2001 YAMAHA XVS125 check engine

EAU00009
TABLE OF CONTENTS
GIVE SAFETY THE RIGHT OF WAY..................1-1
DESCRIPTION....................................................2-1
Left view.............................................................2-1
Right view..........................................................2-2
Controls and Instruments...................................2-3
INSTRUMENT AND CONTROL
FUNCTIONS........................................................3-1
Main switch/steering lock...................................3-1
Indicator lights....................................................3-2
Speedometer unit..............................................3-2
Anti-theft alarm (optional)...................................3-3
Handlebar switches............................................3-3
Clutch lever........................................................3-5
Shift pedal..........................................................3-5
Brake lever.........................................................3-5
Brake pedal........................................................3-6
Fuel tank cap.....................................................3-6
Fuel....................................................................3-7
Fuel cock............................................................3-7
Starter (choke) lever..........................................3-8
Helmet holder.....................................................3-9
Adjusting the shock absorber assemblies..........3-9
Sidestand.........................................................3-10
Ignition circuit cut-off system............................3-10PRE-OPERATION CHECKS...............................4-1
Pre-operation check list.....................................4-1
OPERATION AND IMPORTANT RIDING
POINTS................................................................5-1
Starting the engine.............................................5-1
Starting a warm engine......................................5-2
Shifting...............................................................5-3
Recommended shift points
(for Switzerland only).......................................5-3
Tips for reducing fuel consumption....................5-4
Engine break-in..................................................5-4
Parking...............................................................5-5
PERIODIC MAINTENANCE AND MINOR
REPAIR................................................................6-1
OwnerÕs tool kit..................................................6-1
Periodic maintenance and lubrication chart.......6-2
Removing and installing panels.........................6-5
Checking the spark plugs...................................6-7
Engine oil and oil filter element..........................6-9
Cleaning the air filter element..........................6-12
Adjusting the carburetor...................................6-14
Adjusting the engine idling speed....................6-14
Adjusting the throttle cable free play................6-15
Adjusting the valve clearance..........................6-15
123
456
5JX-9-E1 9/27/00 10:45 AM Page 5

3-2
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU03034
Indicator and warning lights
EAU00063
High beam indicator light Ò&Ó
This indicator light comes on when
the high beam of the headlight is
switched on.
EAU00057
Turn signal indicator light Ò5Ó
This indicator light flashes when the
turn signal switch is pushed to the left
or right.
2040
600
km/h80
100
120140160
1234
EAU00061
Neutral indicator light ÒNÓ
This indicator light comes on when
the transmission is in the neutral
position.
EAU03182
Engine trouble warning light ÒÓ
This warning light comes on or flash-
es when an electrical circuit monitor-
ing the engine is defective. When this
occurs, have the Yamaha dealer
check the self-diagnosis system.NOTE:
This warning light comes on for a few
seconds when the key is turned to
ÒONÓ, but this does not indicate a
malfunction.
1.High beam indicator light Ò&Ó
2.Turn signal indicator light Ò5Ó
3.Neutral indicator light ÒNÓ
4.Engine trouble warning light ÒÓ
EAU01087
Speedometer unit The speedometer unit is equipped
with a speedometer, an odometer
and a tripmeter. The speedometer
shows riding speed. The odometer
shows the total distance traveled.
The tripmeter shows the distance
traveled since it was last set to zero
with the reset knob. The tripmeter
can be used to estimate the distance
that can be traveled with a full tank of
fuel. This information will enable you
to plan future fuel stops.1.Speedometer
2.Odometer
3.Tripmeter
4.Reset knob
2040600
km/h80
100
120140160
1
23
4
5JX-9-E1 9/27/00 10:45 AM Page 12

3-10
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU00330
SidestandThe sidestand is located on the left
side of the frame. Raise the side-
stand or lower it with your foot while
holding the motorcycle upright.NOTE:
The built-in sidestand switch is part of
the ignition circuit cut-off system,
which cuts the ignition in certain situ-
ations. (See further down for an
explanation of the ignition circuit cut-
off system.)
EW000044
wThe motorcycle must not be ridden
with the sidestand down, or if the
sidestand cannot be properly
moved up (or does not stay up),
otherwise the sidestand could con-
tact the ground and distract the
operator, resulting in a possible
loss of control. YamahaÕs ignition
circuit cut-off system has been
designed to assist the operator in
fulfilling the responsibility of rais-
ing the sidestand before starting
off. Therefore, check this system
regularly as described below and
have a Yamaha dealer repair it if it
does not function properly.
EAU03720
Ignition circuit cut-off
systemThe ignition circuit cut-off system
(comprising the sidestand switch,
clutch switch and neutral switch) has
the following functions.
8It prevents starting when the
transmission is in gear and the
sidestand is up, but the clutch
lever is not pulled.
8It prevents starting when the
transmission is in gear and the
clutch lever is pulled, but the
sidestand is still down.
8It cuts the running engine when
the transmission is in gear and
the sidestand is moved down.
Periodically check the operation of
the ignition circuit cut-off system
according to the following procedure.
EW000045
wIf a malfunction is noted, have a
Yamaha dealer check the system
before riding.
5JX-9-E1 9/27/00 10:45 AM Page 20

INSTRUMENT AND CONTROL FUNCTIONS
3
3-11
With the engine turned off:
1. Move the sidestand down.
2. Make sure that the engine stop switch is set to Ò
#Ó.
3. Turn the key to ÒONÓ.
4. Shift the transmission into the neutral position.
5. Push the start switch.
Does the engine start?
The neutral switch may be defective.
The motorcycle should not be ridden until
checked by a Yamaha dealer.
With the engine still running:
6. Move the sidestand up.
7. Keep the clutch lever pulled.
8. Shift the transmission into gear.
9. Move the sidestand down.
Does the engine stall?After the engine has stalled:
10. Move the sidestand up.
11. Keep the clutch lever pulled.
12. Push the start switch.
Does the engine start?
The sidestand switch may be defective.
The motorcycle should not be ridden until
checked by a Yamaha dealer.The clutch switch may be defective.
The motorcycle should not be ridden until
checked by a Yamaha dealer.
NO
NOTE:This check is most reliable if performed with
a warmed-up engine.
YESYESNO
The system is OK.
The motorcycle can be ridden.
YESNO
5JX-9-E1 9/27/00 10:45 AM Page 21

EAU01114
PRE-OPERATION CHECKS
1
2
34
5
6
7
8
9
4-1
The condition of a vehicle is the ownerÕs responsibility. Vital components can start to deteriorate quickly and unexpect-
edly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leak-
age or loss of tire air pressure could have serious consequences. Therefore, it is very important, in addition to a thor-
ough visual inspection, to check the following points before each ride.
EAU03439
Pre-operation check list
ITEMCHECKSPAGE
Fuel¥Check fuel level in fuel tank.
¥Refuel if necessary.
¥Check fuel line for leakage.3-6Ð3-7
Engine oil¥Check oil level in engine.
¥If necessary, add recommended oil to specified level.
¥Check vehicle for oil leakage.6-9Ð6-12
Front brake¥Check operation.
¥If soft or spongy, have Yamaha dealer bleed hydraulic system.
¥Check lever free play.
¥Adjust if necessary.
¥Check fluid level in reservoir.
¥If necessary, add recommended brake fluid to specified level.
¥Check hydraulic system for leakage.3-5, 6-20,
6-22Ð6-24
Rear brake¥Check operation.
¥Check pedal free play.
¥Adjust if necessary.3-6, 6-20Ð6-23
Clutch¥Check operation.
¥Lubricate cable if necessary.
¥Check lever free play.
¥Adjust if necessary.3-5, 6-19
5JX-9-E1 9/27/00 10:45 AM Page 22

EAU00372
OPERATION AND IMPORTANT RIDING POINTS
1
2
3
45
6
7
8
9
5-1
EAU00373
w8Become thoroughly familiar
with all operating controls and
their functions before riding.
Consult a Yamaha dealer
regarding any control or func-
tion that you do not thorough-
ly understand.
8Never start the engine or oper-
ate it in a closed area for any
length of time. Exhaust fumes
are poisonous, and inhaling
them can cause loss of con-
sciousness and death within a
short time. Always make sure
that there is adequate ventila-
tion.
8Before starting out, make sure
that the sidestand is up. If the
sidestand is not raised com-
pletely, it could contact the
ground and distract the opera-
tor, resulting in a possible loss
of control.
EAU03515
Starting the engineIn order for the ignition circuit cut-off
system to enable starting, one of the
following conditions must be met:
8The transmission is in the neutral
position.
8The transmission is in gear with
the clutch lever pulled and the
sidestand up.
EW000054
w8Before starting the engine,
check the function of the igni-
tion circuit cut-off system
according to the procedure
described on page 3-11.
8Never ride with the sidestand
down.
1.Turn the fuel cock lever to ÒONÓ.
2.Turn the key to ÒONÓ and make
sure that the engine stop switch
is set to Ò#Ó.
3.Shift the transmission into the
neutral position.NOTE:
When the transmission is in the neu-
tral position, the neutral indicator light
should be on, otherwise have a
Yamaha dealer check the electrical
circuit.1.Arrow mark positioned over ÒONÓ
1
5JX-9-E1 9/27/00 10:45 AM Page 25

5-4
OPERATION AND IMPORTANT RIDING POINTS
1
2
3
45
6
7
8
9
EAU00424
Tips for reducing fuel
consumptionFuel consumption depends largely on
your riding style. Consider the follow-
ing tips to reduce fuel consumption:
8Thoroughly warm up the engine.
8Turn the starter (choke) off as
soon as possible.
8Shift up swiftly, and avoid high
engine speeds during accelera-
tion.
8Do not rev the engine while shift-
ing down, and avoid high engine
speeds with no load on the
engine.
8Turn the engine off instead of let-
ting it idle for an extended length
of time (e.g., in traffic jams, at
traffic lights or at railroad cross-
ings).
EAU01128
Engine break-inThere is never a more important peri-
od in the life of your engine than the
period between 0 and 1,600 km. For
this reason, you should read the fol-
lowing material carefully.
Since the engine is brand new, do
not put an excessive load on it for the
first 1,600 km. The various parts in
the engine wear and polish them-
selves to the correct operating clear-
ances. During this period, prolonged
full-throttle operation or any condition
that might result in engine overheat-
ing must be avoided.
EAU03183
0Ð1,000 km
Avoid prolonged operation above 1/3
throttle.
1,000Ð1,600 km
Avoid prolonged operation above 1/2
throttle.
ECA00058
cCAfter 1,000 km of operation, the
engine oil must be changed and
the oil filter element replaced.1,600 km and beyond
The vehicle can now be operated
normally.
EC000049
cCIf any engine trouble should occur
during the engine break-in period,
immediately have a Yamaha dealer
check the vehicle.
5JX-9-E1 9/27/00 10:45 AM Page 28

6-3
PERIODIC MAINTENANCE AND MINOR REPAIR
6
10
*Tires¥Check tread depth and for damage.
¥Replace if necessary.
¥Check air pressure.
¥Correct if necessary.ÖÖÖÖ
11*Wheel bearings¥Check bearing for looseness or damage.ÖÖÖÖ
12*Swingarm¥Check operation and for excessive play.ÖÖÖÖ
¥Lubricate with molybdenum disulfide grease.Every 24,000km
13Drive chain¥Check chain slack.
¥Make sure that the rear wheel is properly aligned.
¥Clean and lubricate.Every 1,000 km and after washing the motorcycle
or riding in the rain.
14*Steering bearings¥Check bearing play and steering for roughness.ÖÖÖÖÖ
¥Lubricate with lithium-soap-based greaseEvery 24,000km
15*Chassis fasteners¥Make sure that all nuts, bolts and screws are properly tightened.ÖÖÖÖÖ
16Sidestand¥Check operation.
¥Lubricate.ÖÖÖÖÖ
17*Sidestand switch¥Check operation.ÖÖÖÖÖÖ
18*Front fork¥Check operation and for oil leakage.ÖÖÖÖ
19*Rear shock absorber
assemblies¥Check operation and shock absorbers for oil leakage.ÖÖÖÖ
20*Carburetor¥Check starter (choke) operation.
¥Adjust engine idling speed.ÖÖÖÖÖÖ
21Engine oil¥Change.ÖÖÖÖÖÖ NO.ITEMCHECK OR MAINTENANCE JOBODOMETER READING (´1,000 km)
ANNUAL
CHECK
16121824
5JX-9-E1 9/27/00 10:45 AM Page 32
