Anti−lock brake system is not de-
signed to shorten the stopping dis-
tance: Always drive at the moderate
speed and maintain a safe distance
from the vehicle in front of you.
Compared with vehicles not fitted
with an anti−lock brake system, your
vehicle may require a longer stopping
distance in the following cases:
Driving on rough, gravel or snow−
covered roads.
Driving with tire chains installed.
Driving over the steps such as the
joints on the road.
Driving on roads where the road
surface is pitted or has other differ-
ences in surface height.
Install all 4 tires of specified size at
designated pressure: The anti−lock
brake system detects vehicle speeds
using the speed sensors for respec-
tive wheels’ turning speeds. The use
of tires other than specified may fail
to detect the accurate turning speed,
resulting in a longer stopping dis-
tance.
“ABS” warning light
The light comes on when the ignition key
turned to the “ON” position. If the anti−
lock brake system works properly, the
light turns off after a few seconds. There-
after, if the system malfunctions, the light
comes on again.
When the “ABS” warning light is on (and
the brake system warning light is off), the
anti−lock brake system does not operate,
but the brake system still operates con-
ventionally.When the “ABS” warning light is on (and
the brake system warning light is off), the
anti−lock brake system does not operate
so that the wheels could lock up during
a sudden braking or braking on slippery
road surfaces.
If either of the following conditions oc-
curs, this indicates a malfunction some-
where in the parts monitored by the
warning light system. Contact your au-
thorized Toyota CNG dealer as soon as
possible to service the vehicle.
The light does not come on when the
ignition key is turned to the “ON” posi-
tion, or remains on.
The light comes on while you are driv-
ing.
A warning light turning on briefly during
operation does not indicate a problem.
’01CAMRY CNG (L/O0009)
2082001 CAMRY CNG_U (OM33542U)
Engine compartment
Fuses (type A)
1. A/C 10 A: Air conditioning system
2. SPARE 10 A: Spare fuse
3. SPARE 15 A: Spare fuse
4. SPARE 30 A: Spare fuse
5. ALT−S 5 A: Charging system
6. HEAD (RH) 20 A: Right−hand headlight
7. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, A/F sensor
8. HORN 10 A: Horn
9. HAZARD 15 A: Emergency flasher
Engine compartment
10. AM2 30 A: Gauge and meter, SRS
airbag system, seat belt pretensioners,
multiport fuel injection system/sequen-
tial multiport fuel injection system,
“IGN” and “STARTER” fuses
11 . T E L 5 A : No circuit
12. HEAD (LH) 20 A: Left−hand headlight
13. RADIO NO.1 20 A: Audio system
14. DOME 7.5 A: Clock, ignition switch
light, trunk light, interior light, power
door lock system
15. ECU−B 10 A: Anti−lock brake system,
SRS airbag system, seat belt preten-
sioners
Instrument panel
16. A/F HTR 25 A: No circuit
17. DOOR SUB 25A: No circuit
18. INJ 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, starting system
19. DRL NO.2 5 A: No circuit
20. H−LP LH (LWR) 15 A: No circuit
21. H−LP RH (LWR) 15 A: No circuit
22. SEAT−HEATER 20 A: No circuit
23. HEATER 10 A: Air conditioning system,
rear window defogger
