EL
1. Upper wheel hub nut 2. Lower wheel hub nut
1. Écrou supérieur de moyeu de roue
2. Écrou inférieur de moyeu de roue
1. Tuerca superior del buje de la rueda
2. Tuerca inferior del buje de la rueda
EBU00352
Drive chain slack adjustment
1. Loosen the rear wheel hub nuts.
2. Loosen the adjuster locknuts on each side.
To tighten the chain, turn the chain adjust-
er clockwise. To loosen the chain, turn the
adjuster counterclockwise and push the
wheel forward. Turn each adjuster exactly
the same amount to maintain correct axle
alignment.
There are marks on each side of the swingarm
and on each chain adjuster. Use them to check
for proper alignment.
3. After adjusting, be sure to tighten the lock-
nuts and the wheel hub nuts.
Tightening torque:
Upper wheel hub nut:
120 Nm (12.0 m·kg)
Lower wheel hub nut:
60 Nm (6.0 m·kg)
1. Locknut 2. Adjusting bolt 3. Alignment marks
1. Contre-écrou 2. Boulon de réglage
3. Repères d’alignement
1. Contratuerca 2. Perno de ajuste
3. Marcas de alineación
8-71
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-8.frame
EL
EBU00374
Wheel installation
When installing the wheels, reverse the remov-
al procedure.NOTE:The arrow mark on the tire must point to-ward the rotating direction of the wheel.
Tighten the wheel nuts to the specified torque.
Wheel nut torque:
Front: 45 Nm (4.5 m·kg)
Rear: 45 Nm (4.5 m·kg)
1. Arrow mark
1. Flèche
1. Flecha
