2001 YAMAHA YFM400F fuel cap

Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600TOC-
EL
EBU00015
CONTENTS
LOCATION OF THE WARNING AND
SPECIFICATION LABELS ....................... 1-1
SAFETY INFORMATION ........................ 2-1
DESCRIPTION AND MACHINE
IDENTIFICATION .................................... 3-1
Identification number records ........... 3-3
Key identification number ................. 3-5
Vehicle identification number ........... 3-5
Model label ......................................... 3-7
CONTROL FUNCTIONS ......................... 4-1
Main switch......................................... 4-1
Indicator lights .................................... 4-3
Coolant temperature indicator light
checking method .............................. 4-7
Speedometer .................................... 4-11
Fuel gauge ........................................ 4-13
Handlebar switches .......................... 4-15
Throttle lever .................................... 4-21
Speed limiter .................................... 4-23
Front brake lever .............................. 4-25Rear brake pedal and lever.............. 4-27
Drive select lever .............................. 4-29
Recoil starter..................................... 4-29
Fuel tank cap..................................... 4-31
Fuel cock ........................................... 4-33
Starter (choke) “ ” ........................ 4-35
Seat ................................................... 4-37
Storage box ...................................... 4-39
Front carrier ...................................... 4-39
Rear carrier ....................................... 4-39
Front shock absorber
adjustment...................................... 4-41
Rear shock absorber
adjustment...................................... 4-45
Auxiliary DC jack .............................. 4-49
PRE-OPERATION CHECKS .................... 5-1
Front and rear brakes......................... 5-7
Fuel .................................................... 5-11
Engine oil .......................................... 5-15
Final gear oil ..................................... 5-19
Differential gear oil .......................... 5-21
Throttle lever .................................... 5-21
Fittings and Fasteners...................... 5-21
1234
5

3-1
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-3.frame
EL
EBU00032
DESCRIPTION AND MACHINE
IDENTIFICATION
1. Rear spring preload
adjusting ring
2. Storage box and tool kit
3. Spark plug
4. Rear brake fluid
reservoir
5. Radiator cap
6. Front spring preload
adjusting ring
7. V-belt case
8. Rear brake pedal
9. Front spring preload
adjusting ring
10. Fuel cock
11. Air filter case
12. Fuses13. V-belt cooling duct
check hose
14. Coolant reservoir
15. Oil filter cartridge
16. Engine oil dipstick
17. Rear brake lever
18. Left handlebar switches
19. Starter (choke)
20. Horn switch
21. Drive select lever
22. Speedometer
23. Main switch
24. Fuel tank cap
25. Auxiliary DC jack
26. Right handlebar switch
27. Throttle lever
28. Front brake lever
NOTE:

The machine you have purchased may differ
slightly from those shown in the figures of this
manual.

4-31
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-4.frame
EL
EBU00092
Fuel tank cap
Remove the fuel tank cap by turning it counter-
clockwise.
1. Fuel tank cap
1. Bouchon de réservoir de carburant
1. Tapón del depósito de combustible

5-11
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-5.frame
EL
EBU00128
Fuel
Make sure there is sufficient gasoline in the
tank.
NOTE:

(for Europe only)
1. If knocking or pinging occurs, use a differ-
ent brand of gasoline or higher octane
grade.
2. If unleaded gasoline is not available, then
leaded gasoline can be used. Recommended fuel: Regular gasoline
For Europe: Regular unleaded gasoline
with a research octane number of 91 or
higher.
For Australia: Unleaded fuel only
Fuel tank capacity:
Total:
15 L
Reserve:
4.5 L

5-13
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-5.frame
EL
1. Fuel level 2. Filler tube
1. Niveau de carburant 2. Tube de remplissage
1. Nivel de combustible 2. Tubo del relleno
WARNING

l
Do not overfill the fuel tank. Fuel expands
when it heats up. If the fuel tank is over-
filled, fuel could spill out due to heat from
the engine or the sun.
l
Be careful not to spill fuel, especially on
the engine or exhaust pipe which can
cause a fire and severe injury. Wipe up
any spilled fuel immediately.
l
Do not refuel right after the engine has
been running and is still very hot.
l
Be sure the fuel tank cap is closed secure-
ly.

Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600-8.frame
EL
8-131
EBU00724Troubleshooting chart
Starting problems or poor engine performance1. Fuel
Check if there is fuel
in the fuel tank.There is fuel.Turn the fuel cock
lever to “OFF”.No fuel.Fuel cock is
clogged.
Clean the
fuel cock. Some fuel.Turn the fuel cock
lever to “RES”.Restart the engine.
No fuel.Supply fuel.
2. Compression
Use the electric
starter to see if
there is compression.There is compression.
Compression normal.
No compression.Ask a Yamaha dealer to
inspect.
3. Ignition
Remove the
spark plug and
check electrodes.WetWipe clean with dry cloth.
DryAttach spark plug cap and
ground to chassis.Use the
electric starter.Spark is good.Ignition system is
normal.
Spark is weak.
Adjust the spark plug gap
or replace the spark plug. No spark.
Ask a Yamaha dealer to
inspect. 4. Battery
Use the electric starter.Engine turns over
quickly.Battery is good.
Engine turns over
slowly.Check the connections.Check the
fuel flow.
Turn the fuel cock
lever to “ON”.
Remove the fuel hose
from the fuel cock.

Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B061_YFM400FWA-61:YFM600SPEC-
EL
10-3
Final gear oil:
Type SAE 80 API “GL-4” Hypoid gear oil
Quantity
Periodic oil change 0.19 L
Total amount 0.22 L
Differential gear oil:
Type SAE 80 API “GL-4” Hypoid gear oil
Quantity
Periodic oil change 0.35 L
Total amount 0.42 L
Air filter: Wet type element
Fuel:
Type Unleaded gasoline
Fuel tank capacity 15 L
Fuel reserve amount 4.5 L
Carburetor:
Type/quantity BSR33/1
Manufacturer MIKUNIModel YFM400FA / YFM400FWAN
