2001 YAMAHA TW125 check engine

5-4
OPERATION AND IMPORTANT RIDING POINTS
1
2
3
45
6
7
8
9
EAU00424
Tips for reducing fuel
consumptionFuel consumption depends largely on
your riding style. Consider the follow-
ing tips to reduce fuel consumption:
8Thoroughly warm up the engine.
8Turn the starter (choke) off as
soon as possible.
8Shift up swiftly, and avoid high
engine speeds during accelera-
tion.
8Do not rev the engine while shift-
ing down, and avoid high engine
speeds with no load on the
engine.
8Turn the engine off instead of let-
ting it idle for an extended length
of time (e.g., in traffic jams, at
traffic lights or at railroad cross-
ings).
EAU01128
Engine break-inThere is never a more important peri-
od in the life of your engine than the
period between 0 and 1,600 km. For
this reason, you should read the fol-
lowing material carefully.
Since the engine is brand new, do
not put an excessive load on it for the
first 1,600 km. The various parts in
the engine wear and polish them-
selves to the correct operating clear-
ances. During this period, prolonged
full-throttle operation or any condition
that might result in engine overheat-
ing must be avoided.
EAU01500
0Ð1,000 km
Avoid prolonged operation above 1/3
throttle.
1,000Ð1,600 km
Avoid prolonged operation above 1/2
throttle.
EC000057
cCAfter 1,000 km of operation, the
engine oil must be changed, the oil
filter cartridge/element replaced,
and the oil strainer cleaned.1,600 km and beyond
The vehicle can now be operated
normally.
EC000049
cCIf any engine trouble should occur
during the engine break-in period,
immediately have a Yamaha dealer
check the vehicle.
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 28

6-3
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
10
*Wheels¥ Check runout, spoke tightness and for damage.
¥ Tighten spokes if necessary.ÖÖÖÖ
11*Tires¥ Check tread depth and for damage.
¥ Replace if necessary.
¥ Check air pressure.
¥ Correct if necessary.ÖÖÖÖ
12*Wheel bearings¥ Check bearing for looseness or damage.ÖÖÖÖ
13*Swingarm¥ Check operation and for excessive play.ÖÖÖÖ
¥ Lubricate with lithium-soap-based grease. Every 24,000km
14 Drive chain¥ Check chain slack.
¥ Make sure that the rear wheel is properly aligned.
¥ Clean and lubricate.Every 500 km and after washing
the motorcycle in the rain
15*Steering bearings¥ Check bearing play and steering for roughness.ÖÖÖÖÖ
¥ Lubricate with lithium-soap-based greaseEvery 24,000km
16*Chassis fasteners¥ Make sure that all nuts, bolts and screws are properly tightened.ÖÖÖÖ Ö
17 Sidestand¥ Check operation.
¥ Lubricate.ÖÖÖÖ Ö
18*Sidestand switch¥ Check operation.ÖÖÖÖÖ Ö
19*Front fork¥ Check operation and for oil leakage.ÖÖÖÖ
20*Rear shock absorber
assembly pivoting
points¥ Check operation and shock absorber for oil leakage.ÖÖÖÖ
¥ Lubricate with lithium-soap-based grease.ÖÖ
21*Carburetor¥ Check starter (choke) operation.
¥ Adjust engine idling speed.ÖÖÖÖÖ Ö NO. ITEM CHECK OR MAINTENANCE JOBODOMETER READING (´1,000 km)
ANNUAL
CHECK
1 6 12 18 24
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 32

6-4
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU03541
NOTE:
8The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
8Hydraulic brake service
8
Regularly check and, if necessary, correct the brake fluid level.
8
Every two years replace the internal components of the brake master cylinder and caliper, and change the brake fluid.
8
Replace the brake hoses every four years and if cracked or damaged.
22 Engine oil¥ Change.ÖÖÖÖÖ Ö
23 Engine oil filter element¥ Replace.ÖÖÖ
24
*Engine oil strainer¥ Clean.ÖÖÖ
25*Front and rear brake
switches¥ Check operation.ÖÖÖÖÖ Ö
26 Moving parts and cables¥ Lubricate.ÖÖÖÖ Ö
27*Lights, signals and
switches¥ Check operation.
¥ Adjust headlight beam.ÖÖÖÖÖ Ö NO. ITEM CHECK OR MAINTENANCE JOBODOMETER READING (´1,000 km)
ANNUAL
CHECK
1 6 12 18 24
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 33

6-7
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU01833
Checking the spark plugThe spark plug is an important
engine component, which is easy to
check. Since heat and deposits will
cause any spark plug to slowly erode,
the spark plug should be removed
and checked in accordance with the
periodic maintenance and lubrication
chart. In addition, the condition of the
spark plug can reveal the condition of
the engine.
1. Spark plug wrenchTo remove the spark plug
1. Remove the spark plug cap.
2. Remove the spark plug as
shown, with the spark plug
wrench included in the ownerÕs
tool kit.
1
To install the panelPlace the panel in the original posi-
tion.
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 36

To check the spark plug
1. Check that the porcelain insula-
tor around the center electrode
of the spark plug is a medium-to-
light tan (the ideal color when the
motorcycle is ridden normally).NOTE:
If the spark plug shows a distinctly
different color, the engine could be
defective. Do not attempt to diagnose
such problems yourself. Instead,
have a Yamaha dealer check the
motorcycle.2. Check the spark plug for elec-
trode erosion and excessive car-
bon or other deposits, and
replace it if necessary.
NOTE:
If a torque wrench is not available
when installing a spark plug, a good
estimate of the correct torque is
1/4Ð1/2 turn past finger tight.
However, the spark plug should be
tightened to the specified torque as
soon as possible.4. Install the spark plug cap.
6-8
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9 Specified spark plug:
DR8EA (NGK)
a
a. Spark plug gapTo install the spark plug
1. Measure the spark plug gap with
a wire thickness gauge and, if
necessary, adjust the gap to
specification.
2. Clean the surface of the spark
plug gasket and its mating sur-
face, and then wipe off any grime
from the spark plug threads.
3. Install the spark plug with the
spark plug wrench, and then
tighten it to the specified torque. Spark plug gap:
0.6Ð0.7 mm
Tightening torque:
Spark plug:
17.5 Nm (1.75 mákg)
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 37

6-9
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
93. Wait a few minutes until the oil
settles, and then check the oil
level through the check window
located at the bottom-left side of
the crankcase.
NOTE:
The engine oil should be between the
minimum and maximum level marks.4. If the engine oil is below the
minimum level mark, add suffi-
cient oil of the recommended
type to raise it to the correct
level.1. Engine oil level check window
2. Maximum level mark
3. Minimum level mark
To change the engine oil (with or
without oil filter element cleaning)
1. Start the engine, warm it up for
several minutes, and then turn it
off.
2. Place an oil pan under the
engine to collect the used oil.
3. Remove the engine oil filler cap
and drain bolt to drain the oil
from the crankcase.1. Engine oil filler cap
1
2
3 1
EAU03564
Engine oil and oil filter
elementThe engine oil level should be
checked before each ride. In addition,
the oil must be changed and the oil
filter element cleaned at the intervals
specified in the periodic maintenance
and lubrication chart.
To check the engine oil level
1. Place the motorcycle on a level
surface and hold it in an upright
position.NOTE:
Make sure that the motorcycle is
positioned straight up when checking
the oil level. A slight tilt to the side
can result in a false reading.2. Start the engine, warm it up for
several minutes, and then turn it
off.
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 38

6-11
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
912. Add the specified amount of the
recommended engine oil, and
then install and tighten the oil
filler cap. 9. Install the oil filter element cover
by installing the screws and the
drain bolt. Then tightening them
to the specified torque.
NOTE:
Make sure that the O-rings are prop-
erly seated.10. Clean the oil strainer with sol-
vent, and then check it for dam-
age and replace it if necessary.
11. Install the oil strainer, spring, O-
ring and engine oil drain bolt,
and then tighten the drain bolt to
the specified torque.Tightening torque:
Engine oil drain bolt:
43 Nm (4.3 mákg)
5. Remove the oil filter element
cover by removing the screws.
6. Remove the oil filter element and
O-rings.
7. Check the O-rings for damage
and replace it if necessary.
8. Clean the oil filter element with
solvent, and then install it. NOTE:
Check the oil filter element for dam-
age and replace it if necessary.1. Oil filter element
2. O-ring (´2)
1 2
2
Tightening torques:
Oil filter element cover screw:
7.0 Nm (0.7 mákg)
Oil filter element drain bolt:
10 Nm (1.0 mákg)
Recommended engine oil:
See page 8-1.
Oil quantity:
Without oil filter element
removal:
1.0 L
With oil filter element removal:
1.1 L
Total amount (dry engine):
1.3 L
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 40

6-12
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
1
2
2
EAU03562
Cleaning the air filter
element and check hoseThe air filter element should be
cleaned at the intervals specified in
the periodic maintenance and lubrica-
tion chart. Clean the air filter element
more frequently if you are riding in
unusually wet or dusty areas. In addi-
tion, the air filter check hose must be
frequently checked and cleaned if
necessary.
To clean the air filter element
1. Remove panel A. (See page 6-6
for panel removal and installation
procedures.)
1. Air filter case cover
2. Screw (´4)
EC000072
cC8In order to prevent clutch slip-
page (since the engine oil also
lubricates the clutch), do not
mix any chemical additives
with the oil or use oils of a
higher grade than ÒCDÓ. In
addition, do not use oils
labeled ÒENERGY CONSERV-
ING
IIÓ or higher.
8Make sure that no foreign
material enters the crankcase.
13. Start the engine, and then let it
idle for several minutes while
checking it for oil leakage. If oil is
leaking, immediately turn the
engine off and check for the
cause.
14. Turn the engine off, and then
check the oil level and correct it if
necessary.2. Remove the air filter case cover
by removing the screws.
5EK-9-E2 (TW125)<3.3Passport> 5/23/00 9:47 AM Page 41
