2001 TOYOTA MR2 SPYDER windshield wipers

01MY MR2(U) L/O 0008
612001 MR2 (OM17482U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights, Wipers and Defogger
Headlights and turn signals62
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers 63
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Instrument panel light control 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior light 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Windshield wipers and washer 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window defogger 65
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
SECTION 1− 4

01MY MR2(U) L/O 0008
642001 MR2 (OM17482U)
Instrument panel light control
SB14015
To adjust the brightness of the instru-
ment panel lights, turn the switch.
Interior light
SB14021
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
ON"The light stays on all the time.
OFF"Turns the light off.
DOOR"Turns the light on when either
side door is opened. The light goes off
when both the doors are closed.
Windshield wipers and washer
SB14020
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the ON" position.Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
For a single sweep of the windshield,
push the lever up and release it.

01MY MR2(U) L/O 0008
652001 MR2 (OM17482U)
The INT TIME" band lets you adjust the
wiping time interval when the wiper lever
is in the intermittent position (position 1).
Twist the band upward to increase the
time between sweeps, and downward to
decrease it.
To squirt washer fluid, pull the lever
toward you.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
For instructions on adding washer fluid,
see Adding washer fluid" on page 205 in
Section 7−3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on the windshield, which can
block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
Rear window defogger
SB14017
To defog or defrost the rear window,
push the switch.
The key must be in the ON" position.
The thin heater wires on the inside of the
rear window will quickly clear the surface.
An indicator light will illuminate to indicate
the defogger is operating.
Push the switch once again to turn the
defogger off.
The system will automatically shut off af-
ter the defogger has operated about 15
minutes.Make sure you turn the defogger off when
the window is clear. Leaving the defogger
on for a long time could cause the battery
to discharge, especially during stop−and−
go driving. The defogger is not designed
for drying rain water or for melting snow.
NOTICE

When cleaning the inside of the
rear window, be careful not to
scratch or damage the heater wires
or connectors.
 When the soft top is completely
lowered, keep the rear window de-
fogger turned off to avoid damage
to the top.
