4-22
E
EJU00578a
Replacing the fuse
The fuses are in the electrical box 1.
To replace the fuse:
1. Remove the hose band a and keep the
duct hose b away from the electrical
box.
2. Remove the cap 2 on the electrical box.
3. Remove the fuse using the fuse puller3.
4. Replace the fuse with one of the correct
amperage.
WARNING
Do not use fuses of higher amperage that
those recommended. Substitution of a
fuse of improper rating can cause exten-
sive electrical system damage and possi-
ble fire.
EJU00580
Bleeding the oil injection
pump
If the oil tank becomes completely empty,
or any hose connected to the oil pump has
been disconnected, the oil pump must be
bled to ensure proper oil flow.
If bleeding of the oil pump is necessary,
have a Yamaha dealer bleed it.Fuse amperage: 10 A, 20 A
