Your vehicle has several convenient
storage areas so you can stow cargo
saf ely.
The glove box, and the pockets in
the f ront doors and seat-backs, are
designed f or small, lightweight items.
The cargo area is intended f or larger,
heavier items. The second and third
row seats can be f olded f lat to allow
you to carry more cargo or longer
items.
However, carrying too much cargo,
or improperly storing it, can af f ect
your vehicle’s handling, stability, and
operation and make it unsafe. Before
carrying any type of cargo, be sure to
read the f ollowing pages.
Carrying Cargo
Bef ore Driving203
G GLLOOV VE
E B
BOOX X
S
SEEA
A T
T-
-B
BA A C
CKK P
PO
OC CKKEET
T
C
CAA R
RGGO O A
AR
REEA
A
R
RE
EA
A R
R C
COOM M P
PA
A R
RTTM
M E
EN
NT T
D
D
O
OO ORR P
PO
OC CKKEET
T
01/09/07 12:27:27 31S3V610_208

Store or secure all items that could
be thrown around and hurt
someone during a crash.
Be sure items placed on the f loor
behind the f ront seats cannot roll
under the seats and interf ere with
the driver’s ability to operate the
pedals, or with the proper
operation of the seats.
Keep the glove box closed while
driving. If the lid is open, a
passenger could injure their knees
during a crash or sudden stop.
This f igure includes the total weight
of all occupants, cargo, accessories,
and the tongue weight if you are
towing a trailer.
The f inal number is the total weight
of cargo you can carry.
If you are towing a trailer, add the
tongue weight to the number
above. Add up the weight of all occupants.
To f igure out how much cargo you
can carry: When you load luggage, the total
weight of the vehicle, all passengers,
cargo, and trailer tongue load must
not exceed the Gross Vehicle
Weight Rating (GVWR). The load
for the front and rear axles also must
not exceed the Gross Axle Weight
Rating (GAWR). The GVWR and
GAWRareprintedonthetire
information label attached to the
driver’s doorjamb (see page ).
Subtract the total f rom 1,158 lbs
(525 kg).
The maximum load f or your vehicle
is 1,158 lbs (525 kg).
342Carrying Items in the Passenger
Compartment
Load Limit
Carrying Cargo
Bef ore Driving204
Overloading or improper
loading can affect handling and
stability and cause a crash in
which you can be hurt or killed.
Follow all load limits and other
loading guidelines in this
manual.
01/09/07 12:27:41 31S3V610_209

This section gives you tips on
starting the engine under various
conditions, and how to operate the
automatic transmission. It also
includes important inf ormation on
parking your vehicle, the braking
system, the VTM-4 System, and
f acts you need if you are planning to
tow a trailer.........................
Driving Guidelines .208
........................
Preparing to Drive .209
.......................
Starting the Engine .210
Starting in Cold Weather ....................
at High Altitude .210
..............
Automatic Transmission .211
.
Shif t Lever Position Indicator .211
................
Shif t Lever Positions .212
..............
Engine Speed Limiter .215
....................
Shif t Lock Release .215
Variable Torque Management ..............................
4WD System .217
..............................
VTM-4 Lock .217
...........................................
Parking .219
.....................
The Braking System .220
.............
Brake Wear Indicators .220
...............
Brake System Design .221
.......................
Anti-lock Brakes .221
Important Saf ety .........................
Reminders .222
........................
ABS Indicator .222
...............
Driving in Bad Weather .224
...........................
Towing a Trailer .226
Towing Your Vehicle Behind a
................................
Motorhome .238
..............
Of f -Highway Guidelines .240
Driving
Driving207
01/09/07 12:27:59 31S3V610_212

µ
Always use the parking brake when
you park your vehicle. The indicator
on the instrument panel shows that
the parking brake is not f ully
released; it does not indicate that the
parking brake is f irmly set. Make
sure the parking brake is set f irmly
or your vehicle may roll if it is
parked on an incline.
Set the parking brake bef ore you put
the transmission in Park. This keeps
the vehicle from moving and putting
pressure on the parking mechanism
in the transmission making it
easier to move the shif t lever out of
Park when you want to drive away. If the vehicle is f acing uphill, turn
the f ront wheels away f rom the curb.
If the vehicle is f acing downhill, turn
the f ront wheels toward the curb.
Make sure the parking brake is f ully
released bef ore driving away.
Driving with the parking brake
partially set can overheat or damage
the rear brakes.
Make sure the moonroof and the
windows are closed.
Never park over dry leaves, tall
grass, or other f lammable
materials. The three way catalytic
converter gets very hot, and could
cause these materials to catch on
fire. Lockthedoorswiththekeyorthe
remote transmitter. Place any packages, valuables, etc.,
in the cargo area or take them
with you. Turn of f the lights.
Parking T ips
Parking
Driving219
01/09/07 12:30:00 31S3V610_224

Your MDX has been designed to tow
a trailer, as well as f or carrying
passengers and their cargo.
To saf ely tow a trailer, you should
observe the load limits, use the
proper equipment, and f ollow the
guidelines in this section.
Be sure to read thesectiononpage if you
plan to tow off paved surfaces.
The
maximum weight you can tow
depends on several f actors. See
page f or limits f or your towing
situation. Towing a load that is too
heavy can seriously af f ect your
vehicle’s handling and
perf ormance. The weight that
the tongue of a f ully loaded trailer
puts on the hitch should be 5 to 10
percent of total trailer weight f or
boat trailers, and 8 to 15 percent of
total trailer weight for all other
trailers. See page f or limits f or
your towing situation.
240
228 228
Off-Highway
Guidelines
Load Limits
T otal T railer Weight: T ongue L oad:
Towing a Trailer
Driving226
Exceeding any load limit or
improperly loading your vehicle
and trailer can cause a crash in
which you can be seriously hurt
or killed.
Check the loading of your
vehicle and trailer carefully
beforestartingtodrive.
01/09/07 12:31:02 31S3V610_231

Too much tongue load reduces f ront-
tire traction and steering control.
Too little tongue load can make the
trailer unstable and cause it to sway.The GCWR must be reduced 2
percent f or every 1,000 f eet (305
meters) of elevation.
The maximum allowable weight of
the vehicle, all occupants, all cargo
and the tongue load is 5690 lbs (2580
kg).
The maximum allowable weights on
the vehicle axles are 2865 lbs (1300
kg) on the f ront axle, and 2920 lbs
(1325 kg) on the rear axle. The maximum allowable weight of
the f ully loaded vehicle and trailer is
9700 lbs (4410 kg) with the proper
hitch and f luid coolers (See page
f or inf ormation about f luid
coolers.) 232
Towing a Trailer
Driving
Gross Vehicle Weight Rating
(GVWR):
Gross Axle Weight Rating
(GA WR): Gross Combined Weight Rating
(GCWR):
227
01/09/07 12:31:12 31S3V610_232

Î
Î
ÎNumber of
Occupants 2
3
4
5
6
7 T owing is Not Recommended
Number of
Occupants 2
3
4
5
6
7 T owing is Not Recommended Equipped with transmission cooler and power steering f luid cooler.
Max. T ongue Load
Max. T railer Weight
Max. T ongue Load
Max. T railer Wight Equipped with transmission cooler and power steering f luid cooler.
Towing a Trailer
228
Total Trailer Weight and Tongue Load Limits: BOAT TRAILERS
Total Trailer Weight and Tongue Load Limits: OTHER TYPES OF TRAILERS
The corresponding weight limits assume occupants fill seats from the front of the vehicle to the back, each occupant weights 150 lbs (70 kg) and each has 15 lbs (7
kg) of luggage in the cargo area.
450 lbs (205 kg)
410 lbs (185 kg)
310 lbs (140 kg)
215 lbs (100 kg) 90 lbs (40 kg)
4500 lbs (2045 kg)
4500 lbs (2045 kg)
4500 lbs (2045 kg)
4000 lbs (1820 kg)
1700 lbs (770 kg)
450 lbs (205 kg)
410 lbs (185 kg)
310 lbs (140 kg)
215 lbs (100 kg)90 lbs (40 kg)
3500 lbs (1590 kg)
3500 lbs (1590 kg)
3000 lbs (1365 kg)
2000 lbs (910 kg)
1000 lbs (455 kg)
01/09/07 12:31:24 31S3V610_233

Thebestwaytoconfirmthatall
loads are within limits is to check
them at a public scale.
To help ensure a saf e drive to a scale,
or if you cannot get to a public scale
to check the weights of your rig, we
recommended that you estimate
your total trailer weight and tongue
load as described below.
To estimate your total trailer weight,
add the weight of the trailer (as
quoted by the trailer manuf acturer)
together with everything in or on the
trailer. Then ref er to the tables on
page to conf irm that you do not
exceed the limit f or your conditions.To estimate tongue load:
Park the vehicle on level ground.
Measure f rom the ground to the
bottom of the trailer hitch. Write
this number down.
Connect the f ully loaded trailer to
the hitch.
Measure again f rom the ground to
the same spot on the bottom of the
hitch.
Subtract the result f rom Step 4
f rom the result in Step 2 and ref er
to the chart (Fig. 1). If thedifferenceis:
1½ = 150 lbs (68 kg)
2¼ = 250 lbs (114 kg)3 = 350 lbs (159 kg)
3¾ = 450 lbs (204 kg) 4 = over 450 lbs (204 kg)
If thedifferenceismorethan4 ,
you have too much tongue load
at the rear. Move or remove
cargo f rom the trailer and the
vehicle, and measure again.
If the estimated total trailer weight
and tongue load do not exceed the
limits f or your towing situation (see
page ), caref ully drive your
trailer to a public scale. Be sure your
vehicle and trailer are f ully loaded,
with all occupants and cargo you
plan to take on the road.
1.
2.
3.
4.
5.
228
228
Towing a Trailer
Driving
Estimating Loads
T ot al T railer WeightTongue Load Fig. 1
229
’’
’’
’’
’’
’’ ’’
