2001 SUBARU IMPREZA turn signal

3
Instruments and controls Gauges3-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer 3-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer/Trip meter 3-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer (if equipped) 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel gauge 3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature gauge 3-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning and indicator lights 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat belt warning light and chime 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS airbag system warning light 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charge warning light 3-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil pressure warning light 3-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 3-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHECK ENGINE warning light/Malfunction indicator lamp 3-7 . . . . . .
ABS warning light (for vehicles with ABS) 3-8 . . . . . . . . . . . . . . . . . . . . . . . . .
AT OIL TEMPerature warning light (for AT vehicles) 3-9 . . . . . . . . . . . . . .
Door open warning lights 3-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front-wheel drive warning light (for AWD AT vehicles) 3-10 . . . . . . . . . .
Turn signal indicator lights 3-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High beam indicator 3-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low fuel warning light 3-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock 3-11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard warning flasher 3-11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light control switch 3-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn signal lever 3-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illumination brightness control 3-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking light switch 3-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch (if equipped) 3-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper and washer 3-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wipers and washer switches 3-18 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer switch (if equipped) 3-20 . . . . . . . . . . . . .
Rear window defogger switch 3-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 3-22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mirrors 3-22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside mirror 3-22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside mirrors 3-23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-10
Automatic transmission control system warning
If the lig ht flashes after the eng ine starts, it ma y ind ic ate that the auto-
matic transmission c ontrol system is not working p r op erly. Contac t
your nearest SUBARU d ealer for servic e immed iately.
Door open warning lights
The d oor op en warning lig ht c omes on if any d oor or the rear g ate (for
wag on and OUTBACK SPORT) is not fully c losed .
Always make sure this lig ht is out b efore you start to d rive.
Front-wheel drive warning light
(for AWD AT vehicles)
This lig ht c omes on when All Wheel Drive is d iseng a g ed and the d rive
mec hanism is switc hed to Front Wheel Drive for mai ntenanc e or similar
p urp oses. Turn signal indicator lights
These lig hts show the op eration of the turn sig nal or lane c hang e sig nal.
If the ind ic ator lig hts d o not b link or b link rap id ly, the turn sig nal b ulb
may b e b urned out. Rep lac e the b ulb as soon as p oss ib le. Refer to “Re-
p lac ing b ulb s ” sec tion in c hap ter 10.
High beam indicator
This lig ht shows that the head lig hts are in the hig h b eam mod e.
This ind ic ator lig ht also c omes on when op erating h ead lig ht flasher.
Low fuel warning light
The low fuel warning lig ht c omes on when the tank i s nearly emp ty
(ab out 2.3 U.S. g al., 9.0 liters, 1.9 Imp . g al.). I t only op erates when the
ig nition switc h is in the “ON ” p osition.
NOTE This light does not go out unless the tank is replenished up to an internal fuel quantity of about 3.6 U.S. gal. (14 liters, 3.0 Imp. gal.).

3-12flasher works with the ig nition switc h in any p osit
ion.
When you have to p ark your vehic le und er emerg enc y c ond itions, p ull off
the road safely and p ark away from the traffic if i t is p ossib le.
To turn on the hazard warning flasher, p ush the haz ard warning b utton
on the instrument p anel. To turn off the flasher, p ush the b utton ag ain.
NOTE When the hazard warning flasher is on, the turn signals do not work.
Light control switch
WARNING
To prevent battery discharge resulting from accidentally leaving your lights on when your vehicle is parked, the light switch oper-ates only when the ignition switch is in the “ON” position. In any
other position, the vehicle ’s lights will be out.
If you park vehicle on a roadside at night, use the hazard warningflasher to alert the other drivers.
HS0054 HS0055
Dimmer
Headlight flasher
The lig ht switc h op erates only when the ig nition sw itc h is in the “ON ”
p osition.
Headlights
To turn on the head lig hts, turn the knob on the end of the turn sig nal

3-14The low b eam head lig hts will automatic ally c ome on
at red uc ed
b rig htness when the eng ine has started , und er the f ollowing c ond i-
tions:
The p arking b rake is fully released .
The automatic transmission selec tor lever is set at other than
the “P ” p osition.
The lig ht switc h is in the “OFF ” p osition.
Turn signal lever
HS0056
Right turn Left turn
To ac tivate the rig ht turn sig nal, p ush the turn si g nal lever up . To ac tivate
the left turn sig nal, p ush the turn sig nal lever d o wn. When the turn is fin-
ished , the lever will return automatic ally. If the lever d oes not return after
c ornering , return the lever to the neutral p osition b y hand .
To sig nal a lane c hang e, p ush the turn sig nal lever up or d own slig htly
and hold it d uring the lane c hang e. The turn sig nal ind ic ator lig hts will
flash in the d irec tion of the turn or lane c hang e. The lever will return auto-
matic ally to the neutral p osition when you release it.

8-2
Hazard warning flasher
HS0053
Day or nig ht, if your vehic le b ec omes a traffic haz
ard , use the hazard
warning flasher. Avoid stop p ing on the road . It is b est to safely p ull off
the road if a p rob lem oc c urs. The hazard warning fl asher c an b e ac ti-
vated reg ard less of the ig nition switc h p osition.
Turn on the hazard warning b y p ushing the hazard wa rning flasher
switc h. Turn it off b y p ushing the switc h ag ain. NOTE When the hazard warning flasher is on, the turn signals do not work.
Engine overheating
WARNING
Never attempt to remove the radiator cap until the engine has been shut off and has fully cooled down. When the engine is hot,the coolant is under pressure. Removing the cap while the engineis still hot could release a spray of boiling hot coolant, which
could burn you very seriously.
If the eng ine overheats, safely p ull off the road a nd stop the vehic le in a
safe p lac e.

10-2Fog light (if equipped)
10-48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking light 10-50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front turn signal light 10-51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Side turn signal light 10-52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear combination lights 10-53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
License plate light 10-55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior light, spot light 10-55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maintenance and service10-51
–
CONTINUED –

Front turn signal light Type A
HGA011BB
1. Remove the b olt sec uring the front turn sig nal li g ht assemb ly.
2. Remove the front turn sig nal lig ht assemb ly from the front b ump er
and remove the b ulb soc ket b y turning it c ounterc lo c kwise.
3. Remove the b ulb from the soc ket b y p ushing it in and turning
c loc kwise, then install a new b ulb .
4. Install the removed p arts in the reverse ord er of removal.
Type B
HG0194
1. Remove the front turn sig nal lig ht assemb ly mount ing sc rews using
the p hillip s sc rewd river.
2. Remove the lens from the front turn sig nal lig ht assemb ly.

10-523. Remove the b ulb from the soc ket b y p ushing it in
and turning
c ounterc loc kwise. Install a new b ulb .
4. Reinstall the lens to the front turn sig nal lig ht assemb ly and tig hten
the mounting sc rews.
Side turn signal light
OM-H0246
1. Pull the left sid e of the turn sig nal lig ht assem b ly while moving it for-
ward in relation to the vehic le.
2. Remove the b ulb hold er from the sid e turn sig nal lig ht assemb ly b y
turning it c ounterc loc kwise.
3. Pull the b ulb out of the soc ket. Install a new b u lb .
4. Set the b ulb hold er into the sid e turn sig nal lig ht assemb ly and turn it
c loc kwise until it loc ks.
5. Reinstall the sid e turn sig nal lig ht assemb ly on the sid e of the front
fend er.
