2001 SUBARU IMPREZA fuse 18

Maintenance and service10-43
–
CONTINUED –
Fuses
HG0127
HS0202
The fuses are d esig ned to melt d uring an overload t o p revent d amag e to
the wiring harness and elec tric al eq uip ment. The fu ses are loc ated in
two fuse b oxes.
If any lig hts, ac c essories or other elec tric al c ont rols d o not op erate, in-
sp ec t the c orresp ond ing fuse. If a fuse has b lown, rep lac e it.
HS0204
Good Blown
CAUTION
Never replace a fuse with one having a higher rating or with mate-
rial other than a fuse because serious damage or a fire could re-sult.

10-44
Fuse box (behind the coin tray)
1. Turn the ig nition switc h to the “LOCK ” p osition and turn off all elec -
tric al ac c essories.
HS0202
2. Op en the c oin tray and p ull it horizontally to re move it.
3. Determine whic h fuse may b e b lown. The b ac k sid e of the c oin
tray and the “Fuse and c irc uits ” sec tion in c hap ter 11 in this manual
show the c irc uit for eac h fuse.
HS0208
HS0207
Fuse puller Fuse puller
Spare fuses
4. Pull out the fuse with the fuse p uller. The fuse p uller is stored in the
main fuse b ox c over in the eng ine c omp artment.
5. Insp ec t the fuse. If it has b lown, rep lac e it wit h a sp are fuse of the
same rating . The sp are fuses are stored in the main fuse b ox c over in
the eng ine c omp artment.
6. If the same fuse b lows ag ain, this ind ic ates that its system has a

Maintenance and service10-45
–
CONTINUED –
p rob lem. Contac t your SUBARU d ealer for rep airs.
Main fuse box (in the engine compartment)
1. Turn the ig nition switc h to the “LOCK ” p osition and turn off all elec -
tric al ac c essories.
2. Op en the eng ine hood .
3. Remove the main fuse b ox c over.
4. Determine whic h fuse may b e b lown. The fuse b ox c over and
“ Fuse and c irc uits ” sec tion in c hap ter 11 in this manual show the c ir-
c uit for eac h fuse.
HS0208
HS0207
Fuse puller Fuse puller
Spare fuses
5. Pull out the fuse with the fuse p uller p rovid ed i n the main fuse b ox
c over.
6. Insp ec t the fuse. If it has b lown, rep lac e it wit h a sp are fuse of the
same rating . The sp are fuses are stored in the main fuse b ox c over in
the eng ine c omp artment.
7. If the same fuse b lows ag ain, this ind ic ates that its system has a
p rob lem. Contac t your SUBARU d ealer for rep airs.

10-46Main fuse and fusible link
HG0127
The main fuses and fusib le link are d esig ned to mel
t d uring an overload
to p revent d amag e to the wiring harness and elec tri c al eq uip ment.
Chec k the main fuses and fusib le link if any elec tr ic al c omp onent fails to
op erate (exc ep t the starter motor) and other fuses are g ood . A melted
main fuse or fusib le link must b e rep lac ed . Use onl y rep lac ements with
the same sp ec ified rating as the melted main fuse o r fusib le link. If a
main fuse or fusib le link b lows after it is rep lac e d , have the elec tric al sys-
tem c hec ked b y your nearest SUBARU d ealer.
Installation of accessories
Always c onsult your SUBARU d ealer b efore installing fog lig hts or any
other elec tric al eq uip ment in your vehic le. Suc h ac c essories may c ause
the elec tronic system to malfunc tion if they are in c orrec tly installed or if
they are not suited for the vehic le.

11
Specifications Specifications11-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 11-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum load limits 11-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 11-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical system 11-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities 11-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 11-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and circuits 11-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb chart 11-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle identification 11-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Specifications11-5
–
CONTINUED –
Fuses and circuits
Fuse panel located behind the coin tray
HS0224
12 34 5 6
78 9Q WE TY UI OP
R
Fuse panel
Fuse ratingCircuit
115A Heater fan
215AHeater fan
3Emp ty
420AFront ac c essory p ower soc ket
Cig arette lig hter
Remote c ontrolled rear view mirrors
510ATail lig ht
Parking lig ht
615ASRS airb ag
715AFog lig ht
820AABS solenoid
915ARad io
Cloc k

11-6Fuse panel Circuit
Fuse rating
10Emp ty
1115AEng ine ig nition system
SRS airb ag
1210AIllumination b rig htness c ontrol
13Emp ty
1415AAT shift loc k unit
ABS c ontrol
Cruise c ontrol
1520AWind shield wip er and washer
Rear wind ow wip er and washer
1620ABrake lig ht
1715AAir c ond itioner
1815ABac kup lig ht
Turn lig ht
SRS airb ag system warning lig ht
1920ARear ac c essory p ower soc ket
Seat heater

Specifications11-7
–
CONTINUED –

Fuse panel located in the engine compartment
HS0225Fusible link FWD socket
A S
K L Z X
G H J
DF
Fuse panel
Fuse ratingCircuit
2020A Rad iator c ooling fan (Main)
2120ARad iator c ooling fan (Sub )
2220ARear wind ow d efog g er
2315AHazard warning flasher
Horn
2415APower d oor loc k
2510AAutomatic transmission c ontrol unit
2610AAlternator
2715AHead lig ht (rig ht sid e)
2815AHead lig ht (left sid e)
2920ALig hting switc h
3015ACloc k
Interior lig ht
