2001 SAAB 9-3 technical data

253 Technical data
Plates and labelsIn contacts with your Saab dealer it may
sometimes be necessary to quote the car’s
chassis, engine and gearbox numbers.
1 Modification identity plate (in the spare
wheel compartment).
2 V.I.N. number inside windshield.
3 Certification label.
4 Gearbox number.
5 Engine number.
6 Label for tire pressures and color codes
(trim and body).
7 Chassis number.
8 Chassis number (stamped on body).
9 Vehicle Emission Control Information.
10 Spark ignition system information
(Canada only)
4728473IB1523
CANADA US
ProCarManuals.com

254 Technical data1 - Region
____________
Y = Northern Europe
2 - Country _______S = Sweden
3 - Manufacturer ___3 = Saab Automobile AB
4 - Product line ____D = 9-3
5 - Model series ___D = 9-3 S with driver’s and
passenger’s airbag
F = 9-3 SE with driver’s and
passenger’s airbag
P = 9-3 Viggen with driver’s and
passenger’s airbag6 - Body version ___3 = Coupé (3-door)
5 = 5-door
7 = Convertible
7 - Gearbox _______5 = Manual 5-speed
8 = Automatic 4-speed
8 - Engine variant __G = 2.3 Turbo Viggen
H = 2.0 Turbo (185 bhp)
K = 2.0 Turbo (205 bhp)
9 - Check digit ____0-9 or X
10 - Model year _____1 = 2001
11 - Factory ________2 = Trollhättan
7 = Nystad
12 - Serial number __000001-999999 position: 1234567891011 12
||||||||| | | |
VIN:YS3DF 5 8K7 1 2005543
||||||
123456= identification codes for certain chassis details
IB541
ProCarManuals.com

255 Technical data
Several of the systems in your Saab
car may be adjusted to better fit your
individual needsSome functions are governed by legal
requirements and cannot therefore be
reprogrammed.
Consult an authorized Saab dealer for fur-
ther information.
Car alarm/central locking system:
 The level of the siren when locking/
unlocking, HIGH or LOW.
 The number of blinks when locking/
unlocking, 1 to 7.
 Automatic locking of the trunk when the
car is driven, 1 to 8 mph (2-14 km/h), YES
or NO.
 Preclude the unlocking of the trunk while
the car is driven, YES or NO.
 Automatic locking of the trunk after
1 second-4 minutes if it has not been
opened, YES or NO.
 Automatic locking of the trunk when it is
closed, YES or NO.Saab Information Display (SID):
 Outdoor temperature display can be
adjusted.
Miscellaneous:
 Select the on-time for heated rear seat.
 Coolant temperature gauge adjustment
can be increased/decreased.
 Fuel level gauge adjustment can be
increased/decreased.
 Additional sweep of the wipers after wind-
shield washer function (ON or OFF).
 Courtesy Headlight Feature (follow-me
home) on-time can vary from 20 to
50 seconds.
 Night panel illumination deactivation
speed for the speedometer can be
adjusted.
Following adjustments can be done
by the driver:Automatic Climate Control (ACC):
To alter the preprogrammed “AUTO“ start
up mode with your own preferences you can
manually select the desired settings for:
 Temperature.
 Fan speed.
Air distribution.
See “Programming I” on page 90 and “Pro-
gramming II” on page 91.
ProCarManuals.com

256 Technical dataSaab 9-3 Audio System:
The following functions can be adjusted by
the driver (see page 108):
 Maximum starting volume (when the
radio is switched on).
 Telephone volume (if the car is equipped
with a phone connected to the audio sys-
tem).
 Speed dependent volume (volume
increases or decreases with vehicle
speed).
 Loudness.Alarm System:
The glass breakage sensor can be tempo-
rarily disabled, see page 42.
Daytime Running Lights:
To disable, turn off the ignition and pull out
fuse 15, see page 214.
ProCarManuals.com

258 IndexEEconomical motoring
____________ 176
Electrical system, technical data
____ 250
Electrical window
_______________ 136
Electrically adjustable seats
_______ 133
Electrically heated front seats ______ 135
Electrically heated rear seat
_______ 135
Electrically heated rear window _____ 83
Electronic starting interlock
_________ 37
Emergency opening, fuel filler door
_ 150
Emergency operation of the soft top,
Convertible
____________________ 52
Emergency operation of the sunroof
_ 138
Emission control systems
_________ 194
Engine bay
____________________ 193
Engine bay, cleaning
_____________ 226
Engine break-in period _______ 161
, 176
Engine number
_________________ 253
Engine oil, changing
_____________ 196
Engine oil, checking _____________ 196
Engine oil, grade
________________ 247
Engine oil, volume _______________ 247
Engine variants
_________________ 249
Engine, description ______________ 194
Engine, technical data ____________ 247
FFault codes, Audio System
________ 115
Flat spot
______________________ 224Folding the soft top, Convertible
_____ 49
For long trips
___________________ 190
Front fog lights __________________ 77
Fuel filler door, emergency opening
_150
Fuel gauge
_____________________ 68
Fuel grade _____________________ 249
Fueling
_______________________ 157
Fuel-tank capacity
_______________ 249
Fuse table
_____________________ 214
Fuses
________________________ 212
GGearbox number
________________ 253
Gearbox oil, checking
____________ 197
Gearbox oil, grade
_______________ 250
General particulars ______________ 244
General safety instructions, Convertible
48
Glove compartment
______________ 141
HHandbrake
_____________________ 174
Hazard warning lights
_____________ 76
Head restraint
___________________ 18
Headlight flasher _________________ 75
Hood
_________________________ 192
Horn signal
____________________ 137
IIf the car does not start
___________ 153
Ignition switch
__________________ 152
Immobilizer
_____________________ 37
Important considerations concerning
cars with catalytic converters
_____ 156
Important considerations for driving
_ 154
Indicator lights
___________________ 60
Instrument lighting
________________ 78
Integrated booster seat
____________ 26
Interior equipment
_______________ 129
Interior lighting
__________________ 139
Interior lighting, Convertible
_________ 58
Interior rearview mirror
___________ 143
JJump starting
___________________ 187
KKey
___________________________ 36
Key, removing
__________________ 152
LLATCH (child safety)
______________ 21
Labels and plates
_______________ 253
ProCarManuals.com

260 IndexService information
______________ 238
Service intervals
________________ 236
Service record retention
__________ 237
Side airbags
____________________ 30
Ski hatch
______________________ 147
Snow tires _____________________ 252
Soft top storage, Convertible
_______ 56
Spare wheel
___________________ 149
Speedometer ___________________ 66
Starting the engine
______________ 153
Steering-wheel adjustment
________ 137
Storage compartments
___________ 142
Sunroof
_______________________ 138
Switches _______________________ 75
TTachometer
_____________________ 66
Technical data __________________ 243
Telematics
_____________________ 117
Temperature gauge
______________ 67
Textile carpeting, cleaning
________ 225
Through-load hatch
______________ 147
Tie-down eyes
__________________ 148
Tipping the rear seat
_____________ 144
Tire markings
__________________ 218
Tire pressure ___________________ 184
Tire pressures __________________ 217
Tires and wheels, sizes
___________ 252
Tools
_________________________ 149
Top tether
______________________ 23Touching up paintwork
___________ 227
Towing a caravan or trailer ________ 179
Towing the car
__________________ 185
Traction Control System
__________ 172
Trailer hitch attachment ___________ 179
Trailer hitch load
________________ 182
Transmission, automatic
__________ 162
Transmission, manual
____________ 161
Transporting the car
_____________ 185
Traveling abroad
________________ 190
Trip computer, SID _______________ 69
Trip meter
______________________ 66
Trunk
_________________________ 144
Trunk lid lock, Convertible
__________ 56
Trunk lighting
___________________ 139
Trunk, Convertible
________________ 56
Trunk, opening
__________________ 40
Turbo gauge
____________________ 67
Turn signal
_____________________ 76
UUpholstery and trim
______________ 225
Upholstery and trim, care of
_______ 225
Useful tips on starting
____________ 154
Useful tips, ACC
_________________ 92
VVanity mirror
___________________ 143
WWarning and indicator lights
________ 60
Warning labels
____________________ 7
Warning light, AIR BAG (SRS)
______ 32
Washer fluid
___________________ 205
Washer jets
____________________ 205
Washers
_______________________ 78
Washing ______________________ 226
Waxing and polishing
____________ 227
Wear indicators, brake pads
_______ 200
Wear indicators, tires
_____________ 220
Wheels
_______________________ 217
Wheels and tires, sizes
___________ 252
Window glass sensor, car alarm
_____ 42
Windshield washers
______________ 78
Windshield wipers
________________ 78
Winter driving
__________________ 177
Wiper blades
___________________ 204
Wipers
_________________________ 78
