings
and/or prevent the system from
detecting actual pressure loss.
Flat tire warning
The red warning lamp in the
instrument cluster lights up to
warn of pressure loss and tire
failure. This visual alert is accompanied
by an acoustic warning signal. Reduce
your speed immediately, and steer and
brake gently as you bring the vehicle to
a stop.
To reset the warning lamp: after
replacing the damaged tire you will
need to reset the red warning lamp
manually: maintain pressure on the Flat
Tire Monitor button until the warning
lamp goes out. Then reinitialize the
system.
The Flat Tire Monitor cannot
provide you with advance warning
of sudden and severe tire damage
caused by external factors.
The system also does not detect the
gradual and minor loss of pressure that
all tires display over extended periods
of time.<
Check tire inflation pressures on a
regular basis, correcting them as
necessary, refer to page 24.
The system may respond to operation
on slippery or snow-covered road
surfaces with false warnings or delays
in detecting actual pressure loss.
Performance-oriented driving (slip at
the drive wheels, high rates of lateral
acceleration) can also increase the time
that the Flat Tire Monitor requires to
detect a flat.<
System malfunctionsThe yellow indicator lamp in the instru-
ment cluster lights up and remains on
until the problem is corrected.
Please refer the problem to your BMW
center.

83n
OverviewControlsMaintenanceRepairsDataIndex
Instrument lighting High beams/Standing lampsFog lampsTurn the rotary dial to adjust the illumi-
nation intensity.
1 High beams (blue indicator lamp)
2 Headlamp flasher (blue indicator
lamp)
3 Parking lampsStanding lamps, left or rightAs an additional feature, you can illumi-
nate your vehicle on either side for
parking:
With the ignition key in position 0,
engage the lever in the appropriate
turn-signal position.
Fog lamps
The green indicator lamp in the
instrument cluster lights up to
indicate that the front fog lamps
are on.
If the automatic headlight control
is on, the low beams will come on
automatically whenever you activate
the front fog lamps.<

126n
Lamps and bulbsTurn signal, front 21 watt bulb
1. Extend a screwdriver through the
upper opening and loosen the screw,
continuing until you can extract the
bulb by removing it from the front.
2. Disconnect the plug
3. Apply gentle pressure and turn the
bulb toward the word "AUF" (refer to
the marking on the housing), then
remove it for replacement
4. Connect the plug
5. Align the lamp assembly's two ridges
and the centering pin with the guides
on the vehicle when installing
6. Slide in the lamp, applying gentle
pressure to seat it firmly
7. Tighten the screw.
Side turn signals5 watt bulb
1. Use finger pressure against the rear
end of the lens (arrow) to press it
forward for removal
2. Apply gentle pressure to the bulb
while turning it to the left to remove.

127n
OverviewControlsMaintenanceRepairsDataIndex
Lamps and bulbsTail lampsBulbs: 21 watt
1 Brake lamps red
2 Backup lamps white
3 Tail lamp red
4 Turn signal yellow
Right luggage compartment opening:
Bulbs in the fender:
All of the bulbs are integrated in a
central bulb holder.
1. Unscrew the bulb holder (arrow in
close-up view) to remove
2. Unplug the power supply plug. Set
the bulb holder aside (on the luggage
compartment floor, for example)
3. Applying light pressure, turn the bulb
to the left. Remove and replace the
bulb
4. Plug in the power supply fitting
5. Screw the bulb holder back on
(arrow in close-up view).
Bulbs in the luggage compartment lid:
1. Use a screwdriver to release the two
clips

Everything from A to Z
151n
OverviewControlsMaintenanceRepairsDataIndex
Sliding/tilt sunroof39
electrical malfunction40
manual operation40
Socket95
Sound system91
Space-saver spare
tire25, 132
Spare tire129
Speedometer15
Sports seat
electrical adjustment43
manual adjustment42
Standing lamps83
Starting the engine56
Steering wheel47
Steering wheel lock56
Stopping the vehicle57
Storage compartments92
Storing heavy loads99
Stroke140
Sun blind cover91
Switching off the engine57
Symbols used in this
manual8
Synthetic oils116
T
Tachometer66
Tail lamps
bulb replacement127
Tank capacity143
Technical data140
Technical
modifications10, 120
Telephone preparation94
Temperature display
outside temperature69
Temperature gauge
engine coolant67
Temperature
layering87, 90
Temperature settings
air conditioning86
automatic climate
control89
Thigh support
adjustment42
Third brake light128
Through-loading system96
Tilt alarm sensor30
avoiding unintentional
alarms37
deactivate by remote
control30 Tilt function, passenger-side
mirror47
Tire change129
Tire condition107
Tire inflation
pressures24, 107
monitoring78
table25
Tire Pressure Monitor
(RDC)78, 109, 132
warning lamp17
Tire Quality Grading109
Tire replacement108
Tire tread107
Tool kit124
Torque140
Tow fittings135
Towing the vehicle135
Track141
Transmission58
Transmitter keys28
Transporting children
safely52
Tread depth, tires107
Tread wear, tires107
Trip odometer66
Trunk lid, refer to luggage
compartment lid33 Trunk, refer to luggage
compartment35
Turn signal
indicators20, 61
bulb replacement126
Turning radius141
U
Uniform Tire Quality
Grading109 V
Vehicle Memory55
Vehicle weight142
Vehicle, starting56
Ventilation85, 88
draft-free87, 90 W

Warning lamp "Fasten safety
belts"18
Warning lamps17
Warning messages68
Warning triangle22
Warranty and Service Guide
Booklet (Canadian
models)119
